Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
27
20R-S100S
PWB-E : DUNTKA070WEV2
MTS MODULE UNIT
INTEGRATED CIRCUITS
IC3001 VHiCXA2074Q-1 J CXA2074Q AY
IC3371 VHiAN7511//-1 J AN7511 AK
DIODES
D3301 RH-EX0643GEZZ J Zener Diode, 13V AB
CAPACITORS
[EL.··· Electrolytic]
C3001 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3002 VCKYCY1HB562K J 5600p 50V Ceramic AA
C3003 VCQYTA1HM123K J 0.012 50V Mylar AA
C3004 VCEA0A1HW105M J 1.0 50V EL. AB
C3005 VCEA9A1HW475M J 4.7 50V EL. AB
C3006 VCEA0A1HW106M J 10 50V EL. AB
C3007 VCEA0A1HW475M J 4.7 50V EL. AB
C3008 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C3009 VCEA0A1CW227M J 220 16V EL. AC
C3010 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3011 VCEA0A1HW475M J 4.7 50V EL. AB
C3012 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3013 VCKYCY1HB272K J 2700p 50V Ceramic AA
C3014 VCQYTA1HM473K J 0.047 50V Mylar AB
C3015 VCEACA1HC335K X 3.3 50V EL. AF
C3016 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3017 VCEACA1CC106K J 10 16V EL. AC
C3018 VCEA0A1HW105M J 1.0 50V EL. AB
C3374 VCEA0A1HW225M J 2.2 50V EL. AB
C3376 VCKYCY1HB332K J 3300p 50V Ceramic AA
C3377 VCEA0A1HW106M J 10 50V EL. AB
C3378 VCEA0A1HW106M J 10 50V EL. AB
RESISTORS
[M-Ox.··· Metal Oxide]
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R3001 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R3002 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R3003 VRS-CY1JF105J J 1.0M 1/16W M-Ox. AA
R3004 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R3005 VRS-CY1JF623J J 62k 1/16W M-Ox. AA
R3007 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R3008 VRS-CY1JF302J J 3.0k 1/16W M-Ox. AA
R3010 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R3011 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R3012 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R3373 VRS-CY1JF683J J 68k 1/16W M-Ox. AA
R3374 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA
R3375 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R3377 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
MISCELLANOUS PARTS
P351 QPLGN0561CEZZ J Plug, 5-pin(BBN) AB
P3001 QPLGN0242FJ00 J Plug, 10-pinEA) AE
To Next Page
