Sharp 21V1-L

21V1-L
5 – 5
ADJ US TME NT
ITE M
ADJ US TME NT
POSITION
CONTOROL
PRE-ADJUST
REQUIR EMENT
CONTENT
INP UT
CONDITIO N
OUTPUT
ADJ US TMENT
PROCEDURE
MODEL NAME
V-P HAS E
V07
STEP RANGE
0-7
21V1-L
CONFIRMATION ON CRT S CREEN
ADJUST V07 BUS DATA TO HAVE A MOST ACCEPTABLE VERTICAL POSITION.
THE MONOSCOPE PATTERN SHOULD BE BALANCE IN VERTICAL POSITION
NOTE: THE DATA FOR V07 LIMIT AT <= 0
4,
EVEN POSITION NOT GOOD ENOUGH
[CHECKING CONFIRMATION ]
I2C CONTROL
OP TION S ET UP , BUS S ET UP, CRT P URITY
US 4CHLIONHEAD(MONOSCOPE)
220V,RFINPUT,ZEROMAGNETICFIELD
