Sharp 20MR10 User Manual

Ref. No. Part No. Description Code Ref. No. Part No. Description Code
22
20MR10
C304 VCCCCY1HH470J J 47p 50V Ceramic AA
(IC201:iX3354CEZZ)
C304 VCCCCY1HH220J J 22p 50V Ceramic AA
(IC201:iX3354CEN1)
C305 VCKYCY1HB103K J 0.01 50V Ceramic AA
C306 VCQYTA1HM103K J 0.01 50V Mylar AB
C354 VCEA0A1HW225M J 2.2 50V EL. AB
C356 VCKYCY1HB332K J 3300p 50V Ceramic AA
C357 VCEA0A1HW106M J 10 50V EL. AB
C358 VCEA0A1HW106M J 10 50V EL. AB
C361 VCEA0A1CW227M J 220 16V EL. AC
C401 VCCCCY1HH470J J 47p 50V Ceramic AA
C411 VCEA0A1AW108M J 1000 10V EL. AC
C412 VCKYCY1HB103K J 0.01 50V Ceramic AA
C414 VCEA0A1HW225M J 2.2 50V EL. AB
C416 VCEA0A1HW105M J 1.0 50V EL. AB
C418 VCKYCY1HB103K J 0.01 50V Ceramic AA
C421 VCEA0A1HW106M J 10 50V EL. AB
C451 VCQYTA1HM563K J 0.056 50V Mylar AB
C454 VCEA0A1HW475M J 4.7 50V EL. AB
C455 VCEA0A1CW226M+J 22 16V EL. AB
C456 VCEA0A1HW475M J 4.7 50V EL. AB
C509 VCKYPA2HB102K J 1000p 500V Ceramic AA
C510 VCEA0A1VW477M J 470 35V EL. AB
C512 VCFYSA1JB224J X 0.22 63V Mylar AF
C513 VCFYSA1JB473J J 0.047 63V Mylar AC
C514 VCEA0A1EW477M J 470 25V EL. AD
C515 VCEA0A1HW475M J 4.7 50V EL. AB
C516 VCKYCY1HB222K J 2200p 50V Ceramic AA
C517 VCEA0A1CW226M J 22 16V EL. AB
C520 VCEA0A1HW107M J 100 50V EL. AB
C530 VCFYFA1HA334J J 0.33 50V Mylar AB
C531 VCFYFA1HA564J J 0.56 50V Mylar AB
C606 VCKYPA2HB561K J 560p 500V Ceramic AA
C607 VCKYPA1HB472K J 4700p 50V Ceramic AA
C610 VCFPVC3CA802H X 8000p 1.6kV M-Poly. AF
C612 VCFPVC2DB474J J 0.47 200V M-Poly. AE
C633 VCEA0A1AW337M X 330 10V EL. AE
C634 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C635 VCEA0A1HW105M J 1.0 50V EL. AB
C636 VCQYTA1HM153K J 0.015 50V Mylar AA
C637 VCEA0A1CW476M J 47 16V EL. AB
C652 VCEA0A1HW475M J 4.7 50V EL. AB
C653 VCEA0A1HW105M J 1.0 50V EL. AB
C661 VCKYPA2HB152K J 1500p 500V Ceramic AA
C662 VCEA0A1CW477M J 470 16V EL. AC
C701 RC-FZ036SCEZZ J 0.1 250V M-Poly. AC
or
RC-FZ008SGEZZ
or
RC-FZ016SCEZZ
or
RC-FZ028SCEZZ
or
RC-FZ029CUMZZ
C702 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C703 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C705 RC-EZ1022CEZZ J 470 200V EL. AK
or
RC-EZ0609CEZZ 220 200V EL.
or
RC-EZ0629CEZZ 220 200V EL.
C706 RC-KZ0092GEZZ J 0.0033 AC250V Ceramic AC
or
RC-KZ021SCEZZ
C717 VCKYPA2HB472K J 4700p 500V Ceramic AB
C723 RC-EZ0638CEZZ J 33 160V EL. AG
C725 RC-EZ0724CEZZ J 100 160V EL. AG
C726 RC-KZ0338CEZZ J 560p 2kV Ceramic AD
C727 VCKYPA2HB472K J 4700p 500V Ceramic AB
C730 VCEA0A1CW108M J 1000 16V EL. AD
C731 VCEA0A1EW107M J 100 25V EL. AC
C732 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C735 VCCCPA1HH680J J 68p 50V Ceramic AA
C737 VCEA0A1EW226M J 22 25V EL. AB
C738 RC-KZ0040CEZZ J 820p 2kV Ceramic AD
or
RC-KZ0340CEZZ
C739 VCEA0A1HW104M J 0.1 50V EL. AB
C740 VCEA0A1EW476M J 47 25V EL. AB
C743 RC-KZ0338CEZZ J 560p 2kV Ceramic AD
C750 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C752 VCEA0A1CW476M J 47 16V EL. AB
C753 RC-KZ0338CEZZ J 560p 2kV Ceramic AD
C754 VCEA0A1CW476M J 47 16V EL. AB
C758 VCEA0A2EW106M J 10 250V EL. AD
C759 VCKYPA2HB102K J 1000p 500V Ceramic AA
C760 VCEA0A1CW108M J 1000 16V EL. AD
C771 VCEA0A1CW476M J 47 16V EL. AB
C772 VCEA0A1CW476M J 47 16V EL. AB
C783 VCQYTA1HM103K J 0.01 50V Mylar AB
C801 VCCCCY1HH180J J 18p 50V Ceramic AA
C802 VCEA0A1CW106M J 10 16V EL. AB
(IC201:iX3354CEN1)
C807 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C808 VCEA0A1CW106M J 10 16V EL. AB
C811 VCKYCY1CB473K J 0.047 16V Ceramic AA
C812 VCEA0A1HW474M J 0.47 50V EL. AB
C901 VCEA0A1HW105M J 1.0 50V EL. AB
C905 VCEA0A1HW106M J 10 50V EL. AB
C2001 VCCCCY1HH101J J 100p 50V Ceramic AA
C2002 VCCCCY1HH101J J 100p 50V Ceramic AA
C2040 VCEA0A1AW107M J 100 10V EL. AB
C2041 VCEA0A1HW105M J 1.0 50V EL. AB
C2060 VCKYCY1CB104K J 0.1 16V Ceramic AB
C2061 VCKYCY1HB222K J 2200p 50V Ceramic AA
C2062 VCEA0A1AW107M J 100 10V EL. AB
C2201 VCKYCY1HB682K J 6800p 50V Ceramic AA
C2202 VCCCCY1HH560J J 56p 50V Ceramic AA
C2601 VCEA0A1HW475M J 4.7 50V EL. AB
C2602 VCCCCY1HH101J J 100p 50V Ceramic AA
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. A A
RJ8 VRS-CY1JF000J J 0 1/16W M-Ox. A A
RJ9 VRS-CY1JF000J J 0 1/16W M-Ox. A A
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. A A
RJ1 2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ1 8 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ19 VRS-CY1JF000J J 0 1/16W M-Ox. A A
RJ20 VRS-CY1JF000J J 0 1/16W M-Ox. A A
RJ21 VRS-CY1JF000J J 0 1/16W M-Ox. A A
R53 VRS-RG3LB223J X 22k 3W M-Ox. AF
R54 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R55 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R56 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R57 VRD-RA2BE563J J 56k 1/8W Carbon AA
R101 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R201 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R202 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R203 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R204 VRS-CY1JF270J J 27 1/16W M-Ox. AA
R205 VRD-RA2BE680J J 68 1/8W Carbon AA
R206 VRD-RA2EE151J J 150 1/4W Carbon AA
R207 VRD-RA2BE123J J 12k 1/8W Carbon AA
R208 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R209 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
(IC201:iX3354CEZZ)
R209 VRS-CY1JF000J J 0 1/16W M-Ox. A A
(IC201:iX3354CEN1)
R210 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
PWB-A: DUNTKA358WEX0
MAIN UNIT (Continued)
!
!
!
!
!
!
!
!
!
!
