Sharp 21V-FW100S User Manual

21V-FW100S
5 – 3
ADJUSTMENT
ITEM
ADJUSTMENT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INPUT
CONDITION
OUTPUT
ADJUSTMENT
PROCEDURE
LEFT AND RIGHT SYMMETRICAL
SYMBOL
I2C BUS CONTROL
OPTION SET UP, BUS SET UP,CRT-PURITY
MODEL NAME
H-POSITION
STEP RANGE
V07
0-31
21V-FW100S
US 4 CH LION HEAD (MONOSCOPE)
AC 220V, US MAGNETIC FIELD
1.ADJUST THE
V07
BUS DATA TO HAVE A BALANCE POSITION TO SPEC OF
A=B
.
2.IF CANNOT MAKE IT TO
A=B
, ADJ FROM THE BEST POINT SO THAT
B
SLIDELY SMALLER
THAN
A
[CHECKING SPEC]
CONFIRMATION BY CRT SCREEN
HISTORY
OF REVISION
REVISED CONTENT .
B
A
