Sharp 21V1-L Service Manual

21V1-L
5 – 8
MODEL NAME
ADJ US TME NT
ITEM
ADJ US TME NT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INP UT
CONDIT IO N
OUTP UT
(AT SELF ADJUSTMENT MODE)
1)G O INTO S E R VIC E MO DE ,BY S E LE C TING THE S E R VIC E DATA
V14
2)PRESS THE R/C FOR AUTO PIF-VCO KEY, OSD APPEAR "OK" AT SCREEN
3)IF APPEAR "NG" PLS REPEAT STEP 2
(AT MANUAL ADJ US TMENT MODE)
ADJ US T
1)GO INTO SERVICE MODE, BY SELECTING THE SERVICE DATA
V14
PROCEDURE 2) ADJUS T THE DATA UP /DOWN UNTIL IC801 P IN 7 VOLTAGE BECOME AS SPECIFIED BELOW
I2C CONTROL
OP TION S ET UP , BUS S ET UP
NO S IGNAL (RAS TER) C O NDITIO N
AC 2 2 0
21V1-L
PIF-VCO
V14
STEP RANGE
0-63
CONFIRMATION ON CRT DIS P LAY(AUTO), IC801 P IN 7 VO LTAGE (MANUAL).
[CHECKING SPEC]
2.5±0.5VDC (CHECKINGSPEC:2.50±1.5V)
