21F-PD250 / 21F-PT220 / 21F-PA18 / 21F-PA18(B)
4 – 9
MEMORY MAP (Continued)
MODEL :
GA-7_IXC129WJN1
SEM PCD SOFTWARE GROUP TV DESIGN ENGINEERING TV PRODUCTION ENGINEERING
ISSUED DATE :1 MARCH 2007 ISSUED DATE : ISSUED DATE : 28.JUNE.2007
EEPROM CHECK DATA LIST 9
MANAGER MANAGER MANAGER
MATSUNAGA
CHIEF CHIEF CHIEF
ISMAIL
ENGINEER
Tan
ENGINEER ENGINEER
CHIN
SLAVE ADDRESS : A0(00-FF) A2(100-1FF) A4(200-2FF) A6(300-3FF) A8(400-4FF) AA(500-5FF) AC(600-6FF) AE(700-7FF)
ADDRESS
DATA
MICON EEPROM EEPROM CHASSIS CTV FINAL
LAST INITIAL
(HEX)D7D6D5D4D3D2D1D0
DEFAULT RANGE
WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE
SETTING DATA REMARK
200
R-DRIVE (V00)
3F 00-7F 3F
201
B-DRIVE (V00)
3F 00-7F 3F
202
R-CUTOFF (V00)
7F 00-FF 7F
203
G-CUTOFF (V00)
7F 00-FF 7F
204
B-CUTOFF (V00)
7F 00-FF 7F
205
RF-AGC (V01)
32 00-7F 2A
206
VIF-VCO (V02)
1F 00-3F 1F
207
H-VCO (V03)
03 00-07 03
208
SUB CONTRAST (V04)
64 00-7F 64
209
SUB COLOUR (V05)
3F 00-7F 47
20A
SUB BRIGHTNESS (V06)
7F 00-FF 7F
20B
SUB TINT (V07)
3F 00-7F 3D
20C
SUB SHARPNESS PRE (V08)
2B 00-3F 26
20D
SUB-COLOUR-YUV (V09)
5A 00-7F 5A
20E
SUB-TINT-YUV (V10)
3F 00-7F 3F
20F
V-SIZE-50Hz (V11)
26 00-3F 27
210
V-SHIFT-50Hz (V12)
03 00-07 02
211
H-SHIFT-50Hz (V13)
09 00-1F 12
212
SECAM BR (V14)
25 00-3F 25
213
SECAM BB (V15)
16 00-3F 16
214
SUB VOLUME (V16)
3C 00-3C 3C
215
V-SIZE-60Hz (V17)
1F 00-3E 23
216
V-SHIFT-60Hz (V18)
06 00-0E 05
217
H-SHIFT-60Hz (V19)
11 00-1E 11
218
S-TRAP-BG (V20)
40 00-7F 40
219
S-TRAP-I (V21)
40 00-7F 40
21A
S-TRAP-DK (V22)
40 00-7F 40
21B
S-TRAP-M (V23)
40 00-7F 40
21C
S-TRAP-574 (V24)
40 00-7F 40
21D
21E
21F
220
221
222
SUB CONTRAST YUV (V26)
64 00-7F 64
223
SUB BRIGHTNESS YUV (V27)
7F 00-FF 7F
224
VS-CORRECT (V28)
20 00-3F 2C
225
VS-CORRECT OFFSET (V29)
0D 00-1A 04
226
V-LINEARITY (V30)
20 00-3F 24
227
V-LINEARITY OFFSET (V31)
0D 00-1A 10
228
SUB SHARPNESS OV (V32)
2B 00-3F 26
229
22A
22B
22C
S-OUT-LEVEL (F06)
5F 00-7F 5F
22D
VIF-G (F07)
04 00-07 07
22E
YDL (F13)
05 00-07 05
22F
YDL-PAL (F14)
05 00-07 05
230
YDL-SECAM (F15)
07 00-07 07
231
YDL-N443 (F16)
05 00-07 05
232
YDL-N358 (F17)
05 00-07 05
233
YDL-AV (F18)
06 00-07 06
234
YDL-AV-PAL (F19)
06 00-07 06
235
YDL-AV-SECAM (F20)
07 00-07 07
236
YDL-AV-N443 (F21)
06 00-07 06
237
YDL-AV-N358 (F22)
06 00-07 05
238
YDL-YUV (F23)
06 00-07 06
239
COLOUR-AV (F24)
29 00-3E 23
23A
COLOUR-PAL (F25)
1F 00-3E 2B
23B
COLOUR-SECAM (F26)
28 00-3E 28
23C
COLOUR-N443 (F27)
17 00-3E 17
23D
COLOUR-N358 (F28)
18 00-3E 27
23E
COLUR-ADJ (F29)
1F 00-3E 2D
23F
SHARPNESS-PRE-AV (F30)
24 00-3E 20
MODEL MODEL
LETTER NO. LETTER NO.
To Next Page
