Ref. No. Part No. Description CodeRef. No. Part No. Description Code
53
21C-FX1(C)/(G)
21C-FX5/FX8
CAPACITORS
C200 VCEA0A1CW476M R 47 16V Electrolytic AB
C203 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C204 VCEA0A1CW108M R 1000 16V Electrolytic AD
(21C-FX5/FX8)
C204 VCEA0A1CW477M R 470 16V Electrolytic AC
(21C-FX1(C)/(G))
C205 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C206 VCEA0A1HW106M R 10 50V Electrolytic AB
C207 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C208 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C209 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C210 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C211 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C212 VCEA0A1CW106M R 10 16V Electrolytic AB
C213 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C214 VCEA0A1CW226M R 22 16V Electrolytic AB
C216 VCKYCY1HB821K R 820p 50V Ceramic AA
C217 VCKYCY1HB472K R 4700p 50V Ceramic AA
C218 VCKYCY1HF103Z R 0.01 50V Ceramic AA
(21C-FX5/FX8)
C306 VCEA0A1EW107M R 100 25V Electrolytic AC
C307 VCEA0A1HW105M R 1 50V Electrolytic AB
C308 VCEA0A1EW108M R 1000 25V Electrolytic AD
C309 VCEA0A1HW225M R 2.2 50V Electrolytic AB
C310 VCEA0A1CW336M R 33 16V Electrolytic AB
C311 VCEA0A1EW108M R 1000 25V Electrolytic AD
C312 VCQYTA1HM102J R 1000p 50V Mylar AA
(21C-FX1(G)/FX8)
C313 VCQYTA1HM102J R 1000p 50V Mylar AA
(21C-FX1(G)/FX8)
C314 VCEA0A1VW108M R 1000 35V Electrolytic AD
C315 VCKYPA1HF103Z R 0.01 50V Ceramic AA
C316 VCEA0A1CW106M R 10 16V Electrolytic AB
C317 VCEA0A1CW106M R 10 16V Electrolytic AB
C319 VCEA0A1HW105M R 1 50V Electrolytic AB
C322 VCEA0A1CW106M R 10 16V Electrolytic AB
C323 VCEA0A1CW106M R 10 16V Electrolytic AB
C327 VCQYTA1HM103J R 0.01 50V Mylar AA
C328 VCEA0A1HW104M R 0.1 50V Electrolytic AB
C329 VCEA0A1CW106M R 10 16V Electrolytic AB
C330 VCEA0A1CW106M R 10 16V Electrolytic AB
C331 VCEA0A1HW105M R 1 50V Electrolytic AB
C332 VCEA0A1VW108M R 1000 35V Electrolytic AD
C333 VCKYPA2HB102K R 1000p 500V Ceramic AA
C337 VCQYTA1HM392J R 3900p 50V Mylar AA
C338 VCQYTA1HM103J R 0.01 50V Mylar AA
C339 VCQYTA1HM333J R 0.033 50V Mylar AA
C340 VCEA0A1CW106M R 10 16V Electrolytic AB
C341 VCEA0A1CW106M R 10 16V Electrolytic AB
C342 VCEA0A1CW106M R 10 16V Electrolytic AB
C343 VCQYTA1HM103J R 0.01 50V Mylar AA
C344 VCEA0A1HW104M R 0.1 50V Electrolytic AB
C346 VCEA0A1CW106M R 10 16V Electrolytic AB
C347 VCEA0A1CW106M R 10 16V Electrolytic AB
C348 VCKYPA1HF103Z R 0.01 50V Ceramic AA
C349 VCEA0A1CW107M R 100 16V Electrolytic AC
C350 VCEA0A1CW106M R 10 16V Electrolytic AB
C352 VCQYTA1HM103J R 0.01 50V Mylar AA
C355 VCEA0A1CW106M R 10 16V Electrolytic AB
C356 VCKYCY1HB682K R 6800p 50V Ceramic AA
C357 VCKYCY1HB182K R 1800p 50V Ceramic AA
C359 VCEA0A1CW106M R 10 16V Electrolytic AB
C361 VCE9GA1CW106M R 10 16V Elect. (N.P) AB
(21C-FX1(C)/(G))
C361 VCEA0A1CW106M R 10 16V Electrolytic AB
(21C-FX5/FX8)
C362 VCEA0A1CW106M R 10 16V Electrolytic AB
(21C-FX5/FX8)
C363 VCEA0A1CW106M R 10 16V Electrolytic AB
C364 VCEA0A1CW106M R 10 16V Electrolytic AB
C365 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C367 VCCCCY1HH221J R 220p 50V Ceramic AA
C368 VCCCCY1HH221J R 220p 50V Ceramic AA
C369 VCEA0A1HW105M R 1 50V Electrolytic AB
C370 VCEA0A1HW105M R 1 50V Electrolytic AB
D707 VHD1SS82///1A R 1SS82 AC
D708 RH-DX0400CEZZ R Diode AC
D709 RH-DX0164CEZZ R Diode AC
D710 RH-EX0601GEZZ R Zener Diode AA
D711 VHD1SS82///1A R 1SS82 AC
D712 VHD1SS82///1A R 1SS82 AC
D713 RH-EX0621GEZZ R Zener Diode AB
D714 RH-DX0055TAZZ R Diode AD
D715 RH-DX0055TAZZ R Diode AD
D718 RH-EX0649GEZZ R Zener Diode AB
D719 RH-EX0649GEZZ R Zener Diode AB
D752 RH-DX0048GEZZ R Diode AA
D753 RH-DX0471CEZZ R Diode AE
D756 RH-DX0471CEZZ R Diode AE
D757 RH-DX0302CEZZ R Diode AC
D758 RH-DX0461CEZZ R Diode AG
D759 RH-EX0716GEZZ R Zener Diode AB
D760 RH-DX0048GEZZ R Diode AA
D761 RH-DX0048GEZZ R Diode AA
D762 VHDTF321S//-1 R TF321S AH
D763 RH-DX0471CEZZ R Diode AE
D764 RH-DX0471CEZZ R Diode AE
D765 RH-DX0048GEZZ R Diode AA
D802 RH-DX0048GEZZ R Diode AA
D803 RH-DX0048GEZZ R Diode AA
D804 RH-DX0048GEZZ R Diode AA
D805 RH-DX0048GEZZ R Diode AA
D806 RH-DX0048GEZZ R Diode AA
D808 RH-EX0257TAZZY R Zener Diode AB
D1001 RH-PX0423CEZZ R PhotoDiode AD
D1004 RH-DX0048GEZZ R Diode AA
D1007 RH-EX0867CEZZ R Zener Diode AC
D1008 RH-EX0867CEZZ R Zener Diode AC
D1009 RH-EX0867CEZZ R Zener Diode AC
D1010 RH-EX0867CEZZ R Zener Diode AC
D1011 RH-DX0048GEZZ R Diode AA
D1017 RH-EX0612GEZZ R Zener Diode AA
å IC702 RH-FX0008GEZZ R PC123FY8 AE
PACKAGED CIRCUITS
å VA700 RH-VX0073CEZZ R Varistor AD
PR701 RMPTP0001PEZZ R Packaged Circuit AN
X1001 RCRSB0300CEZZ R Crystal, 12MHz AF
COILS
L202 VP-DF270K0000 R Peaking 27µHAB
L203 VP-DF270K0000 R Peaking 27µHAB
L204 VP-XF1R2M0000 R Peaking 1.2µHAB
L205 VP-DF1R0M0000 R Peaking 1µHAB
L206 VP-DF1R0M0000 R Peaking 1µHAB
L208 VP-XF100K0000 R Peaking 10µHAB
L209 VP-XF6R8K0000 R Peaking 6.8µHAB
L210 VP-XF120K0000 R Peaking 12µHAB
L211 VP-CF270K0000 R Peaking 27µH (21C-FX5/FX8)AB
L401 VP-DF1R0M0000 R Peaking 1µHAB
L602 RCiLZ1055CEZZ R Coil AK
L603 RCiLP0225CEZZ R Coil AF
L604 RCiLP0223CEZZ R Coil AE
å L702 RCiLF0019PEZZ R Coil AN
L802 VP-DF100K0000 R Peaking 10µHAB
L803 VP-DF100K0000 R Peaking 10µHAB
L1001 VP-DF100K0000 R Peaking 10µHAB
L1002 VP-DF100K0000 R Peaking 10µHAB
L1003 VP-DF100K0000 R Peaking 10µHAB
FILTERS
CF201 RFiLC0024CEZZ R Filter AE
CF202 RFiLC0318CEZZ R Filter AG
CF203 RFiLC0446CEZZ R Filter AD
SF201 RFiLC0037PEZZ R Filter AP
TRANSFORMERS
T601 RTRNZ0731CEZZ R Transformer AG
å T602 RTRNF0202PEZZ R H-Volt Transformer BA
å T701 RTRNZ0193PEZZ R Transformer AQ
