52
21C-FX1(C)/(G)
21C-FX5/FX8
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
are identified in this manual; electrical components having such
features are identified by "å" in the Replacement Parts Lists.
The use of a substitute replacement part which does not have the
same safety characteristics as the factory recommended replace-
ment parts shown in this service manual may create shock, fire or
other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
MARK : SPARE PARTS-DELIVERY SECTION.
Ref. No. Part No. Description Code
IC751 VHiTA48M033-1 R TA48M033F AH
IC752 VHiKA7805AP-1 R KIA7805API AE
IC753 VHiSE120N//-1 R SE120N AG
IC801 RH-iX3410CEN5 R I.C. (21C-FX1(C)/(G), FX8) BD
IC801 RH-iX3412CEN5 R I.C. (21C-FX5) BK
IC1003 VHiM24C08W/-1 R M24C08-WBN6 AH
TRANSISTORS
Q201 VS2SC2735//1E R 2SC2735 AC
Q203 VS2PD601AR/-1 R 2PD601AR AB
Q204 VS2PD601AR/-1 R 2PD601AR AB
Q251 VS2PD601AR/-1 R 2PD601AR AB
Q303 VS2PD601AR/-1 R 2PD601AR AB
Q304 VS2PD601AR/-1 R 2PD601AR AB
Q305 VS2PD601AR/-1 R 2PD601AR AB
Q306 VS2PD601AR/-1 R 2PD601AR AB
Q307 VS2PB709AR/-1 R 2PB709AR AB
Q501 VS2PD601AR/-1 R 2PD601AR AB
Q502 VS2PD601AR/-1 R 2PD601AR AB
Q601 VS2SC2482//-1 R 2SC2482 AD
å Q602 VS2SD2634++-G R 2SD2634++ AM
å Q603 VS2PD601AR/-1 R 2PD601AR AB
Q751 VS2SA1015Y/1E R 2SA1015Y AC
Q752 VS2SC1815GW-1 R 2SC1815GW AB
Q753 VS2SC1815GW-1 R 2SC1815GW AB
Q754 VS2PD601AR/-1 R 2PD601AR AB
Q755 VS2PD601AR/-1 R 2PD601AR AB
Q801 VS2PB709AR/-1 R 2PB709AR AB
Q802 VS2PB709AR/-1 R 2PB709AR AB
Q1004 VS2PD601AR/-1 R 2PD601AR AB
Q1005 VS2PD601AR/-1 R 2PD601AR AB
Q1006 VS2PD601AR/-1 R 2PD601AR AB
DIODES
D201 RH-EX0676GEZZ R Zener Diode AA
D252 VHD1SS356//-1 R 1SS356 AB
D301 RH-DX0048GEZZ R Diode AA
D302 RH-EX0615GEZZ R Zener Diode AA
D303 RH-EX0615GEZZ R Zener Diode AA
D304 RH-EX0631GEZZ R Zener Diode AA
D305 RH-EX0631GEZZ R Zener Diode AA
D306 RH-DX0445CEZZ R Diode AL
D309 RH-DX0048GEZZ R Diode AA
D312 RH-DX0048GEZZ R Diode AA
D313 RH-DX0048GEZZ R Diode AA
D314 RH-DX0048GEZZ R Diode AA
D315 RH-DX0048GEZZ R Diode AA
D316 RH-DX0048GEZZ R Diode AA
D320 RH-DX0048GEZZ R Diode AA
D402 RH-EX0631GEZZ R Zener Diode AA
D403 RH-EX0867CEZZ R Zener Diode AC
D404 RH-EX0867CEZZ R Zener Diode AC
D502 RH-EX0654CEZZ R Zener Diode AD
D504 RH-DX0048GEZZ R Diode AA
D505 RH-DX0295CEZZ R Diode AD
D506 RH-DX0295CEZZ R Diode AD
D509 RH-EX0640GEZZ R Zener Diode AA
D512 RH-EX0603GEZZ R Zener Diode AA
D513 RH-DX0048GEZZ R Diode AA
D602 RH-DX0048GEZZ R Diode AA
D603 RH-DX0062CEZZ R Diode AD
D604 RH-EX0627GEZZ R Zener Diode AA
D606 RH-DX0048GEZZ R Diode AA
å D607 RH-EX0658GEZZ R Zener Diode AA
D608 RH-EX0604GEZZ R Zener Diode AB
D609 RH-DX0048GEZZ R Diode AA
å D610 RH-EX0662GEZZ R Zener Diode AB
D611 RH-DX0302CEZZ R Diode AC
D612 RH-DX0302CEZZ R Diode AC
D613 RH-DX0048GEZZ R Diode AA
D614 RH-DX0048GEZZ R Diode AA
D615 RH-DX0048GEZZ R Diode AA
D701 RH-DX0476CEZZ R Diode AG
D702 VHD1SS82///1A R 1SS82 AC
D705 RH-DX0492CEZZ R Diode AE
D706 VHD1SS82///1A R 1SS82 AC
å V801 VB51QDJ279X2E R Picture Tube CG
å L708 RCiLG0069PEZZ R Degaussing Coil AR
RCiLHA010WJZZ R Deflection Yoke BF
PMAGF3046CEZZ R Magnet AF
QEARC2122PEZZ R Grounding Strap AF
LHLDW0003PEKZ R ADG Holder, x4 AB
MSPRT0001PEFJ R Spring, Grounding Strap AC
PSPAG0003PEZZ R Wedge, x3 AD
PICTURE TUBE
PRINTED WIRING BOARD ASSEMBLY
(NOT REPLACEMENT ITEM)
PWB-A DUNTKA200FMW3 - Main Unit (21C-FX1(C)) —
PWB-A DUNTKA200FMW4 - Main Unit (21C-FX1(G)) —
PWB-A DUNTKA200FMW1 - Main Unit (21C-FX5) —
PWB-A DUNTKA200FMW5 - Main Unit (21C-FX8) —
PWB-B DUNTK9990WEC2 - CRT Unit (21C-FX1(C)) —
PWB-B DUNTK9990WEC3 - CRT Unit (21C-FX1(G)) —
PWB-B DUNTK9990WEB9 - CRT Unit (21C-FX5) —
PWB-B DUNTK9990WEC4 - CRT Unit (21C-FX8) —
PWB-C DUNTK9668FMX1 - NICAM Unit (21C-FX5) —
PWB-C DUNTK9668FMX4 - NICAM Unit (21C-FX8) —
DUNTKA200FMW3/W4/W1/W5
MAIN UNIT
TUNER AND ASSEMBLY
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT INDEPENDENTLY.
å TU201 VTUVTST5HD970 R VHF Tuner AY
INTEGRATED CIRCUITS
IC302 VHiAN5277//-1 R AN5277 AN
IC305 VHiAN5891K+-1 R AN5891K AQ
IC401 VHiM52797SP-1 R M52797SP AP
IC501 VHiLA7841//-1 R LA7841 AM
IC605 VHiKA7808AP-1 R KIA7808API AE
å IC701 VHiSTRF6654-1 R STR-F6654 AX
