Ref. No. Part No. « Description Code
CF2040 RFILA0099CEZZ+ X FILTER AB
SF201 RFILC0441CEZZ X SAW Filter AD
L50 VP-DF150K0000Y X Peaking 15mH AB
L201 VP-XF1R2K0000Y X Peaking 1.2mH AB
L202 VP-XF1R2K0000Y X Peaking 1.2mH AB
L203 VP-XF220K0000Y X Peaking 22mH AB
L204 RCILI0632CEZZ X IF Coil AB
L301 VP-XF150K0000Y X Peaking 15mH AB
U L701 RCILF0078PEZZ X Coil Line Filter AC
U L705 RCILP0179CEZZ+ X Coil AB
L706 RCILP0197CEZZ X Coil AB
L2040 RCILB0131CEZZ X Coil (OSC) AB
U T601 RTRNZ0731CEZZ X Transformer AD
U T602 RTRNF0213PEZZ X H-Volt Transformer AP
U T702 RTRNW0003PEZZ X Power Transformer AE
R738 RVR-M4588CEZZ+ X 22k 130V Adj. AB
C51 VCEA0A1AW337M+ X 330 10V EL. AB
C53 VCEA0A1HW105M+ X 1 50V EL. AB
C54 VCEA0A1HW475M+ X 4.7 50V EL. AB
C55 VCEA0A1AW107M+ X 100 10V EL. AB
C101 VCEA0A1CW476M+ X 47 16V EL. AB
C201 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C202 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C203 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C204 VCQYTA1HM223J+ X 0.022 50V Mylar AB
C205 VCKYPA1HB103K+ X 0.01 50V Ceramic AB
C206 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C207 VCEA0A1CW476M+ X 47 16V EL. AB
C208 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C209 VCEA0A1HW105M+ X 1 50V EL. AB
C210 VCEA0A1HW474M+ X 0.47 50V EL. AB
C212 VCEA0A1HW474M+ X 0.47 50V EL. AB
C220 VCKYCY1CB104KY X 0.1 16V Ceramic AA
C301 VCCCCY1HH220JY X 22p 50V Ceramic AA
C302 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C304 VCCCCY1HH220JY X 22p 50V Ceramic AA
C305 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C306 VCQYTA1HM103J+ X 0.01 50V Mylar AB
C354 VCEA0A1HW225M+ X 2.2 50V EL. AB
C356 VCKYCY1HB332KY X 3300p 50V Ceramic AA
C357 VCEA0A1HW106M+ X 10 50V EL. AB
C358 VCEA0A1HW106M+ X 10 50V EL. AB
C361 VCEA0A1CW227M+ X 220 16V EL. AB
C401 VCCCCY1HH470JY X 47p 50V Ceramic AA
C411 VCEA0A1AW108M+ X 1000 10V EL. AB
C412 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C414 VCEA0A1HW225M+ X 2.2 50V EL. AB
C416 VCEA0A1HW105M+ X 1 50V EL. AB
C418 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C421 VCEA0A1HW106M+ X 10 50V EL. AB
C451 VCQYTA1HM563J+ X 0.056 50V Mylar AB
C454 VCEA0A1HW475M+ X 4.7 50V EL. AB
C455 VCEA0A1CW226M+ X 22 16V EL. AB
C456 VCEA0A1HW475M+ X 4.7 50V EL. AB
C509 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C510 VCEA0A1VW477M+ X 470 35V EL. AB
C512 VCFYSA1JB224J+ X 0.22 63V Mylar AB
C513 VCFYSA1JB473J+ X 0.047 63V Mylar AB
C514 VCEA0A1EW477M+ X 470 25V EL. AB
C515 VCEA0A1HW475M+ X 4.7 50V EL. AB
Ref. No. Part No. « Description Code
C516 VCKYCY1HB222KY X 2200p 50V Ceramic AA
C517 VCEA0A1CW226M+ X 22 16V EL. AB
C520 VCEA0A1HW107M+ X 100 50V EL. AB
C530 VCFYFA1HA334J+ X 0.33 50V Mylar AB
C531 VCFYFA1HA564J+ X 0.56 50V Mylar AB
C606 VCKYPA2HB561K+ X 560p 500V Ceramic AB
C607 VCKYPA1HB472K+ X 4700p 50V Ceramic AB
C610 VCFPVC3ZA772H X 7700p 1.5kV M-Poly. AB
C612 VCFPVC2DB474J X 0.47 200V M-Poly. AB
C633 VCEA0A1AW337M+ X 330 10V EL. AB
C634 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C635 VCEA0A1HW105M+ X 1.0 50V EL. AB
C636 VCQYTA1HM153J+ X 0.015 50V Mylar AB
C637 VCEA0A1CW476M+ X 47 16V EL. AB
C652 VCEA0A1HW475M+ X 4.7 50V EL. AB
C653 VCEA0A1HW105M+ X 1.0 50V EL. AB
C661 VCKYPA2HB152K+ X 1500p 500V Ceramic AB
C662 VCEA0A1CW477M+ X 470 16V EL. AB
C701 RC-FZ036SCEZZ X
0.1mF
AC125V Plastic AB
C702 RC-KZ0029CEZZ+ X 0.01 250V Ceramic AB
C703 RC-KZ0029CEZZ+ X 0.01 250V Ceramic AB
C705 RC-EZ0718CEZZ X 470 200V EL. AE
C706 RC-KZ0092GEZZA X 3300p AC125V Ceramic AB
C717 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C723 RC-EZ0638CEZZ X 33 160V EL. AC
C725 RC-EZ0724CEZZ X
100mF
160V EL. AC
C726 VCKYPH3DB561K X 560p 2kV Ceramic AB
C727 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C730 VCEA0A1CW108M+ X
1000mF
16V EL. AB
C731 VCEA0A1EW107M+ X
220mF
25V EL. AB
C732 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C735 VCCCPA1HH680J+ X 68p 50V Ceramic AA
C737 VCEA0A1EW226M+ X 22 25V EL. AB
C738 RC-KZ0040CEZZ X 820p 2kV Ceramic AB
C739 VCEA0A1HW104M+ X 0.1 50V EL. AB
C740 VCEA0A1EW476M+ X 47 25V EL. AB
C743 VCKYPH3DB561K X 560p 2kV Ceramic AB
C750 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C752 VCEA0A1CW476M+ X 47 16V EL. AB
C754 VCEA0A1CW476M+ X 47 16V EL. AB
C758 VCEA0A2EW106M+ X 10 250V EL. AB
C759 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C760 VCEA0A1CW108M+ X 1000 16V EL. AB
C771 VCEA0A1CW476M+ X 47 16V EL. AB
C772 VCEA0A1CW476M+ X 47 16V EL. AB
C783 VCQYTA1HM103J+ X 0.01 50V Mylar AB
C801 VCCCCY1HH180JY X 18p 50V Ceramic AA
C802 VCEA0A1CW106M+ X 10 16V EL. AB
C807 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C808 VCEA0A1CW106M+ X 10 16V EL. AB
C809 VCEA0A1HW105M+ X 1.0 50V EL. AB
C811 VCKYCY1CB473KY X 0.047 16V Ceramic AA
C812 VCEA0A1HW474M+ X 0.47 50V EL. AB
C901 VCEA0A1HW105M+ X 1.0 50V EL. AB
C905 VCEA0A1HW106M+ X 10 50V EL. AB
C2001 VCCCCY1HH101JY X 100p 50V Ceramic AA
C2002 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C2040 VCEA0A1AW107M+ X 100 10V EL. AB
C2041 VCEA0A1HW105M+ X 1.0 50V EL. AB
C2060 VCKYCY1CB104KY X 0.1 16V Ceramic AA
C2061 VCKYCY1HB222KY X 2200p 50V Ceramic AA
C2062 VCEA0A1AW107M+ X 100 10V EL. AB
C2201 VCKYCY1HB682KY X 6800p 50V Ceramic AA
C2202 VCCCCY1HH560JY X 56p 50V Ceramic AA
C2601 VCEA0A0JW107M+ X 100 6.3V EL. AB
C2602 VCCCCY1HH101JY X 100p 50V Ceramic AA
RJ2 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ7 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ8 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
PWB-A: DUNTKA358WEX1
MAIN UNIT (Continued)
PACKAGED CIRCUITS
FILTERS AND COILS
TRANSFORMERS
CAPACITORS
CONTROL
CAPACITORS
RESISTORS
19
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
20MU14
