Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
47
25L-M100/180/S100/180
CL25M10,CL25S18
TRANSISTORS
Q851 VS2SC3198-Y-1 J 2SC3198 AA
Q852 VS2SC3789//2E M 2SC3789 AA
Q853 VS2SC3198-Y-1 J 2SC3198 AA
Q854 VS2SC3789//2E M 2SC3789 AA
Q855 VS2SC3198-Y-1 J 2SC3198 AA
Q856 VS2SC3789//2E M 2SC3789 AA
Q881 VS2SA1266-Y-1 J 2SA1266 AA
DIODES
D881 VHD1SS119//-1 J Diode AB
D882 VHD1SS119//-1 J Diode AB
D884 VHD1SS119//-1 J Diode AB
COIL
L851 VP-MK820K0000 J Peaking 82µH AB
CAPACITORS
[EL.··· Electrolytic]
C851 VCCSPA1HL391J J 390p 50V Ceramic AA
C852 VCCSPA1HL331J J 330p 50V Ceramic AA
C853 VCCSPA1HL391J J 390p 50V Ceramic AA
C854 RC-KZ0024CEZZ J 0.001 2kV Ceramic AC
C883 VCEA0A1HW106M J 10 50V EL. AB
RESISTORS
[M-Ox.··· Metal Oxide.]
R851 VRD-RA2BE470J J 47 1/8W Carbon AA
R852 VRD-RA2BE181J J 180 1/8W Carbon AA
R853 VRD-RA2BE121J J 120 1/8W Carbon AA
R855 VRD-RA2BE471J J 470 1/8W Carbon AA
R856 VRD-RA2BE221J J 220 1/8W Carbon AA
å R857 VRS-VV3LB123J J 12k 3.0W M-Ox. AB
R858 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R859 VRD-RA2BE470J J 47 1/8W Carbon AA
R860 VRD-RA2BE181J J 180 1/8W Carbon AA
R861 VRD-RA2BE121J J 120 1/8W Carbon AA
R863 VRD-RA2BE471J J 470 1/8W Carbon AA
R864 VRD-RA2BE221J J 220 1/8W Carbon AA
å R865 VRS-VV3LB123J J 12k 3.0W M-Ox. AB
R866 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R867 VRD-RA2BE470J J 47 1/8W Carbon AA
R868 VRD-RA2BE181J J 180 1/8W Carbon AA
R869 VRD-RA2BE121J J 120 1/8W Carbon AA
R871 VRD-RA2BE471J J 470 1/8W Carbon AA
R872 VRD-RA2BE221J J 220 1/8W Carbon AA
å R873 VRS-VV3LB123J J 12k 3.0W M-Ox. AB
R874 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R881 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R882 VRD-RA2BE331J J 330 1/8W Carbon AA
R883 VRD-RA2BE561J J 560 1/8W Carbon AA
R884 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R895 VRD-RA2BE470J J 47 1/8W Carbon AA
MISCELLANEOUS PARTS
P851 QPLGN0541CEZZ J Plug, 5-pin(GBN) AB
P852 QPLGN0441CEZZ J Plug, 4-pin(YBN) AB
SC851 QSOCV0937CEZZ M CRT Socket AF
PWB-H: DUNTK9310WEK0 (25L-M100/180, CL25M10)
PWB-H: DUNTK9310WEK1 (25L-S100/180, CL25S18)
FRONT AV UNIT
MISCELLANEOUS PARTS
J1001 QJAKE0053GEZZ J Jack, Video in AD
J1002 QJAKE0055GEZZ J Jack, Audio in (L) AD
(25L-S100/180, CL25S18)
J1003 QJAKE0055GEZZ J Jack, Audio in AD
(25L-M100/180, CL25M10)
J1003 QJAKE0059GEZZ J Jack, Audin in (R) AC
(25L-M100/180, CL25M10)
P1001 QPLGN0541CEZZ J Plug, 5-pin (HA) AB
PWB: DUNTK9510WEK1
CRT UNIT
