Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
36
21BM2GMK2
R1046 VRN-MD2AL101J R 100 1/10W Metal Film AA
R1048 VRS-CY1JF102JY R 1k 1/16W Metal Oxide AA
R1050 VRN-MD2AL392J R 3.9k 1/10W Metal Film AA
R1051 VRN-MD2AL683J R 68k 1/10W Metal Film AA
R1072 VRN-MD2AL101J R 100 1/10W Metal Film AA
R1073 VRN-MD2AL101J R 100 1/10W Metal Film AA
BALUN
FB601 RBLN-0091GEZZY R Ferrite Bead AB
SWITCHES
å S702 QSW-P0591CEZZ R Switch AQ
S1001 QSW-K0003AJZZ+ R Switch, CH UP AB
S1002 QSW-K0003AJZZ+ R Switch, CH DOWN AB
S1003 QSW-K0003AJZZ+ R Switch, VOL UP AB
S1004 QSW-K0003AJZZ+ R Switch, VOL DOWN AB
S1005 QSW-K0003AJZZ+ R Switch, PICTURE/PRESET AB
MISCELLANEOUS PARTS
å ACC701 QACCZ2008PEZZ R AC Cord AM
å F701 QFS-C3229CEZZ R Fuse, T3.15A/250V AD
å FH701 QFSHD1013CEZZ+ R Fuse Holder AC
å FH702 QFSHD1014CEZZ+ R Fuse Holder AC
J402 QJAKE0210CE04 R Jack, Video AC
J403 QJAKE0210CE09 R Jack, Audio AC
J409 QJAKHA004WJZZ R Jack, AV-1 IN AE
P302 QPLGN0461CEZZ R Plug, 4pin(S) AB
å P601 QPLGN0660CEZZ R Plug, 6pin(F) AC
P602 LHLDW1104PEZZ R Holder (H) AB
P603 QPLGN0341CEZZ R Plug, 3pin(TP651-3) AA
P701 QPLGN0260CEZZ R Plug, 2pin(M) AC
å P702 QPLGN0269GEZZ R Plug, 2pin AB
P1001 LHLDW1105PEZZ R Holder (K) AB
P1002 QPLGN0561CEZZ R Plug, 5pin(BC) AB
RDA302 PRDAR0340PEFW R Heat Sink for IC302 AE
RDA501 PRDAR0118GJFW R Heat Sink for IC501 AD
RDA602 PRDAR0224PEFW R Heat Sink for Q602 AF
RDA701 PRDARA028WJFW R Heat Sink for IC701 AE
RMC1001
RRMCU0222CEZZ R Remote Receiver AL
TP201 QLUGP0102PEZZ R Lug, Test Point AA
LHLDP1066PE00 R Holder AC
DUNTKB509WEA7
PWB-B CRT UNIT
TRANSISTORS
Q870 RH-TX0110BMZZ+ R TX-0110BM AC
Q871 RH-TX0110BMZZ+ R TX-0110BM AC
Q872 RH-TX0110BMZZ+ R TX-0110BM AC
Q883 RH-TX0124BMZZ+ R TX-0124BM AC
Q885 RH-TX0124BMZZ+ R TX-0124BM AC
Q887 RH-TX0124BMZZ+ R TX-0124BM AC
DIODES
D881 VHD1SS244//-1Y R 1SS244 AB
D882 VHD1SS244//-1Y R 1SS244 AB
D883 VHD1SS244//-1Y R 1SS244 AB
D884 VHD1SS119//-1Y R 1SS119 AA
D885 VHD1SS119//-1Y R 1SS119 AA
D886 VHD1SS82///1AY R 1SS82 AC
D887 VHD1SS82///1AY R 1SS82 AC
D888 VHD1SS82///1AY R 1SS82 AC
CAPACITORS
C871 VCCCCY1HH471J R 470p 50V Ceramic AA
C872 VCCCCY1HH471J R 470p 50V Ceramic AA
C873 VCCCCY1HH471J R 470p 50V Ceramic AA
C875 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C876 RC-KZ0150CEZZ R 1000p
3.15kV
Ceramic AB
C878 VCEA0A2EW106M+R 10 250V Electrolytic AD
C880 VCCCCY1HH471J R 470p 50V Ceramic AA
C881 VCKYPA1HB471K+ R 470p 50V Ceramic AA
C882 VCKYPA1HB471K+ R 470p 50V Ceramic AA
C886 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
RESISTORS
R879 VRN-MD2AL471J R 470 1/10W Metal Film AA
R880 VRN-MD2AL471J R 470 1/10W Metal Film AA
R881 VRN-MD2AL471J R 470 1/10W Metal Film AA
R882 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R883 VRD-RM2HD272JY R 2.7k 1/2W Carbon AA
R884 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R885 VRD-RM2HD272JY R 2.7k 1/2W Carbon AA
R886 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R887 VRD-RM2HD272JY R 2.7k 1/2W Carbon AA
R892 VRN-MD2AL102J R 1k 1/10W Metal Film AA
R893 VRN-MD2AL102J R 1k 1/10W Metal Film AA
R894 VRN-MD2AL102J R 1k 1/10W Metal Film AA
R895 VRN-MD2AL471J R 470 1/10W Metal Film AA
R896 VRN-MD2AL471J R 470 1/10W Metal Film AA
R899 VRN-MD2AL471J R 470 1/10W Metal Film AA
MISCELLANEOUS PARTS
å SC883 QSOCV0016PEZZ R Socket AF
P882 LHLDW1105PEZZ R Holder (K) AB
P884 LHLDW1104PEZZ R Holder (H) AB
MISCELLANEOUS PARTS
SP301 VSP1206PB50WA R Speaker AP
SP302 VSP1206PB50WA R Speaker AP
QCNW-A230WJZZ R Connecting Cord AD
QCNW-A720WJZZ R Connecting Cord AD
QCNW-2381PEZZ R Connecting Cord AG
SUPPLIED ACCESSORIES
ACCESSORIES
RRMCG1342PESA R Infrared-R/C AU
TiNS-A414WJZZ R Opearation Manual AK
TMAPCA015WJZZ R Circuit Diagram AC
ACCESSORIE
(NOT REPLACEMENT ITEM)
TCAUA0002PEZZ - Caution Card —
PACKING PARTS
(NOT REPLACEMENT ITEM)
SPAKCA356WJZZ - Packing Case —
SPAKX2756PEZZ - Buffer Material —
SSAKA0031PEZZ - Polyethylene Bag —
SSAKH0016PEZZ - Wrapping Paper —
TLABK0002PEZZ - Serial No. Label —
TLABN0001PEZZ - No. Card —
TLABVA100WJZZ - Bar Code label —
