Ref. No. Part No. « Description Code
RJ9 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ10 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ12 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ18 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ19 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ20 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ21 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ16 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ18 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ19 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ20 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ21 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R53 VRS-RG3LB223J+ X 22k 3W M-Ox. AB
R54 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R55 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R56 VRS-CY1JF823JY X 82k 1/16W M-Ox. AA
R57 VRD-RA2BE563JY X 56k 1/8W Carbon AA
R101 VRD-RA2BE152JY X 1.5k 1/8W Carbon AA
R201 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R202 VRS-CY1JF122JY X 1.2k 1/16W M-Ox. AA
R203 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R204 VRS-CY1JF270JY X 27 1/16W M-Ox. AA
R205 VRD-RA2BE680JY X 68 1/8W Carbon AA
R206 VRD-RA2EE151JY X 150 1/4W Carbon AA
R207 VRD-RA2BE223JY X 22k 1/8W Carbon AA
R208 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R209 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R210 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R211 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R212 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R215 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R220 VRS-CY1JF331JY X 330 1/16W M-Ox. AA
R301 VRS-CY1JF102JY X 1.0k 1/16W M-Ox. AA
R302 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R353 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R354 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R355 VRD-RA2BE223JY X 22k 1/8W Carbon AA
R357 VRS-CY1JF822JY X 8.2k 1/16W M-Ox. AA
R401 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R402 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R403 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R404 VRD-RA2BE102JY X 1.0k 1/8W Carbon AA
R411 VRS-CY1JF684JY X 680k 1/16W M-Ox. AA
R412 VRS-CY1JF391JY X 390 1/16W M-Ox. AA
R413 VRS-CY1JF102JY X 1.0k 1/16W M-Ox. AA
R414 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R421 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
U R451 VRS-RG2HC103J+ X 10k 1/2W M-Ox. AB
R453 VRD-RA2BE152JY X 1.5k 1/8W Carbon AA
R454 VRD-RA2EE334JY X 330k 1/4W Carbon AA
R455 VRD-RA2BE392JY X 3.9k 1/8W Carbon AA
R456 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R457 VRD-RA2BE102JY X 1.0k 1/8W Carbon AA
R458 VRD-RA2EE334JY X 330k 1/4W Carbon AA
R460 VRD-RA2BE152JY X 1.5k 1/8W Carbon AA
R461 VRS-CY1JF184JY X 180k 1/16W M-Ox. AA
R462 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R495 VRS-RG3DB820J+ X 180k 1/16W M-Ox. AB
R512 VRD-RM2HD102JY X 1.0k 1/2W Carbon AA
R513 VRD-RM2HD102JY X 1.0k 1/2W Carbon AA
R514 VRD-RM2HD1R0JY X 1.0 1/2W Carbon AA
R515 VRS-RG3AB391J+ X 390 1W M-Ox. AB
R516 VRS-CY1JF153JY X 15k 1/16W M-Ox. AA
R517 VRS-CY1JF102JY X 1.0k 1/16W M-Ox. AA
R518 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R519 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R520 VRD-RM2HD1R5JY X 1.5 1/2W Carbon AA
R522 VRD-RA2BE102JY X 1.0k 1/2W Carbon AA
R523 VRD-RA2BE562JY X 5.6k 1/8W Carbon AA
R525 VRD-RA2BE272JY X 2.7k 1/8W Carbon AA
20
PWB-A: DUNTKA358WEX1
MAIN UNIT (Continued)
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No. « Description Code
R527 VRD-RA2BE223JY X 22k 1/8W Carbon AA
R528 VRD-RA2BE272JY X 2.7k 1/8W Carbon AA
R529 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
U R604 VRS-RG3DB682J+ X 6.8k 2W M-Ox. AB
R605 VRD-RA2BE121JY X 120 1/8W Carbon AA
R606 VRD-RA2BE102JY X 1.0k 1/8W Carbon AA
R607 VRS-RG3DB682J+ X 6.8k 2W M-Ox. AB
U R608 VRS-RG3DB391J+ X 390 2W M-Ox. AB
U R609 VRS-RG3AB562J+ X 5.6k 1W M-Ox. AB
R610 VRD-RM2HD220JY X 22 1/2W Carbon AA
U R611 VRS-KA3HG3R3K X 3.3 5W M-Ox. AB
R622 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R623 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R624 VRN-RA2BK472FY X 4.7k 1/8W M-Film AB
R634 VRD-RM2HD121JY X 120 1/2W Carbon AA
R635 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R636 VRD-RA2EE221JY X 220 1/4W Carbon AA
U R641 VRS-RG3AB682J+ X 6.8k 1W M-Ox. AB
R651 VRD-RM2HD270JY X 27 1/2W Carbon AA
R653 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R654 VRD-RA2BE154JY X 150k 1/8W Carbon AA
R655 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R659 VRN-RL3AB3R3J+ X 3.3 1W M-Ox. AB
R661 VRN-RL3ABR47J+ X 0.47 1W M-Film AB
R662 VRD-RA2BE102GY X 1.0k 1/8W Carbon AA
U R702 RR-DZ0049CEZZY X 3.9M 1/2W Carbon AB
U R703 VRW-KP3HC1R8K X 1.8 5W Cement AB
U R705 VRN-RL3ABR39J+ X 0.39 1W M-Ox. AB
U R706 VRN-RL3ABR39J+ X 0.39 1W M-Ox. AB
U R707 VRD-RM2HD270JY X 27 1/2W Carbon AA
U R708 VRS-CY1JF102JY X 1.0k 1/16W M-Ox. AA
U R710 VRS-RG2HC102J+ X 1k 1/2W M-Ox. AB
U R711 VRS-CY1JF334JY X 330k 1/16W M-Ox. AA
R712 VRD-RA2BE100JY X 10 1/8W Carbon AA
R713 VRS-RG2HC122J+ X 1.2k 1/2W M-Ox. AB
R715 VRD-RA2BE150JY X 15 1/8W Carbon AA
R716 VRS-RG3AB121J+ X 120 1W M-Ox. AB
R721 VRD-RM2HD124JY X 120k 1/2W Carbon AA
R723 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R725 VRS-RG2HC821J+ X 820 1/2W M-Ox. AB
R733 VRD-RA2EE394JY X 390k 1/4W Carbon AA
R736 VRD-RM2HD184JY X 180k 1/2W Carbon AA
R739 VRD-RM2HD332JY X 3.3k 1/2W Carbon AA
R740 VRD-RM2HD470JY X 47 1/2W Carbon AA
R741 VRN-RA2BK682FY X 6.8k 1/8W M-Film AB
R751 VRD-RA2BE821JY X 820 1/8W Carbon AA
R752 VRD-RA2BE392JY X 3.9k 1/8W Carbon AA
U R755 VRD-RM2HD151JY X 150 1/2W Carbon AA
U R758 VRS-RG2HC100J+ X 10 1/2W M-Ox. AB
R759 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
U R773 VRS-VV3LB270J X 27 3.0W M-Ox. AB
R774 VRS-VV3LB680J X 68 3.0W M-Ox. AB
R801 VRD-RM2HD470JY X 47 1/2W Carbon AA
R807 VRS-CY1JF272JY X 2.7k 1/16W M-Ox. AA
R808 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R809 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R810 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R901 VRD-RA2BE101JY X 100 1/8W M-Ox. AA
R902 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R906 VRS-CY1JF102JY X 1.0k 1/16W M-Ox. AA
R925 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R961 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R962 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2001 VRS-CY1JF102JY X 1.0k 1/16W M-Ox. AA
R2002 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2006 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2008 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R2009 VRS-CY1JF102JY X 1.0k 1/16W M-Ox. AA
R2010 VRS-CY1JF102JY X 1.0k 1/16W M-Ox. AA
R2012 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2016 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R2018 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2020 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R2022 VRS-CY1JF333JY X 33k 1/8W Carbon AA
R2023 VRD-RA2BE223JY X 22k 1/8W Carbon AA
R2024 VRD-RA2BE682JY X 6.8k 1/8W Carbon AA
R2025 VRD-RA2BE682JY X 6.8k 1/8W Carbon AA
R2026 VRD-RA2BE682JY X 6.8k 1/8W Carbon AA
R2027 VRD-RA2BE682JY X 6.8k 1/8W Carbon AA
R2028 VRS-CY1JF102JY X 1.0k 1/16W M-Ox. AA
