EEPROM ITEMS OSD DATA LENGTH
INITIAL DATA
FIX/ADJ REMARK
COLOUR OFFSET (PAL) COL-OP 0 ~ 15 8 FIX *3
COLOUR OFFSET (SECAM) COL-OS 0 ~ 15 8 FIX *3
COLOUR OFFSET (NTSC358) COL-O3 0 ~ 15 4 FIX *3
COLOUR OFFSET (NTSC443) COL-O4 0 ~ 15 4 FIX *3
SHARPNESS OFFSET(PAL) SHP-OP 0 ~ 15 8 FIX
SHARPNESS OFFSET(SECAM) SHP-OS 0 ~ 15 4 FIX
SHARPNESS OFFSET(NTSC358) SHP-O3 0 ~ 15 12 FIX
SHARPNESS OFFSET(NTSC443) SHP-O4 0 ~ 15 8 FIX
Bass Mix for AN7396K BM-ON
0(DISABLE)/1(ENABLE)
0 FIX
Bass Mix Effect for AN7396K BM-EFF 0 ~ 3 2 FIX
AGC for AN7396 or AN5891 AGC-ON
0(DISABLE)/1(ENABLE)
1 FIX
AGC Adjust for AN7396K or AN5891 AGC-ADJ 0 ~ 3 3 FIX
NICAM AGC AGC-N
0(DISABLE)/1(ENABLE)
0 FIX
NICAM AGC Gain adjust GAIN-N 0 ~ 31 0 FIX
FM Output Level FM-LV 0 ~ 30 15 (22) FIX
IGR Output Level IGR-LV 0 ~ 30 16 (23) FIX
NICAM Output Level (B/G) BG-NLV 0 ~ 30 13 (20) FIX
NICAM Output Level (I) I-NLV 0 ~ 30 18 (25) FIX
NICAM Output Level (D/K) DK-NLV 0 ~ 30 13 (20) FIX
NICAM lower error limit LOW-ERR 0 ~ 255 35 FIX
NICAM upper error limit UP-ERR 0 ~ 255 70 FIX
IGR Stereo R ch gain adjust(tda9873) IGR-STR 0 ~ 13 6 FIX
Vertical Scan Disable VSD
0 or 1 (not Stored)
0 FIX
Black Stretch BKS
0(DISABLE)/1(ENABLE)
1 FIX
Automatic Volume Leveling AVL
0(DISABLE)/1(ENABLE)
1 FIX
Fast Filter IF-PLL FFI
0(DISABLE)/1(ENABLE)
0 FIX
Enable Vertical Guard (RGB blanking) EVG
0(DISABLE)/1(ENABLE)
1 FIX
EHT Tracking mode [HCO] EHT
0(DISABLE)/1(ENABLE)
1 FIX
Overscan Switch Off OSO
0(DISABLE)/1(ENABLE)
0 FIX
Auto Colour Limit ACL
0(DISABLE)/1(ENABLE)
0 (1) FIX
Forced Colour ON FCO
0(DISABLE)/1(ENABLE)
0 FIX
Sound system M S-M
0(DISABLE)/1(ENABLE)
*1 FIX
Sound system DK S-DK
0(DISABLE)/1(ENABLE)
*1 FIX
Sound system I S-I
0(DISABLE)/1(ENABLE)
*1 FIX
Sound system BG S-BG
0(DISABLE)/1(ENABLE)
*1 FIX
Playback SECAM P-SECAM
0(DISABLE)/1(ENABLE)
*1 FIX
FE (RF) NTSC 3.58 F-N358
0(DISABLE)/1(ENABLE)
*1 FIX
FE (RF) NTSC 4.43 F-N443
0(DISABLE)/1(ENABLE)
*1 FIX
FE (RF) SECAM F-SECAM
0(DISABLE)/1(ENABLE)
*1 FIX
Video Mute at Ident loss VMI
0(DISABLE)/1(ENABLE)
1 FIX
Video Mute at program/source Change VMC
0(DISABLE)/1(ENABLE)
1 FIX
Hotel mode HTL
0(DISABLE)/1(ENABLE)
0 FIX
Reduced FM demodulator Gain (for BTSC sig) BTSC
0(DISABLE)/1(ENABLE)
0 FIX
Number of external AV sources AV
0 FOR 1 AV / 1 FOR 2 AV
1 FIX
FM Window Selection FMWS
0(DISABLE)/1(ENABLE)
0 FIX
Sound Mute bit 0 SM0
0(DISABLE)/1(ENABLE)
1 FIX
Sound Mute bit 1 SM1
0(DISABLE)/1(ENABLE)
0 FIX
Thai language THA
0(DISABLE)/1(ENABLE)
0 FIX
Arabic language ARA
0(DISABLE)/1(ENABLE)
1 FIX
Malay language MAL
0(DISABLE)/1(ENABLE)
1 FIX
Chinese language CHI
0(DISABLE)/1(ENABLE)
1 FIX
French language FRE
0(DISABLE)/1(ENABLE)
1 FIX
Russian language RUS
0(DISABLE)/1(ENABLE)
1 FIX
EEPROM ITEMS OSD DATA LENGTH
INITIAL DATA
FIX/ADJ REMARK
Forced V-SYNC slicing level FSL
0(DISABLE)/1(ENABLE)
0 FIX
Sync of OSD HP2
0 FOR Ph1 / 1 FOR Ph2
0 FIX
IF AGC speed bit0 AGC0
0(DISABLE)/1(ENABLE)
1 FIX
IF AGC speed bit1 AGC1
0(DISABLE)/1(ENABLE)
0 FIX
Phi 1 time constant for FE(RF) FOA-FE
0(DISABLE)/1(ENABLE)
0 FIX
Phi 2 time constant for FE(RF) FOB-FE
0(DISABLE)/1(ENABLE)
0 FIX
Phi 1 time constant for AV FOA-AV
0(DISABLE)/1(ENABLE)
1 FIX
Phi 2 time constant for AV FOB-AV
0(DISABLE)/1(ENABLE)
1 FIX
Teletext TXT
0(DISABLE)/1(ENABLE)
*1 FIX
Teletext Western or Eastern characters TXT-WE
0(DISABLE)/1(ENABLE)
0 FIX
0 (teletext pan-
Teletext pan-European language TXT-EURO
european language) /
0 FIX
depends on delivery
(Arabic/Russian))
IF frequency selection IF-38.0
0 (IF FREQUENCY 38.9) /
0 FIX
1 (IF FREQUENCY 38.0)
0 (FAST TUNING) /
Charge pump CP
1 (MODERATE
0(1) FIX
SPEED TUNING)
AN5890 Sound processor present AN5890
0(DISABLE)/1(ENABLE)
1(0) FIX
AN5891 sound processor present AN5891
0(DISABLE)/1(ENABLE)
0(1) FIX
AN7396 sound processor present AN7396
0(DISABLE)/1(ENABLE)
0 FIX
NICAM decoding enabled NICAM
0(DISABLE)/1(ENABLE)
*1 FIX
IGR decoding enabled IGR
0(DISABLE)/1(ENABLE)
*1 FIX
GAME mode enabled GAME
0(DISABLE)/1(ENABLE)
0 FIX
BIL enabled BIL
0(DISABLE)/1(ENABLE)
0 FIX
LED blink Speed when On-Timer is active LED-F 0(62.5Hz)/1(1Hz) 0 FIX
PWM volume table for MONO MSA
0(original table)/1(new table)
0 FIX
Output Vertical Guard NDF
0(lgnore)/1(accopl)
0(1) FIX
OSD "IGR" or "A2" display A2
0(display IGR)/1(display A2)
*1 FIX
EEPROM ITEMS OSD DATA LENGTH
FIX/ADJ
*(1) *(2) *(3)
Sound system M S-M
0(DISABLE)/1(ENABLE)
0 (1) 0 (1) 0 (1)
Sound system DK S-DK
0(DISABLE)/1(ENABLE)
111
Sound system I S-I
0(DISABLE)/1(ENABLE)
111
Sound system BG S-BG
0(DISABLE)/1(ENABLE)
111
Playback SECAM P-SECAM
0(DISABLE)/1(ENABLE)
111
FE (RF) NTSC 3.58 F-N358
0(DISABLE)/1(ENABLE)
0 (1) 0 (1) 0 (1)
FE (RF) NTSC 4.43 F-N443
0(DISABLE)/1(ENABLE)
111
FE (RF) SECAM F-SECAM
0(DISABLE)/1(ENABLE)
111
Teletext TXT
0(DISABLE)/1(ENABLE)
0 (1) 0 0
NICAM decoding enabled NICAM
0(DISABLE)/1(ENABLE)
0 (1) 0 (1) 0
IGR decoding enabled IGR
0(DISABLE)/1(ENABLE)
0 (1) 0 (1) 0
OSD "IGR" or "A2" display A2
0(display IGR)/1(display A2)
0 (1) 0 (1) 0
NOTE :
Please set the EEPROM initial data according to the value in parenthesis ( ) before adjustment.
Fixed data, please do not change without specific instruction.
*1: Please refer the following table.
MODEL : *(1) : 21C-FX5 *(2) :21C-FX8 *(3) : 21C-FX1(C)/(G)
*2 : DRI-RC = 27, DRI-GC = (DRI-GS)-5 for 21C-FX1(G)
DRI-RC = 25, DRI-GC = (DRI-GS)-7 for the other models
*3 :After Adjust SUB-COL then change:
1.COL-0P from 8 to 14
2.COL-0S from 8 to 14
3.COL-03 from 4 to 10
4.COL-04 from 4 to 10
