Sharp 21F-PT220 User Manual

21F-PD250 / 21F-PT220 / 21F-PA18 / 21F-PA18(B)
3 – 7
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD
DATA LENGTH
INITIAL DATA FIX/ADJ/AUTO REMARK
C.CLIP-LVL CLIP LEVEL CONTRAST
CONTROL OF RGB INPUT
F01
0(20H)/1(40H)
0*FIX
BUS SETUP
RGB-CLIP CLIPPING OF RGB CONTRAST
CONTROL
F02
0 (enable)/
1
(
disable
)
0FIX
BS BLACK STRETCH
F03
0 (enable)/
1
(
disable
)
0FIX
ABCL ABCL PROCESSING (ACL
PROCESSING)
F04
0 (ACL)/ 1(ABCL)
0FIX
ABCL-GAIN ABCL PROCESSING GAIN
F05
0
(
Lo
)
/1
(
Hi
)
0FIX
S-OUT-LVL-NOT USED
AUDIO OUTPUT GAIN CONTROL
F06
0…127
95 FIX
NO FUNCTION
VIF-G P-IF DETECTION GAIN OUTPUT
F07
0…7
4*FIX
BUS SETUP
SHPG SHARPNESS GAIN
F08
0 (soft)/ 1(sharp)
0FIX
SHPG-P SHARPNESS GAIN PAL
F09
0 (soft)/ 1(sharp)
0FIX
SHPG-S SHARPNESS GAIN SECAM
F10
0 (soft)/ 1(sharp)
0FIX
SHPG-N4 SHARPNESS GAIN N443
F11
0 (soft)/ 1(sharp)
0FIX
SHPG-N3 SHARPNESS GAIN N358
F12
0 (soft)/ 1(sharp)
1FIX
YDL Y SIGNAL DELAY
F13
0…7
5FIX
YDL-P Y SIGNAL DELAY PAL
F14
0…7
5FIX
YDL-S Y SIGNAL DELAY SECAM
F15
0…7
7FIX
YDL-N4 Y SIGNAL DELAY N443
F16
0…7
5FIX
YDL-N3 Y SIGNAL DELAY N358
F17
0…7
5FIX
YDL-AV Y SIGNAL DELAY AV
F18
0…7
6FIX
YDL-AV-P Y SIGNAL DELAY PAL (AV)
F19
0…7
6FIX
YDL-AV-S Y SIGNAL DELAY SECAM (AV)
F20
0…7
7FIX
YDL-AV-N4 Y SIGNAL DELAY N443 (AV)
F21
0…7
6FIX
YDL-AV-N3 Y SIGNAL DELAY N358 (AV)
F22
0…7
6*FIX
BUS SETUP
YDL-YUV Y SIGNAL DELAY YUV
F23
0…7
6*FIX
COL-AV (OFFSET) COLOUR OFFSET AV
F24
-31…0…+31
+10 *FIX
BUS SETUP
COL-P (OFFSET) COLOUR OFFSET PAL
F25
-31…0…+31
0*FIX
COL-S (OFFSET) COLOUR OFFSET SECAM
F26
-31…0…+31
+9 FIX
COL-N4 (OFFSET) COLOUR OFFSET N443
F27
-31…0…+31
-8 FIX
COL-N3 (OFFSET) COLOUR OFFSET N358
F28
-31…0…+31
-7 *FIX
COL-ADJ (OFFSET) COLOUR OFFSET ADJUST
F29
-31…0…+31
0*FIX
BUS SETUP
SHP-PRE-AV (OFFSET) SHARPNESS PRE OFFSET -AV
F30
-31…0…+31 +5
*FIX
BUS SETUP
SHP-PRE-YUV (OFFSET) SHARPNESS PRE OFFSET -YUV
F31
-31…0…+31 -5
*FIX
SHP-PRE-P (OFFSET) SHARPNESS PRE OFFSET -PAL
F32
-31…0…+31 -10
*FIX
BUS SETUP
SHP-PRE-S (OFFSET) SHARPNESS PRE OFFSET -
SECAM
F33
-31…0…+31 -15
*FIX
BUS SETUP
SHP-PRE-N4 (OFFSET) SHARPNESS PRE OFFSET -N443
F34
-31…0…+31 -10
*FIX
BUS SETUP
SHP-PRE-N3 (OFFSET) SHARPNESS PRE OFFSET -N358
F35
-31…0…+31 -10
*FIX
BUS SETUP
SHP-OV-AV (OFFSET)
SHARPNESS OV OFFSET -AV
F36
-31…0…+31
+5
*FIX
BUS SETUP
SHP-OV-YUV (OFFSET)
SHARPNESS OV OFFSET - YUV
F37
-31…0…+31
+5
FIX
SHP-OV-P (OFFSET)
SHARPNESS OV OFFSET -PAL
F38
-31…0…+31
0
*FIX
BUS SETUP
SHP-OV-S (OFFSET)
SHARPNESS OV OFFSET -
SECAM
F39
-31…0…+31
-5
*FIX
BUS SETUP
SHP-OV-N4 (OFFSET)
SHARPNESS OV OFFSET-N443
F40
-31…0…+31
0
*FIX
BUS SETUP
SHP-OV-N3 (OFFSET)
SHARPNESS OV OFFSET -N358
F41
-31…0…+31
0
*FIX
BUS SETUP
TINT-AV (OFFSET) TINT OFFSET AV
F42
-63…0…+63
0*FIX
BUS SETUP
TINT-ADJ (OFFSET) TINT OFFSET ADJUST
F43
-63…0…+63
0*FIX
BUS SETUP
TINT-YUV-ADJ (OFFSET) TINT YUV OFFSET ADJUST
F44
-63…0…+63
0FIX
R-R (OFFSET) R-DRIVE OFFSET WHEN WHITE
TEMP IS RED
F45
-63…0…+63
+8 *FIX
BUS SETUP
B-R (OFFSET) B-DRIVE OFFSET WHEN WHITE
TEMP IS RED
F46
-63…0…+63
-10 *FIX
BUS SETUP
R-B (OFFSET) R-DRIVE OFFSET WHEN WHITE
TEMP IS BLUE
F47
-63…0…+63
-3 *FIX
BUS SETUP
B-B (OFFSET) B-DRIVE OFFSET WHEN WHITE
TEMP IS BLUE
F48
-63…0…+63
+13 *FIX
BUS SETUP
CTRAP-ADJ
CENTER VALUE OF CHROMA
TRAP
F49
0…3
2FIX
CTRAP-ADJ-P
CENTER VALUE OF CHROMA
TRAP PAL
F50
0…3
2FIX
CTRAP-ADJ-S
CENTER VALUE OF CHROMA
TRAP SECAM
F51
0…3
2FIX
CTRAP-ADJ-N4
CENTER VALUE OF CHROMA
TRAP N443
F52
0…3
2FIX
CTRAP-ADJ-N3
CENTER VALUE OF CHROMA
TRAP N358
F53
0…3
2FIX
BUS SETUP
BUS SETUP
BUS SETUP
BUS SETUP
