Ref. No. Part No. « Description Code
P651 QPLGN0361CEZZA X PLUG (3 PINS) RHU AB
P701 QPLGN0260CEZZ X PLUG (2 PINS) AB
P751 QPLGN0461CEZZA X PLUG (4 PINS) RHU AB
P2001 QPLGN0561CEZZA X PLUG (5 PINS) RHU AB
RMC2601 RRMCU0222CEZZ X R/C RECEIVER AD
JA409 RBLN-0047CEZZ* X FERRITE BEAD AB
RDA501 PRDAR0106GJFW X HEATSINK (STEEL) AB
RDA602 PRDAR0216PEFW X HEATSINK (STEEL) AB
RDA701 PRDAR0026PEFW X HEATSINK (STEEL) AB
LX-BZ3100CEFD X SCREW AA
LX-TZ3004CEFD X SCREW AA
Q852 VSBF422////-1+ X BF422 AB
Q854 VSBF422////-1+ X BF422 AB
Q856 VSBF422////-1+ X BF422 AB
Q881 VS2SA1266-Y-1+ X 2SA1266(Y) AB
D882 RH-DX0475CEZZY X Diode AB
D885 RH-DX0475CEZZY X Diode AB
L852 VP-MK820K0000+ X Peaking
82 mH
AB
C851 VCCCCY1HH151JY X 150p 50V Ceramic AA
C852 VCCCCY1HH151JY X 150p 50V Ceramic AA
C853 VCCSPA1HL151J+ X 150p 50V Ceramic AA
C854 RC-KZ0029CEZZ+ X 0.01 250V Ceramic AB
C883 VCEA0A1CW336M+ X 33 16V EL. AB
R852 VRD-RA2BE181JY X 180
1/8W Carbon AA
R853 VRS-CY1JF121J
Y X 120 1/16W M-Ox. AA
U R857 VRS-VV3AB123J X 12K 1W M-Ox. AB
R858 VRD-RM2HD332JY X 3.3k 1/2W Carbon AA
R860 VRD-RA2BE181JY X 180
1/8W Carbon AA
R861 VRS-CY1JF121JY X 120 1/16W M-Ox. AA
U R865 VRS-VV3AB123J X 12K 1W M-Ox. AB
R866 VRD-RM2HD332JY X 3.3k 1/2W Carbon AA
R867 VRS-CY1JF470J
Y X 47 1/16W M-Ox. AA
R868 VRS-CY1JF181J
Y X 180 1/16W M-Ox. AA
R869 VRS-CY1JF121JY X 120 1/16W M-Ox. AA
U R873 VRS-VV3AB123J X 12K 1W M-Ox. AB
R874 VRD-RM2HD332JY X 3.3k 1/2W Carbon AA
R881 VRS-CY1JF561J
Y X 560 1/16W M-Ox. AA
R882 VRS-CY1JF391JY X 390 1/16W M-Ox. AA
R883 VRD-RA2BE561J
Y X 560 1/8W Carbon AA
R884 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R886 VRS-CY1JF821J
Y X 820 1/16W M-Ox. AA
R887 VRD-RA2BE470J
Y X 47 1/8W Carbon AA
R890 VRS-CY1JF470JY X 47 1/16W M-Ox. AA
R891 VRS-CY1JF470JY X 47 1/16W M-Ox. AA
P851 QPLGN0561CEZZ X PLUG (5 PINS) AB
P852 QPLGN0461CEZZ X PLUG (4 PINS) AB
SC852 QSOCV0840CEZZ X SOCKET (CRT) AC
Ref. No. Part No. « Description Code
R2029 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2032 VRD-RA2BE471JY X 470 1/8W Carbon AA
R2033 VRS-CY1JF684JY X 680k 1/16W M-Ox. AA
R2034 VRS-CY1JF684JY X 680k 1/16W M-Ox. AA
R2040 VRS-CY1JF102JY X 1.0k 1/16W M-Ox. AA
R2041 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R2042 VRD-RA2BE101JY X 100 1/8W M-Ox. AA
R2043 VRD-RA2BE101JY X 100 1/8W M-Ox. AA
R2044 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R2045 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2047 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R2048 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R2049 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R2060 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R2061 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R2062 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
R2063 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R2065 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2066 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2067 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2068 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2070 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2072 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2103 VRD-RA2BE101JY X 100 1/8W M-Ox. AA
R2104 VRD-RA2BE101JY X 100 1/8W M-Ox. AA
R2201 VRD-RA2BE103JY X 10k 1/8W M-Ox. AA
R2202 VRD-RA2BE473JY X 47k 1/8W Carbon AA
R2203 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R2211 VRD-RA2BE222JY X 2.2k 1/8W Carbon AA
R2212 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R2213 VRD-RA2BE223JY X 22k 1/8W Carbon AA
R2401 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2402 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2403 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2404 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2501 VRS-CY1JF123JY X 12k 1/16W M-Ox. AA
R2503 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R2504 VRS-CY1JF123JY X 12k 1/16W M-Ox. AA
R2505 VRS-CY1JF563JY X 56k 1/16W M-Ox. AA
R2506 VRS-CY1JF563JY X 56k 1/16W M-Ox. AA
R2507 VRS-CY1JF823JY X 82k 1/16W M-Ox. AA
R2508 VRS-CY1JF153JY X 15k 1/16W M-Ox. AA
R2509 VRS-CY1JF272JY X 2.7k 1/16W M-Ox. AA
R2601 VRD-RA2BE100JY X 10 1/8W Carbon AA
R2603 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2605 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2607 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
S2501 QSW-K0202PEZZ+ X SWITCH Power AB
S2502 QSW-K0202PEZZ+ X SWITCH Vol-Down AB
S2503 QSW-K0202PEZZ+ X SWITCH Vol-Up AB
S2504 QSW-K0202PEZZ+ X SWITCH CH-Down AB
S2505 QSW-K0202PEZZ+ X SWITCH CH-Up AB
U RY701 RRLYJ0081CEZZ X RELAY AD
U F701 QFS-B4023CEZZ X FUSE - 4A 125V AB
FB351 RBLN-0047CEZZY X FERRITE BEAD AB
FB601 RBLN-0047CEZZY X FERRITE BEAD AB
FB2002 RBLN-0037CEZZY X FERRITE BEAD AB
FH701 QFSHD1013CEZZ+ X FUSE CLIP AB
FH702 QFSHD1014CEZZ+ X FUSE CLIP AB
J9
03 QJAKE0211CE09 X JACK (AUDIO IN)
AC
P302 QPLGN0261CEZZ X PLUG (2 PINS) AB
P401 QPLGN0561CEZZA X PLUG (5 PINS) RHU AB
P601 QPLGN0660CEZZ X PLUG (6 PINS) AB
MISCELLANEOUS PARTS
MISCELLANEOUS PARTS
SWITCHES
JACK (A/V)
PLUG
DUNTKA359WEW0
PWB-B CRT Unit
PWB-A: DUNTKA358WEX1
MAIN UNIT (Continued)
RESISTORS
(Continued)
TRANSISTORS
DIODES
COILS
CAPACITORS
RESISTORS
MISCELLANEOUS PARTS
21
J905 QJAKE0211CE04 X JACK (VIDEO IN) AC
