21F-PD250 / 21F-PT220 / 21F-PA18 / 21F-PA18(B)
3 – 6
**AFTER INITIALIZED THE EEPROM (REFER TO FACTORY PRESETTING), READ DATA FROM
EEPROM ADDRESS 00H ~ 03H,AND COMPARE TO THE LIST BELOW, IF DIFFERENT,
INITIALIZE THE EEPROM.
ADDRESS DATA ADDRESS DATA
00H:
7CH
02H:
78H
01H:
70H
03H:
70H
*** There are four stages of service mode data. First stage data from V00~V32 (Adjustment Mode).
To go into second stage of service mode data, press MENU key.Second stage data from F01~F185(Setting Mode).
To go into third stage of service mode data, press MENU key.Third stage data is Check Mode.
To go into fourth stage of service mode data, press MENU key.Fourth stage data from O01~O37(Option Mode).
EEPROM ITEMS OSD DATA LENGTH INITIAL DATA FIX/ADJ/AUTO REMARK
R-DRIVE
V00 0~127 63 ADJ
PLS REFER TO
B-DRIVE
V00 0~127 63 ADJ
ADJ ITEM FOR
R-CUT
V00 0~255 127 ADJ
SCREEN AND
G-CUT
V00 0~255 127 ADJ
WHITE BALANCE
B-CUT
V00 0~255 127 ADJ
RF-AGC
V01 0~127 50 AUTO
VIF-VCO
V02 0~63 31 AUTO
H-VCO
V03 0~7 3 AUTO
SUB-CON
V04 0~127 100 ADJ
SUB-COLOR
V05 0~127 63 ADJ
SUB-BRIGHT
V06 0~255 127 ADJ
SUB-TINT
V07 0~127 63 ADJ
SUB-SHP PRE
V08 0~63 43 *FIX
BUS SETUP
SUB-COLOR-YUV
V09 0~127 90 *FIX
SUB-TINT-YUV
V10 0~127 63 FIX
V-SIZE
V11 0~63 38 ADJ
V-SHIFT
V12 0~7 3 ADJ
H-SHIFT
V13 0~31 9 ADJ
SCM-BR
V14 0~63 37 FIX
SCM-BB
V15 0~63 22 FIX
SUB-VOL
V16 0~60 60 FIX
V-SIZE60
V17 -31~0~+31 0 *FIX
BUS SETUP
V-SHIFT60
V18 -7~0~+7 -1 *FIX
BUS SETUP
H-SHIFT60
V19 -15~0~+15 +2 FIX
IF NECESSARY, ADJ
S-TRAP(BG)
V20 0~127 64 AUTO
S-TRAP(I)
V21 0~127 64 AUTO
S-TRAP(DK)
V22 0~127 64 AUTO
S-TRAP(M)
V23 0~127 64 AUTO
S-TRAP(574)
V24 0~127 64 AUTO
CUTOFF/BKGD YUV
V25
R-DRI YUV
V25
0…127 63
FIX
B-DRI YUV
V25
0…127 63
FIX
R-CUT YUV
V25
0…255 127
FIX NO FUNCTON
G-CUT YUV
V25
0…255 127
FIX NO FUNCTON
B-CUT YUV
V25
0…255 127
FIX NO FUNCTON
SUB-CON YUV
V26 0~127 100 FIX
SUB-BRIGHT YUV
V27 0~255 127 FIX
VS-CORRECT
V28 0~63 32 *FIX
BUS SETUP
VS-CORRECT_OFFSET
V29 -13~+13 0 *FIX
BUS SETUP
VLINEARITY
V30 0~63 32 *FIX
BUS SETUP
V LINEARITY_OFFSET
V31 -13~+13 0 *FIX
BUS SETUP
SUB-SHP OV
V32 0~63 43 *FIX
BUS SETUP
ADJUSTMENT MODE
(
FIRST STAGE
)
To go into fifth stage of service mode data, press MENU key.Fifth stage data is NVM Edit Mode.
BUS SETUP
