Ref. No. Part No. Description Code
Ref. No. Part No. Description Code
54
21C-FX1(C)/(G)
21C-FX5/FX8
C708 RC-KZ0029CEZZ R 0.01 250V Ceramic AC
C709 VCQYTA1HM471J R 470p 50V Mylar AB
C711 RC-KZ0039CEZZ R 680p 2kV Ceramic AB
C712 VCQYTA1HM102J R 1000p 50V Mylar AA
C713 RC-KZ007JCEZZ R 0.01 250V Ceramic AC
C714 VCKYPH3DB561K R 560p 2000V Ceramic AC
C715 VCKYPA2HB102K R 1000p 500V Ceramic AA
C716 VCEA0A1EW226M R 22 25V Electrolytic AB
C717 VCQYTA1HM272J R 2700p 50V Mylar AA
C718 VCEA0A2AW475M R 4.7 100V Electrolytic AB
å C721 RC-KZ0102GEZZ R 680p 4kV Ceramic AE
C751 VCEA0A1EW476M R 47 25V Electrolytic AB
C752 VCEA0A0JW227M R 220 6.3V Electrolytic AB
C753 VCKYPA2HB102K R 1000p 500V Ceramic AA
C754 VCEA0A1CW476M R 47 16V Electrolytic AB
C755 VCEA0A1CW108M R 1000 16V Electrolytic AD
C756 VCEAGH1CW338M R 3300 16V Electrolytic AE
C758 VCKYPA2HB221K R 220p 500V Ceramic AA
C759 VCKYPA1HB102K R 1000p 50V Ceramic AA
C760 RC-KZ0039CEZZ R 680p 2kV Ceramic AB
C761 RC-EZ0006PEZZ R 220 160V Electrolytic AK
C762 VCQYTA1HM473J R 0.047 50V Mylar AA
C801 VCEA0A1HW105M R 1 50V Electrolytic AB
C802 VCEA0A1CW337M R 330 16V Electrolytic AC
C803 VCEA0A1CW107M R 100 16V Electrolytic AC
C804 VCKYCY1HB222K R 2200p 50V Ceramic AA
C805 VCKYCY1HB102K R 1000p 50V Ceramic AA
C806 VCKYCY1HB102K R 1000p 50V Ceramic AA
C807 VCKYCY1HB102K R 1000p 50V Ceramic AA
C808 VCEA0A1CW107M R 100 16V Electrolytic AC
C809 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C810 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C811 VCEA0A1CW107M R 100 16V Electrolytic AC
C812 VCFYFA1HA224J R 0.22 50V M.Polypro AB
C813 VCFYFA1HA224J R 0.22 50V M.Polypro AB
C814 VCKYCY1HB471K R 470p 50V Ceramic AA
C815 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C816 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C818 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C1001 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1003 VCEA0A1CW106M R 10 16V Electrolytic AB
C1004 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C1005 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C1006 VCEA0A1CW106M R 10 16V Electrolytic AB
C1008 VCCCCY1HH330J R 33p 50V Ceramic AA
C1009 VCCCCY1HH330J R 33p 50V Ceramic AA
C1010 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1011 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C1012 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C1013 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1014 VCEA0A1CW106M R 10 16V Electrolytic AB
C1016 VCQYTA1HM104J R 0.1 50V Mylar AA
C1017 VCFYFA1HA474J R 0.47 50V M.Polypro AC
C1020 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C1021 VCEA0A0JW227M R 220 6.3V Electrolytic AB
C1025 VCEA0A0JW107M R 100 6.3V Electrolytic AB
RESISTORS
RJ1 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ2 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ3 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ5 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ6 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ7 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ8 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ9 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ10 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ12 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ22 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ24 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ25 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ26 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ31 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ33 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ34 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ44 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
C371 VCEA0A1CW476M R 47 16V Electrolytic AB
C372 VCEA0A1CW106M R 10 16V Electrolytic AB
C375 VCEA0A1HW225M R 2.2 50V Electrolytic AB
C376 VCEA0A1CW106M R 10 16V Electrolytic AB
C380 VCQYTA1HM333J R 0.033 50V Mylar AA
C381 VCEA0A1HW105M R 1 50V Electrolytic AB
C382 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C383 VCEA0A1CW227M R 220 16V Electrolytic AC
C384 VCEA0A1HW105M R 1 50V Electrolytic AB
C386 VCFYFA1HA394J R 0.39 50V M.Polypro AC
C387 VCFYFA1HA394J R 0.39 50V M.Polypro AC
C390 VCKYCY1HB102K R 1000p 50V Ceramic AA
(21C-FX5/FX8)
C391 VCKYCY1HB102K R 1000p 50V Ceramic AA
(21C-FX5/FX8)
C401 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C402 VCEA0A1CW106M R 10 16V Electrolytic AB
C403 VCEA0A1CW106M R 10 16V Electrolytic AB
C404 VCEA0A1CW106M R 10 16V Electrolytic AB
C405 VCEA0A1CW107M R 100 16V Electrolytic AC
C406 VCEA0A1CW477M R 470 16V Electrolytic AC
C407 VCEA0A1CW106M R 10 16V Electrolytic AB
C408 VCEA0A1CW106M R 10 16V Electrolytic AB
C409 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C410 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C411 VCKYCY1HB102K R 1000p 50V Ceramic AA
C412 VCKYPA2HB102K R 1000p 500V Ceramic AA
C501 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C502 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C503 VCQYTA2AA563K R 0.056 100V Mylar AB
C504 RC-FZ0272CEZZ R 0.39 100V Mylar AD
C505 VCEA0A1HW107M R 100 50V Electrolytic AB
C506 VCEA0A1EW108M R 1000 25V Electrolytic AD
C507 VCEA0A1EW108M R 1000 25V Electrolytic AD
C508 VCKYPA1HB102K R 1000p 50V Ceramic AA
C509 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C512 VCKYCY1HB102K R 1000p 50V Ceramic AA
C513 VCKYCY1HB102K R 1000p 50V Ceramic AA
C515 VCKYPA2HB102K R 1000p 500V Ceramic AA
C516 VCEA0A1EW108M R 1000 25V Electrolytic AD
C517 VCQYTA1HM104J R 0.1 50V Mylar AA
C518 VCKYCY1CB333K R 0.033 16V Ceramic AA
C601 VCEA0A2EW106M R 10 250V Electrolytic AD
C602 VCQYTA1HM104J R 0.1 50V Mylar AA
å C603 VCEA0A1HW105M R 1 50V Electrolytic AB
å C604 VCEA0A1HW105M R 1 50V Electrolytic AB
å C605 VCKYPA1HF103Z R 0.01 50V Ceramic AA
C606 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C607 VCEA0A1CW477M R 470 16V Electrolytic AC
C608 VCEA0A1EW476M R 47 25V Electrolytic AB
C609 VCEA0A1EW108M R 1000 25V Electrolytic AD
C611 VCKYPA2HB561K R 560p 500V Ceramic AA
C612 RC-EZ0724CEZZ R 100 160V Electrolytic AG
C613 RC-FZ0332CEZZ R 0.3 250V Mylar AF
C615 VCFPVC2DB224J R 0.22 200V M.Polypro AE
å C616 VCFPVC3ZA912H R 9100p 1.8kV M.Polypro AE
C617 VCKYPA2HB102K R 1000p 500V Ceramic AA
C618 VCKYPA2HB102K R 1000p 500V Ceramic AA
C619 VCEA0A1EW108M R 1000 25V Electrolytic AD
C620 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C622 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C623 VCQYTA1HM222J R 2200p 50V Mylar AA
C624 VCQYTA1HM472J R 4700p 50V Mylar AB
C625 VCEA0A1HW105M R 1 50V Electrolytic AB
C626 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C627 VCEA0A1HW106M R 10 50V Electrolytic AB
C629 VCKYPA1HB472K R 4700p 50V Ceramic AA
C630 VCKYPH3DB561K R 560p 2000V Ceramic AC
C650 VCEA0A1HW224M R 0.22 50V Electrolytic AB
C700 VCFYAA2AA103J R 0.01 100V M.Polypro AF
å C701 RC-FZ031SCEZZ R 0.1 AC250V Mylar AD
C702 RC-KZ0029CEZZ R 0.01 250V Ceramic AC
C703 RC-KZ0029CEZZ R 0.01 250V Ceramic AC
C704 VCKYPA2HB102K R 1000p 500V Ceramic AA
C705 VCKYPA2HB102K R 1000p 500V Ceramic AA
C707 RC-EZ0804CEZZ R 220 400V Electrolytic AU
