Sharp 21V-FR95S - Replacement Parts List; Tuner Parts; Integrated Circuits; Transistors

21V-FR95S
! TU201 VTUVT1Y5UF201 Tuner
IC301 VHIAN17821A-1 AN17821A
IC402 VHIMM1501XN-1 MM1501XN
! IC501 VHITDA9302H-1 TDA9302H
IC601 VHIKA78R09AP1 KA78R09AP
1. MODEL NUMBER 2. REF. NO.
! IC701 VHISTRW5453-1 STRW5453
3. PART NO. 4. DESCRIPTION IC801 VHIM61250CF1EQ M61250CF
IC1001 RH-IXA983WJZZ IXA983WJ
IC1003 VHIBR24L04F-1* BR24L04F
Q201 VS2SC2735//1E 2SC2735
Q601 VS2SC2235Y/1E 2SC2235Y
! V101 VB51LYZ295X2E Q602 VSTT2140+++-F TT2140++
! DY601 ITC TYPE CRT DY Q603 VS2SC3198-G-1 2SC3198-G
! L706 RCILGA095WJZZ Degaussing Coil Q604 VS2SD601AR/-1 2SD601AR
QEARCA012WJZZ CRT Ground Wire Q751 VS2SD468-C/-1 2SD468-C
ITC TYPE CRT Purity Magnet Q752 VS2SD468-C/-1 2SD468-C
ITC TYPE CRT Spacer Q753 VS2SC3198-G-1 2SC3198-G
LHLDW0003PEKZ Wire Holder Q754 VS2SD468-C/-1 2SD468-C
LBNDC0001PFZZ Wire Holder Q801 VS2SD601AR/-1 2SD601AR
Q803 VS2SD601AR/-1 2SD601AR
Q804 VS2SB709AR/-1 2SB709AR
Q805 VS2SB709AR/-1 2SB709AR
Q1001 VS2SD601AR/-1 2SD601AR
PWB-A DUNTKD373WEA0 MAIN Unit Q1002 VS2SD601AR/-1 2SD601AR
PWB-B DUNTKA599WEI1 CRT Unit Q1073 VS2SD601AR/-1 2SD601AR
PWB-C DUNTKC574WEA3 MTS Unit
D201 RH-EX0676GEZZ Zener, EX0676GE
D203 VHD1SS119//-1 D1SS119
D393 RH-DX0247CEZZ DX0247CE
D503 RH-EX0612GEZZ Zener, EX0612GE
D505 RH-DX0441CEZZ DX0441CE
D510 RH-DX0131CEZZ DX0131CE
D601 VHD1SS119//-1 D1SS119
D602 VHD1SS244//-1 1SS244
D603 RH-EX0667GEZZ Zener, EX0667GE
D606 RH-DX0131CEZZ DX0131CE
! D701 RH-DX0476CEZZ DX0476CE
D706 RH-DX0066GEZZ DX0066GE
D707 RH-DX0066GEZZ DX0066GE
D709 RH-DX0066GEZZ DX0066GE
D710 VHD1SS119//-1 D1SS119
D715 RH-EX0615GEZZ Zener, EX0615GE
D721 RH-DX0066GEZZ DX0066GE
D722 RH-EX0669GEZZ Zener, EX0669GE
D723 RH-EX0640GEZZ Zener, EX0640GE
MARK: X-RAY RELATED PARTS
REPLACEMENT PARTS LIST
To have your order filled promptly and correctly, please
furnish the following informations.
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by ! And shaded areas in the Replacement Parts
Lists and Schematic Diagrams. The use of a substitute replacement
part which does not have the same safety characteristic as the
factory recommended replacement parts shown in this service
manual may create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
Description
PWB-A: DUNTKD373WEA0 MAIN UNIT
TUNER
INTEGRATED CIRCUITS
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
Ref. No. Part No.
(NOT REPLACEMENT ITEM)
TRANSISTORS
DIODES
Part No.
Picture Tube
DescriptionRef. No.
PICTURE TUBE
PRINTED WIRING BOARD ASSEMBLIES
40
