21V1-L
5 – 4
ADJ US TME NT
ITEM
ADJ US TME NT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INP UT
CONDIT IO N
OUTP UT
ADJ US TME NT
PROCEDURE
MODEL NAME
V-S IZE
V10
STEP RANGE
0~63
21V1-L
CONFIRMATION BY CRT S CREEN
ADJUST THE V10 BUS DATA UNTILL THE OVERSCAN BECOME AS SPECIFIED BELOW.
CAUTION:- PLEASE AGING T V MORE THAN 10 MINUTES BEFORE ADJUSTMENT.
[CHECKING SPEC]
OVERSCAN 10 ± 2.5%
I2C CONTROL
OP TION S ET UP , BUS S ET UP,CRT P URITY, V-PHASE , +B ADJ US T
US4CHLIONHEAD(MONOSCOPE)
AC 2 2 0
