Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
26
20R-S100S
PWB-B: DUNTKA359WEW2
CRT UNIT
TRANSISTORS
Q852 VSBF422////-1 J BF422 AC
or
VS2SC2229O/1E
Q854 VSBF422////-1 J BF422 AC
or
VS2SC2229O/1E
Q856 VSBF422////-1 J BF422 AC
or
VS2SC2229O/1E
Q881 VS2SA1266-Y-1 J 2SA1266-Y AA
or
VS2SA1015-Y-1
DIODES
D882 RH-DX0475CEZZ J Diode AB
D885 RH-DX0475CEZZ J Diode AB
COIL
L852 VP-MK820K0000 J Peaking 82µH AB
CAPACITORS
[EL.··· Electrolytic]
C851 VCCCCY1HH151J J 150p 50V Ceramic AA
C852 VCCCCY1HH151J J 150p 50V Ceramic AA
C853 VCCSPA1HL151J J 150p 50V Ceramic AA
C854 RC-KZ0029CEZZ J 0.01 1kV Ceramic AC
or
RC-KZ0016GEZZ
C883 VCEA0A1CW336M J 33 16V EL. AB
RESISTORS
[M-Ox.··· Metal Oxide]
R851 VRS-CY1JF470J J 47 1/16W M-Ox. AA
R852 VRD-RA2BE181J J 180 1/8W Carbon AA
R853 VRS-CY1JF121J J 120 1/16W M-Ox. AA
å R857 VRS-VU3AE123J J 12k 1W M-Ox. AB
R858 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R859 VRS-CY1JF470J J 47 1/16W M-Ox. AA
R860 VRD-RA2BE181J J 180 1/8W Carbon AA
R861 VRS-CY1JF121J J 120 1/16W M-Ox. AA
å R865 VRS-VU3AE123J J 12k 1W M-Ox. AB
R866 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R867 VRS-CY1JF470J J 47 1/16W M-Ox. AA
R868 VRS-CY1JF181J J 180 1/16W M-Ox. AA
R869 VRS-CY1JF121J J 120 1/16W M-Ox. AA
å R873 VRS-VU3AE123J J 12k 1W M-Ox. AB
R874 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R881 VRS-CY1JF561J J 560 1/16W M-Ox. AA
R882 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R883 VRD-RA2BE561J J 560 1/8W Carbon AA
R884 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R886 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R887 VRD-RA2BE470J J 47 1/8W Carbon AA
MISCELLANEOUS PARTS
P851 QPLGN0561CEZZ J Plug, 5-pin(GBN) AB
P852 QPLGN0461CEZZ J Plug, 4-pin(YBN) AB
SC851 QSOCV0016PEZZ X CRT Socket
or
QSOCV0933CEZZ
R2501 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2503 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R2504 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2505 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2506 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2507 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R2508 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R2509 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA
R2601 VRD-RA2BE331J J 330 1/8W Carbon AA
SWITCHES
S2501 QSW-K0202PEZZ R Power AC
or
QSW-K0079GEZZ
S2502 QSW-K0202PEZZ R VOL-Down AC
or
QSW-K0079GEZZ
S2503 QSW-K0202PEZZ R VOL-Up AC
or
QSW-K0079GEZZ
S2504 QSW-K0202PEZZ R CH-Down AC
or
QSW-K0079GEZZ
S2505 QSW-K0202PEZZ R CH-Up AC
or
QSW-K0079GEZZ
MISCELLANEOUS PARTS
å F701 QFS-B4023CEZZ J Fuse 4A/125V AC
or
QFS-B4021GEZZ
FB351 RBLN-0091GEZZ X Ferrite Bead AC
FB601 RBLN-0047CEZZ J Ferrite Bead AB
FB2002RBLN-0091GEZZ X Ferrite Bead AC
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
J906 QJAKE0202CE09 X Jack, Audio-In(L)
or
QJAKE0156CEZZ
J907 QJAKE0202CE02 J Jack, Audio-In(R) AD
or
QJAKE0157CEZZ
J908 QJAKE0202CE04 X Jack, Video-In
or
QJAKE0155CEZZ
J951 QJAKG0033CEZZ J Jack, Rear AV-In AL
P301 QPLGN0561CEZZ J Plug, 5-pin(BBN) AB
P303 QPLGN0461CEZZ J Plug, 4-pin(S) AB
P401 QPLGN0561CEZZ J Plug, 5-pin(GBN) AB
P601 QPLGN0660CEZZ J Plug, 6-pin(K) AC
P651 QPLGN0361CEZZ J Plug, 3-pin(TP651-3) AB
P701 QPLGN0260CEZZ J Plug, 2-pin(M) AC
P751 QPLGN0461CEZZ J Plug, 4-pin(YBN) AB
P2001 QPLGN0561CEZZ J Plug, 5-pin(TP2001-5) AB
SC3001 QSOCN0259FJ00 J Socket, 10-pin(EA) AE
RMC2601 RRMCU0252CEZZ X R/C Receiver AH
or
RRMCU0232CEZZ
HM602 LX-GZ3001PEZZ J Screw AB
HM604 LX-GZ3001PEZZ J Screw AB
HM612 LX-GZ3001PEZZ J Screw AB
HM613 LX-GZ3002PEZZ J Screw AB
HM614 LX-GZ3002PEZZ J Screw AB
HM726 LX-GZ3002PEZZ J Screw AB
HM740 LX-GZ3002PEZZ J Screw AB
HM741 LX-GZ3002PEZZ J Screw AB
HM742 LX-GZ3002PEZZ J Screw AB
RDA501 PRDAR0297PEFW R Heat Sink, for IC501 AD
RDA602 PRDAR0216PEFW R Heat Sink, for Q602 AE
RDA701 PRDAR0026PEFW R Heat Sink, for Q701 AD
LX-BZ3100CEFD J Screw AA
PWB-A: DUNTKA358WEW2
MAIN UNIT (Continued)
