Sharp 21V1-L

21V1-L
5 – 6
ADJ US TME NT
ITE M
ADJ US TME NT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INP UT
CONDITION
OUTPUT
ADJ US TME NT
PROCEDURE
LEFT AND RIGHT SYMMETRICAL THEN V22 DATA REDUCE 5 S TEP .
CONFIRMATION ON CRT DIS P LAY.
1) BY SELECTING THE
V22
, BOX BLK TEXT WILL BE APPEARED.
2) ADJUST THE
V22
BUS DATA TO HAVE A BALANCE POSITION TO SPEC OF A=B.
[CHECKING SPEC]
I2C CONTROL
OP TION S ET UP , BUS S ET UP
US4CHLIONHEAD(MONOSCOPE)
AC 220
MODEL NAME
CLOSED CAP TION S ET UP
V22
STEP RANGE
0-255
21V1-L
A
TEXT BOX BLK
B
