Sharp 21C-FX1C User Manual

Ref. No. Part No. Description CodeRef. No. Part No. Description Code
55
21C-FX1(C)/(G)
21C-FX5/FX8
R339 VRS-CY1JF564J R 560k 1/16W Metal Oxide AA
R340 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R341 VRD-RA2BE102J R 1k 1/8W Carbon AA
R342 VRS-CY1JF564J R 560k 1/16W Metal Oxide AA
R343 VRS-CY1JF104J R 100k 1/16W Metal Oxide AA
R344 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R345 VRS-CY1JF104J R 100k 1/16W Metal Oxide AA
R351 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R354 VRS-CY1JF471J R 470 1/16W Metal Oxide AA
R355 VRS-CY1JF471J R 470 1/16W Metal Oxide AA
R356 VRD-RA2BE103J R 10k 1/8W Carbon AA
R358 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R359 VRD-RA2BE101J R 100 1/8W Carbon AB
R360 VRD-RA2BE101J R 100 1/8W Carbon AB
R362 VRS-CY1JF123J R 12k 1/16W Metal Oxide AA
R363 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R367 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R368 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R369 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R370 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R379 VRN-VV3LB1R5J R 1.5 3.0W Metal Film AC
R388 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R389 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R391 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R396 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(21C-FX1(C)/(G))
R397 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R398 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(21C-FX1(C)/(G))
R401 VRD-RA2BE103J R 10k 1/8W Carbon AA
R403 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R404 VRD-RA2EE750J R 75 1/4W Carbon AA
R405 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R406 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R411 VRD-RA2EE750J R 75 1/4W Carbon AA
R412 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R501 VRS-CY1JF181J R 180 1/16W Metal Oxide AA
R502 VRS-CY1JF181J R 180 1/16W Metal Oxide AA
R504 VRD-RA2BE1R0J R 1 1/8W Carbon AA
R506 VRD-RA2BE102J R 1k 1/8W Carbon AA
R508 VRS-VV3DB331J R 330 2W Metal Oxide AA
R510 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R511 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R513 VRD-RA2BE393J R 39k 1/8W Carbon AA
R515 VRD-RA2BE153J R 15k 1/8W Carbon AA
R516 VRD-RA2BE153J R 15k 1/8W Carbon AA
R517 VRD-RA2BE362GY R 3.6k 1/8W Carbon AA
R518 VRN-VV3DB2R7J R 2.7 2W Metal Film AB
R519 VRD-RM2HD102J R 1k 1/2W Carbon AA
R520 VRD-RM2HD100J R 10 1/2W Carbon AA
R521 VRS-CY1JF104J R 100k 1/16W Metal Oxide AA
R522 VRS-CY1JF392J R 3.9k 1/16W Metal Oxide AA
R560 VRD-RA2BE123J R 12k 1/8W Carbon AA
R561 VRD-RA2BE103J R 10k 1/8W Carbon AA
å R601 RR-XZ0084CEZZ R 1 1/4W Fuse Resistor AB
R602 VRN-RV3ABR82J R 0.82 1W Metal Film AB
R603 VRD-RM2HD102J R 1k 1/2W Carbon AA
R604 VRD-RA2BE393J R 39k 1/8W Carbon AA
R605 VRD-RM2HD101J R 100 1/2W Carbon AA
R606 VRD-RA2BE333J R 33k 1/8W Carbon AA
å R607 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
å R608 VRS-CY1JF123J R 12k 1/16W Metal Oxide AA
R609 VRD-RA2BE153G R 15k 1/8W 2% Carbon AA
R610 VRD-RA2BE822G R 8.2k 1/8W 2% Carbon AA
R611 VRD-RA2EE563G R 56k 1/4W 2% Carbon AA
R612 VRD-RA2BE103J R 10k 1/8W Carbon AA
R613 VRD-RA2BE103J R 10k 1/8W Carbon AA
R614 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R615 VRS-KT3LB272J R 2.7k 3.0W Metal Oxide AC
R616 VRD-RA2BE102J R 1k 1/8W Carbon AA
R617 VRS-VV3AB562J R 5.6k 1W Metal Oxide AA
R618 VRS-KA3NG3R3K R 3.3 7.0W Metal Oxide AD
R619 VRD-RM2HD682J R 6.8k 1/2W Carbon AA
R620 VRD-RM2HD150J R 15 1/2W Carbon AA
R622 VRS-KT3LB122J R 1.2k 3.0W Metal Oxide AC
R624 VRD-RA2BE101J R 100 1/8W Carbon AB
RJ46 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ47 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ55 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ57 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ60 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ64 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ65 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R201 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R202 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R203 VRD-RM2HD472J R 4.7k 1/2W Carbon AA
R204 VRD-RM2HD472J R 4.7k 1/2W Carbon AA
R205 VRD-RA2BE680J R 68 1/8W Carbon AA
R206 VRS-CY1JF122J R 1.2k 1/16W Metal Oxide AA
R207 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R208 VRS-CY1JF271J R 270 1/16W Metal Oxide AA
R209 VRD-RA2BE392J R 3.9k 1/8W Carbon AA
R210 VRD-RM2HD472J R 4.7k 1/2W Carbon AA
R211 VRD-RA2BE682J R 6.8k 1/8W Carbon AA
R212 VRS-CY1JF392J R 3.9k 1/16W Metal Oxide AA
R215 VRS-CY1JF681J R 680 1/16W Metal Oxide AA
(21C-FX5/FX8)
R217 VRD-RA2BE392J R 3.9k 1/8W Carbon AA
R218 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R219 VRS-CY1JF391J R 390 1/16W Metal Oxide AA
R220 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R221 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R222 VRS-CY1JF681J R 680 1/16W Metal Oxide AA
R223 VRD-RA2BE101J R 100 1/8W Carbon AB
R224 VRS-CY1JF750J R 75 1/16W Metal Oxide AA
R225 VRD-RA2EE680J R 68 1/4W Carbon AA
R229 VRS-CY1JF680J R 68 1/16W Metal Oxide AA
R230 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R231 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R232 VRD-RA2BE680J R 68 1/8W Carbon AA
R233 VRD-RA2BE181J R 180 1/8W Carbon AA
R234 VRD-RA2BE331J R 330 1/8W Carbon AA
R235 VRS-CY1JF561J R 560 1/16W Metal Oxide AA
R236 VRS-CY1JF681J R 680 1/16W Metal Oxide AA
R237 VRS-CY1JF272J R 2.7k 1/16W Metal Oxide AA
R238 VRS-CY1JF821J R 820 1/16W Metal Oxide AA
R239 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R240 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R251 VRS-CY1JF472J R 4.7k 1/16W Metal Oxide AA
R252 VRS-CY1JF472J R 4.7k 1/16W Metal Oxide AA
R253 VRS-CY1JF472J R 4.7k 1/16W Metal Oxide AA
R291 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R300 VRD-RM2HD680J R 68 1/2W Carbon AA
R301 VRD-RM2HD680J R 68 1/2W Carbon AA
R306 VRD-RA2BE153J R 15k 1/8W Carbon AA
R307 VRD-RA2BE822J R 8.2k 1/8W Carbon AA
R308 VRD-RA2BE562J R 5.6k 1/8W Carbon AA
R309 VRS-CY1JF822J R 8.2k 1/16W Metal Oxide AA
R310 VRD-RA2BE102J R 1k 1/8W Carbon AA
R311 VRD-RA2BE562J R 5.6k 1/8W Carbon AA
R312 VRD-RA2BE101J R 100 1/8W Carbon AB
R313 VRD-RA2BE101J R 100 1/8W Carbon AB
R314 VRS-CY1JF224J R 220k 1/16W Metal Oxide AA
R315 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R316 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R318 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R319 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R322 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R323 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R324 VRD-RA2BE103J R 10k 1/8W Carbon AA
R325 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R326 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R327 VRS-CY1JF564J R 560k 1/16W Metal Oxide AA
R328 VRS-CY1JF564J R 560k 1/16W Metal Oxide AA
R329 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R332 VRS-CY1JF561J R 560 1/16W Metal Oxide AA
R333 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R334 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R335 VRS-CY1JF561J R 560 1/16W Metal Oxide AA
R336 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R337 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R338 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
