Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
33
21BM2GMK2
PICTURE TUBE
å VB51JSY63X/*S R Picture Tube CE
å RCiLG0097PEZZ R Degaussing Coil AP
å DY601 RCiLHA009WJZZ R Deflection Yoke BB
QEARC2107PEZZ R Grounding Strap AE
PMAGF3046CEZZ R Magnet AF
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A DUNTKB508WEA7 - Main. Unit —
PWB-B DUNTKB509WEA7 - CRT Unit —
DUNTKB508WEA7
PWB-A Main Unit
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY NOT INDEPENDENTLY.
å TU201 VTUCTF5511+++ R Tuner AZ
INTEGRATED CIRCUITS
IC302 VHiAN7523++-1 R AN7523 AH
å IC501 VHiTDA9302H-1 R TDA9302H AH
IC601 VHiKA7808AP-1 R KIA7808API AE
IC701 VHiSTRG5653-1 R STR-G5653 AQ
IC801 RH-iX3368CEN6 R I.C. BE
IC1005 VHiCAT24W04-1 R I.C. AE
TRANSISTORS
Q251 VS2PD601AR/-1Y R 2PD601AR AB
Q252 VS2PC1815G+-1+ R 2PC1815G+ AC
Q302 VS2PD601AR/-1Y R 2PD601AR AB
Q321 VS2PD601AR/-1Y R 2PD601AR AB
Q352 VS2PD601AR/-1Y R 2PD601AR AB
Q501 VS2PC1815G+-1+ R 2PC1815G+ AC
Q601 VS2SC3207//-1+ R 2SC3207 AC
Q602 VS2SD2586//1E R 2SD2586 AM
Q603 VS2PC1815G+-1+ R 2PC1815G+ AC
Q751 VS2PC1815G+-1+ R 2PC1815G+ AC
REPLACEMENT PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics are
identified in this manual; electrical components having such features
are identified by "å" in the Replacement Parts Lists.
The use of a substitute replacement part which does not have the same
safety characteristics as the factory recommended replacement parts
shown in this service manual may create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the following
informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
MARK : SPARE PARTS-DELIVERY SECTION.
Ref. No. Part No. ★ Description Code
Q752 VS2PC1815G+-1+ R 2PC1815G+ AC
Q801 VS2PB709AR/-1Y R 2PB709AR AB
Q802 VS2PB709AR/-1Y R 2PB709AR AB
Q804 VS2PD601AR/-1Y R 2PD601AR AB
Q1010 VS2PD601AR/-1Y R 2PD601AR AB
DIODES AND LED’S
D201 RH-EX0676GEZZY R Zener Diode 33V AA
D203 RH-DX0045GEZZY R Diode AA
D301 VHD1SS119//-1Y R 1SS119 AA
D302 VHD1SS119//-1Y R 1SS119 AA
D332 RH-DX0445CEZZ R Diode AL
D503 RH-DX0045GEZZY R Diode AA
D505 RH-DX0441CEZZY R Diode AC
D506 RH-EX0630GEZZY R Zener Diode AA
D507 RH-DX0045GEZZY R Diode AA
D508 RH-DX0131CEZZY R Diode AC
D509 RH-EX0660GEZZY R Zener Diode 22V AB
D531 RH-EX0627GEZZY R Zener Diode 8.2V AA
D532 RH-EX0627GEZZY R Zener Diode 8.2V AA
D601 RH-DX0048GEZZY R Diode AA
D602 VHD1SS244//-1Y R 1SS244 AB
D603 RH-EX0667GEZZY R Zener Diode 27V AA
D604 VHD1SS119//-1Y R 1SS119 AA
D606 RH-DX0131CEZZY R Diode AC
D607 RH-DX0045GEZZY R Diode AA
D608 RH-DX0468CEZZ R Diode AE
D651 RH-EX0627GEZZY R Zener Diode 8.2V AA
D652 RH-EX0253TAZZY R Zener Diode 3.3V AC
D653 RH-DX0045GEZZY R Diode AA
D701 RH-DX0111PEZZ R Diode AG
D705 VHD1SS82///1AY R 1SS82 AC
D706 VHD1SS82///1AY R 1SS82 AC
D707 VHD1SS82///1AY R 1SS82 AC
D751 RH-DX0229CEZZ R Diode AF
D752 RH-DX0131CEZZY R Diode AC
D754 RH-EX0616GEZZY R Zener Diode 5.6V AA
D755 RH-EX0603GEZZY R Zener Diode 3.9V AA
D801 VHD1SS119//-1Y R 1SS119 AA
D802 RH-DX0045GEZZY R Diode AA
D803 RH-DX0045GEZZY R Diode AA
D804 RH-DX0045GEZZY R Diode AA
D805 RH-DX0045GEZZY R Diode AA
D806 RH-DX0045GEZZY R Diode AA
D808 RH-EX0610GEZZY R Zener Diode 4.7V AA
D1001 RH-PX0013PEZZ R PhotoDiode AC
D1003 VHD1SS119//-1Y R 1SS119 AA
D1004 VHD1SS119//-1Y R 1SS119 AA
D1007 RH-EX0263TAZZY R Zener Diode 8.3V AC
D1012 RH-EX0611GEZZY R Zener Diode 5.1V AA
D1018 RH-EX0263TAZZY R Zener Diode 8.3V AC
D1019 RH-EX0263TAZZY R Zener Diode 8.3V AC
D1024 VHD1SS119//-1Y R 1SS119 AA
PACKAGED CIRCUITS
å VA701 RH-VX0073CEZZ R Varistor AD
PR701 RMPTP0001PEZZ R Packaged Circuit AN
X1001 RCRSB0300CEZZ R “Crystal, 12MHz” AF
COILS AND TRANSFORMERS
CF251 RFiLC0318CEZZ R Filter AG
CF252 RFiLC0465CEZZ R Filter AD
L202 VP-DF270K0000Y R Peaking 27µHAB
L203 VP-DF270K0000Y R Peaking 27µHAB
L251 VP-XF100K0000Y R Peaking 10µHAB
L252 VP-XF6R8K0000Y R Peaking 6.8µHAB
å L701 RCiLF0096PEZZ R Coil AF
L751 RCiLP0225CEZZ R Coil AF
L802 VP-DF100K0000Y R Peaking 10µHAB
L803 VP-DF100K0000Y R Peaking 10µHAB
L1030 VP-DF100K0000Y R Peaking 10µHAB
L1050 VP-DF100K0000Y R Peaking 10µHAB
L1051 VP-DF100K0000Y R Peaking 10µHAB
SF201 RFiLC0442CEZZ R Filter AL
å T601 RTRNZ0144PEZZ R Transformer AE
å T602 RTRNF0229PEZZ R H-Volt Transformer AY
