Sharp 20MR10 User Manual

Ref. No. Part No. Description Code Ref. No. Part No. Description Code
21
20MR10
or
VSSTP7NB60F-1
Q702 VS2SC945AQ/-1 J 2SC945AQ AB
or
VS2SC3198Y/-1
Q751 VS2SC945AQ/-1 J 2SC945AQ AB
Q752 VS2SC945AQ/-1 J 2SC945AQ AB
or
VS2SC3198Y/-1
Q2201 VS2SC3928R/-1 J 2SC3928R AB
or
VS2PD601ARQ-1
Q2211 VS2SC3928R/-1 J 2SC3928R AB
DIODES
D52 RH-EX0676GEZZ J Zener Diode, 32V AA
D101 RH-EX0616GEZZ J Zener Diode, 5.6V AA
D352 VHD1SS119//-1 J Diode AB
or
RH-DX0475CEZZ
D353 RH-EX0644GEZZ J Zener Diode, 13V AB
D453 RH-EX0616GEZZ J Zener Diode, 5.1V AA
D455 VHD1SS119//-1 J Diode AB
or
RH-DX0475CEZZ
D456 VHD1SS119//-1 J Diode AB
or
RH-DX0475CEZZ
D457 RH-EX0644GEZZ J Zener Diode, 13V AB
D458 RH-EX0644GEZZ J Zener Diode, 13V AB
D459 VHD1SS119//-1 J Diode AB
or
RH-DX0475CEZZ
D502 RH-DX0131CEZZ J Diode AC
D511 RH-DX0441CEZZ J Diode AC
D632 RH-EX0630GEZZ J Zener Diode, 9.1V AA
D641 RH-EX0630GEZZ J Zener Diode, 9.1V AA
D651 VHD1SS244//-1 J Diode AB
D653 RH-EX0667GEZZ J Zener Diode, 27V AA
D661 RH-DX0468CEZZ J Diode AE
or
RH-DX0302CEZZ
D701 RH-DX0490CEZZ J Diode AC
or
RH-DX0154CEZZ
D702 RH-DX0490CEZZ J Diode AC
or
RH-DX0154CEZZ
D703 RH-DX0490CEZZ J Diode AC
or
RH-DX0154CEZZ
D704 RH-DX0490CEZZ J Diode AC
or
RH-DX0154CEZZ
D707 RH-DX0475CEZZ J Diode AB
or
VHD1SS244//-1
D708 RH-DX0475CEZZ J Diode AB
or
VHD1SS244//-1
D709 RH-DX0229CEZZ J Diode AF
D712 RH-DX0487CEZZ J Diode AC
or
RH-DX0302CEZZ
or
RH-DX0468CEZZ
or
VHDD1NS4///-1
D717 RH-EX0616GEZZ J Zener Diode, 5.6V AA
D725 RH-DX0131CEZZ J Diode AC
D726 VHD1SS119//-1 J Diode AB
or
RH-DX0475CEZZ
D751 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D753 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D758 RH-DX0131CEZZ J Diode AC
VA701 RH-VX0048CEZZ J Varistor AE
or
RH-VX0019CEZZ
PACKAGED CIRCUIT
PR701 RMPTP0026CEZZ J Packaged Circuit AF
X801 RCRSB0001PEZZ J Crystal AL
or
RCRSB0205CEZZ
FILTER AND COILS
CF2040 RFiLA0099CEZZ J Ceramic Filter AE
or
RFiLC0121GEZZ
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L202 VP-XF1R2K0000 J Peaking 1.2µH AB
L203 VP-XF220K0000 J Peaking 22µH AB
L204 RCiLi0632CEZZ J IF Coil AE
L301 VP-XF150K0000 J Peaking 15µH AB
L701 RCiLF0078PEZZ J Coil AF
or
RCiLF0069PEZZ
L705 RCiLP0179CEZZ J Coil AD
L706 RCiLP0197CEZZ J Coil (JA301)
L2040 RCiLB0131CEZZ J Oscillation Coil AE
SF201 RFiLC0441CEZZ J SAW Filter AH
TRANSFORMERS
T601 RTRNZ0731CEZZ J Transformer AG
or
RTRNZ0026PEZZ
T602 RTRNF0213PEZZ J H-Volt Transformer AY
T702 RTRNW0003PEZZ J Transformer AM
or
RTRNW0009PEZZ
CONTROL
R738 RVR-M4588CEZZ X 22k(B) Variable Resistor AF
or
RVR-M4336CEZZ
CAPACITORS
[EL.··· Electrolytic, M-Poly..··· Metalized Polypro Film]
C51 VCEA0A1AW337M X 330 10V EL. AE
C53 VCEA0A1HW105M J 1.0 50V EL. AB
C54 VCEA0A1HW475M J 4.7 50V EL. AB
C101 VCEA0A1CW476M J 47 16V EL. AB
C201 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C202 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C204 VCQYTA1HM223K J 0.022 50V Mylar AB
C205 VCKYPA1HB103K J 0.01 50V Ceramic AA
C206 VCKYCY1HB102K J 1000p 50V Ceramic AA
C207 VCEA0A1CW476M J 47 16V EL. AB
C208 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C209 VCEA0A1HW105M J 1.0 50V EL. AB
C210 VCEA0A1HW474M J 0.47 50V EL. AB
C211 VCKYCY1HB102K J 1000p 50V Ceramic AA
(IC201:iX3354CEZZ)
C212 VCEA0A1HW474M J 0.47 50V EL. AB
C220 VCKYCY1CB104K J 0.1 16V Ceramic AB
C301 VCCCCY1HH470J J 47p 50V Ceramic AA
(IC201:iX3354CEZZ)
C301 VCCCCY1HH220J J 22p 50V Ceramic AA
(IC201:iX3354CEN1)
C302 VCKYCY1HB102K J 1000p 50V Ceramic AA
PWB-A: DUNTKA358WEX0
MAIN UNIT (Continued)
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
