Sharp 21V-FR95S - Capacitors

C208 VCKYCY1HF103Z 0.01, 50V Ceramic
C209 VCKYCY1HF103Z 0.01, 50V Ceramic
D732 RH-EX0626GEZZ Zener, EX0626GE C210 VCKYCY1HF103Z 0.01, 50V Ceramic
D736 RH-EX0683GEZZ Zener, EX0683GE C213 VCKYCY1HB102K 1000p, 50V Ceramic
D751 RH-DXA006WJZZ DXA006WJ C301 VCEA0A1CW477M 470, 16V EL.
D752 RH-DX0247CEZZ DX0247CE C304 VCEA9M1CW106M 10, 16V EL.
D801 RH-EX1393CEZZ Zener, EX1393CE C308 VCKYCY1HB822K 8200, 50V Ceramic
D802 RH-EX0630GEZZ Zener, EX0630GE C310 VCEA0A1HW105M 1, 50V EL.
D803 VHD1SS119//-1 D1SS119 C311 VCEA0A1HW105M 1, 50V EL.
D806 VHD1SS119//-1 D1SS119 C312 VCEA0A1HW335M 3.3, 50V EL.
D810 RH-EX0263TAZZ Zener, EX0263TA C313 VCKYCY1HB822K 8200, 50V Ceramic
D811 RH-EX0263TAZZ Zener, EX0263TA C318 VCEA0A1CW107M 100, 16V EL
D812 RH-EX0263TAZZ Zener, EX0263TA C321 VCEA0A1HW335M 3.3, 50V EL.
D1001 RH-PX0013PEZZ LED, Power C322 VCEA0A1HW105M 1, 50V EL.
D1081 VHD1SS119//-1 D1SS119 C391 VCKYPA1HB102
K
1000p, 50V Ceramic
D1085 RH-EX1393CEZZ Zener, EX1393CE C392 VCQYTA1HM103J 0.01, 50V Ceramic
D1086 RH-EX1393CEZZ Zener, EX1393CE C393 VCEA0A1EW108M 1000, 25V EL.
D1089 RH-EX1393CEZZ Zener, EX1393CE C437 VCE9GA1HW106M 10, 50V EL.
D1091 VHD1SS119//-1 D1SS119 C438 VCEA0A1CW106M 10, 16V EL.
D1094 VHD1SS119//-1 D1SS119 C439 VCKYCY1HF103Z 0.01, 50V Ceramic
D1095 VHD1SS119//-1 D1SS119 C451 VCEA0A1CW477M 470, 16V EL.
D1801 VHD1SS119//-1 D1SS119 C505 VCEA0A1HW107M 100, 50V EL.
D1802 RH-EX1393CEZZ Zener, EX1393CE C508 VCFYAA2AA224J 0.22, 100V M-Poly.
D1803 RH-EX1393CEZZ Zener, EX1393CE C511 VCEA0A1VW477M 470, 35V EL.
VA701 RH-VX0073CEZZ Varistor C512 VCKYPA2HB102
K
1000p, 500V Ceramic
C513 RC-EZA332WJZZ EZA332WJ
C515 VCEACA1HC335J 3.3, 50V EL.
NR701 RH-HXA013WJZZ Thermistor C601 VCQYTA1HM563J 0.056, 50V Mylar
! PR701 RMPTP0085CEZZ Packaged Circuit C602 VCEA0A1HW475M 4.7, 50V EL.
X801 RCRSAA010WJZZ Crystal Oscillator C603 VCEA0A1HW105M 1, 50V EL.
C604 VCEA0A2EW336M 33, 250V EL.
CF201 RFILC0447CEZZ Ceramic Filter C606 VCKYPA2HB102
K
1000p, 500V Ceramic
CF802 RFILC0446CEZZ Ceramic Filter ! C607 VCFPVC3ZA972H 9700p, 1800V M-Poly.
L203 VP-DF270K0000
Peaking 27
µ
H
C608 VCQYTA2AA103K 0.01, 100V Mylar
L204 VP-XF1R2K0000
Peaking 1.2
µ
H
C610 VCEA0A1EW227M 220, 25V EL.
L602 RCILP0223CEZZ
Coil 3.3
µ
H
C611 VCFPVC2DB334J 0.33, 200V M-Poly
! L701 RCILFA060WJZZ Coil C642 VCEA0A1EW476M 47, 25V EL.
L751 RCILP0179CEZZ Coil C643 VCEA0A1CW477M 470, 16V EL.
L801 VP-DF100K0000
Peaking 10
µ
H
C650 VCKYPA2HB101
K
100p, 500V Ceramic
L802 VP-DF100K0000
Peaking 10
µ
H
! C701 RC-FZ029SCEZZ 0.22, 275V M-Poly.
L803 VP-DF100K0000
Peaking 10
µ
H
C702 RC-KZ0029CEZZ 0.01, 250V Ceramic
L804 VP-XF150K0000
Peaking 15
µ
H
C703 RC-KZ0029CEZZ 0.01, 250V Ceramic
L806 VP-DF100K0000
Peaking 10
µ
H
C704 RC-KZ0029CEZZ 0.01, 250V Ceramic
L807 VP-XF1R2K0000
Peaking 1.2
µ
H
! C705 RC-EZA533WJZZ 220, 400V EL.
SF201 RFILCA045WJPZ SAW Filter C706 VCEA0A1HW336M 33, 50V EL.
C708 VCKYPA1HB221
K
220p, 50V Ceramic
C709 VCKYPA1HB103
K
0.01, 50V Ceramic
! T602 RTRNFA113WJZZ H-Volt Transformer C710 VCFYFA1HA103J 0.01, 50V M-Poly
! T603 RTRNZA058WJZZ Transformer C711 VCKYPA1HB472
K
4700p, 50V Ceramic
! T701 RTRNWA193WJZZ Transformer C719 VCFYFA1HA105J 1, 50V M-Poly
C743 VCKYPH3DB561K 560p, 2kV Ceramic
! C750 VCKYPA2HB102
K
1000p, 500V Ceramic
! C751 RC-KZ0102GEZZ 680p, AC250V Porcelain
C201 VCEA0A1CW476M 47, 16V EL. C752 VCKYPH3DB561K 560p, 2kV Ceramic
C202 VCEA0A0JW108M 1000, 6.3V EL. C753 RC-EZA523WJZZ 100, 160V EL.
C203 VCKYCY1HF103Z 0.01, 50V Ceramic C754 RC-EZA522WJZZ 33, 160V EL.
C205 VCKYCY1HF103Z 0.01, 50V Ceramic C755 VCQYTA1HM103J 0.01, 50V Mylar
C206 VCEA0A1HW106M 10, 50V EL. C756 VCEA0A1EW228M 2200, 25V EL.
C207 VCKYCY1HF103Z 0.01, 50V Ceramic C757 VCKYCY1HB471K 470p, 50V Ceramic
21V-FR95S
FILTERS AND COILS
CAPACITORS
[EL. …Electrolytic, M-Poly. …Metalized Polypro Film]
TRANSFORMERS
Ref. No. Part No.Ref. No. DescriptionPart No. Description
(Continued)
PWB-A: DUNTKD373WEA0 MAIN UNIT
PACKAGED CIRCUITS
41
