21F-PD250 / 21F-PT220 / 21F-PA18 / 21F-PA18(B)
4 – 10
MEMORY MAP (Continued)
MODEL :
GA-7_IXC129WJN1
SEM PCD SOFTWARE GROUP TV DESIGN ENGINEERING TV PRODUCTION ENGINEERING
ISSUED DATE :1 MARCH 2007 ISSUED DATE : ISSUED DATE : 28.JUNE.2007
EEPROM CHECK DATA LIST 10
MANAGER MANAGER MANAGER
MATSUNAGA
CHIEF CHIEF CHIEF
ISMAIL
ENGINEER
Tan
ENGINEER ENGINEER
CHIN
SLAVE ADDRESS : A0(00-FF) A2(100-1FF) A4(200-2FF) A6(300-3FF) A8(400-4FF) AA(500-5FF) AC(600-6FF) AE(700-7FF)
ADDRESS DATA MICON EEPROM EEPROM CHASSIS CTV FINAL
LAST INITIAL
(HEX)D7D6D5D4D3D2D1D0 DEFAULT RANGE WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE SETTING DATA REMARK
240
SHARPNESS-PRE-YUV (F31)
1A 00-3E 1A
241
SHARPNESS-PRE-PAL (F32)
15 00-3E 26
242
SHARPNESS-PRE-SECAM (F33)
10 00-3E 21
243
SHARPNESS-PRE-N443 (F34)
15 00-3E 26
244
SHARPNESS-PRE-N358 (F35)
15 00-3E 26
245
TINT-AV (F42)
3F 00-7E 40
246
TINT-ADJ (F43)
3F 00-7E 41
247
TINT-YUV-ADJ (F44)
3F 00-7E 3F
248
R-R DRIVE (F45)
47 00-7E 3F
249
B-R DRIVE (F46)
35 00-7E 36
24A
R-B DRIVE (F47)
3C 00-7E 39
24B
B-B DRIVE (F48)
4C 00-7E 47
24C
TRAP (F49)
02 00-03 02
24D
TRAP-PAL (F50)
02 00-03 02
24E
TRAP-SECAM (F51)
02 00-03 02
24F
TRAP-N443 (F52)
02 00-03 02
250
TRAP-N358 (F53)
02 00-03 02
251
GAMMA (F58)
00 00-03 01
252
BS-D/C (F59)
0A 00-0F 0A
253
SL-TV (F62)
02 00-07 02
254
SL-AV (F63)
04 00-07 02
255
SL-YUV (F64)
04 00-07 04
256
AS/FBP-TV (F65)
02 00-03 03
257
AS/FBP-AV (F66)
02 00-03 03
258
AS/FBP-YUV (F67)
02 00-03 03
259
VDL (F68)
00 00-03 00
25A
UDL (F69)
00 00-03 00
25B
AUTO-SCM-KIL-TV (F70)
01 00-03 01
25C
SECAM-BGP (F71)
00 00-03 00
25D
25E
25F
OSD-POS (F75)
09 00-7F 09
260
SHARPNESS-OVER-AV (F36)
24 00-3E 20
261
SHARPNESS 7)
24
-OVER-YUV (F3
00-3E 24
262
SHARPNESS-OVER-PAL (F38)
1F 00-3E 26
263
SHARPNESS-OVER-SECAM (F39)
1A 00-3E 21
264
SHARPNESS-OVER-N443 (F40)
1F 00-3E 26
265
SHARPNESS-OVER-N358 (F41)
1F 00-3E 26
266
AFC2 GAIN (F57)
00 00-03 00
267
268
269
26A
26B
26C
26D
AUTO-SCM-KIL-AV-YUV
(F78)
01 00-03 01
26E
AFC1-GAIN-TV (F79)
00 00-03 00
26F
AFC1-GAIN-AV (F80)
03 00-03 03
270
AFC1-GAIN-YUV (F81)
03 00-03 03
271
OSD LEVEL (F82)
03 00-04 04
272
AC-FAIL-WO-BRIGHT (F87)
FF 00-FF FF
273
FORCED-SCM-KIL-TV (F88)
02 00-03 02
274
FORCED-SCM-KIL-AV-YUV
(F89)
02 00-03 02
275
VIDEO-DEMUTE-DELAY (F91)
00 00-FF 19
276
SOUND-DEMUTE-DELAY (F92)
00 00-FF 28
277
MER (F93)
46 00-FF 46
278
MEL1 (F94)
96 00-FF 96
279
MEL2 (F95)
9C 00-FF 9C
27A
MEL3 (F96)
A3 00-FF A3
27B
MEL4 (F97)
A5 00-FF A5
27C
MEL5 (F98)
AA 00-FF AA
27D
MEL6 (F99)
B4 01-FF B4
27E
S-Start Point (F100)
15 00-3C 15
27F
S-Stop Point (F101)
3C 00-3C 3C
MODEL MODEL
LETTER NO. LETTER NO.
