Sharp 21V1-L Service Manual

21V1-L
5 – 7
ADJ US TME NT
ITEM
ADJ US TME NT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INP UT
CONDIT IO N
OUTP UT
(MANUAL ADJ)
1) GO TO SERVICE MODE
2) GO TO SERVICE DATA
V25
, ADJ UNTIL FREQUENCY AS BELOW
(SELF ADJ)
1) GO TO SERVICE MODE, BY SELECTING THE SERVICE DATA
V25
2) PRESS THE R/C TO OPERATE AUTO H-VCO, OSD APPEAR "OK" AT SCREEN
ADJ US TMENT
3) IF APPEAR "NG" PLS REPEAT STEP 2
PROCEDURE
MODEL NAME
H-VCO
V25
STEP RANGE
0-7
21V1-L
IC 801 P IN 13 (MANUAL), CONFIRMATION ON CRT DIS P LAY (AUTO)
[CHECKING SPEC]
FREQ = 15.735 ± .02 KHz
I2C CONTROL
OP TION S ET UP , BUS S ET UP
NO SIG NAL (R ASTER) CONDITION
AC 2 2 0
