Sharp 27C240 Service Manual

Ref. No. Part No. « Description Code
D708 VHD1SS119//-1Y X Diode AA
U
D709 RH-DXA006WJZZ X Diode AB
U
D712 RH-DX0532CEZZY X Diode AB
D725 RH-DX0131CEZZY X Diode AB
D726 VHD1SS119//-1Y X Diode AA
D752 RH-DX0441CEZZY X Diode AB
D753 RH-DX0441CEZZY X Diode AB
D757 VHD1SS119//-1Y X Diode AA
U
D758 RH-DX0131CEZZY X Diode AB
D881 VHD1SS119//-1Y X Diode AA
D882 VHD1SS119//-1Y X Diode AA
D884 VHD1SS119//-1Y X Diode AA
D1411 RH-EX0630GEZZY X Zener Diode 9.1V AB
D1412 RH-EX0630GEZZY X Zener Diode 9.1V AB
D1413 RH-EX0630GEZZY X Zener Diode 9.1V AB
D1414 VHD1SS119//-1Y X Diode AA
D1415 VHD1SS119//-1Y X Diode AA
D2201 VHD1SS119//-1Y X Diode AA
VA701 RH-VXA009WJZZ X VARISTOR AB
U
PR701 RMPTP0092CEZZ X Packaged Circuit AD
X801 RCRSAA010WJZZ X CRYSTAL AB
CF2040 RFILA0099CEZZ+ X FILTER AB
SF201 RFILC0405CEZZ X Filter (4.5MHZ) AD
L201 VP-XF1R2K0000Y X Peaking 1.2mH AB
L203 VP-XF220K0000Y X Peaking 22mH AB
L204 RCILI0632CEZZ X IF Coil AB
L301 VP-XF150K0000Y X Peaking 15mH AB
L601 RCILZ0101MEZZ X Coil AD
U
L701 RCILF0078PEZZ X Coil Line Filter AC
L705 RCILP0179CEZZ+ X Coil AB
L2040 RCILB0131CEZZ X Coil (OSC) AB
U
T601 RTRNZ0057PEZZ X Transformer AD
U
T602 RTRNF0049MEZZ X H-Volt Transformer AS
U
T702 RTRNW0001GJZZ X Transformer AF
C51 VCEA0A1AW108M+ X 1000 10V EL. AB
C53 VCEA0A1HW105M+ X 1 50V EL. AB
C54 VCEA0A1HW475M+ X 4.7 50V EL. AB
C101 VCEA0A1CW476M+ X 47 16V EL. AB
C201 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C202 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C203 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C204 VCQYTA1HM223J+ X 0.022 50V Mylar AB
C205 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C206 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C207 VCEA0A1CW476M+ X 47 16V EL. AB
C208 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C209 VCEA0A1HW105M+ X 1 50V EL. AB
C210 VCEA0A1HW474M+ X 0.47 50V EL. AB
C212 VCEA0A1HW474M+ X 0.47 50V EL. AB
C220 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C301 VCCCCY1HH220JY X 22p 50V Ceramic AA
C302 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C303 VCCCCY1HH331JY X 330p 50V Ceramic AB
C304 VCCCCY1HH220JY X 22p 50V Ceramic AA
C305 VCKYCY1HB103KY X 0.01 50V Ceramic AA
DIODES
Ref. No. Part No. « Description Code
C356 VCKYCY1HB332KY X 3300p 50V Ceramic AA
C357 VCEA0A1HW106M+ X 10 50V EL. AB
C358 VCEA0A1HW106M+ X 10 50V EL. AB
C361 VCEA0A1CW477M+ X 470 16V EL. AB
C401 VCCCCY1HH470JY X 47p 50V Ceramic AA
C411 VCEA0A1AW108M+ X 1000 10V EL. AB
C412 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C414 VCEA0A1HW225M+ X 2.2 50V EL. AB
C416 VCEA0A1HW105M+ X 1 50V EL. AB
C451 VCQYTA1HM104J+ X 0.1 50V Mylar AB
C454 VCEA0A1HW475M+ X 4.7 50V EL. AB
C456 VCEA0A1HW106M+ X 10 50V EL. AB
C491 VCEA0A1CW107M+ X 100 16V EL. AB
C492 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C510 VCEA0A1VW477M+ X 470 35V EL. AB
C511 VCCSPA2HL180K+ X 18p 500V Ceramic AB
C512 VCFYSA1JB224J+ X 0.22 63V Mylar AB
C513 VCFYSA1JB473J+ X 0.047 63V Mylar AB
C514 VCEA0A1EW108M+ X 1000 25V EL. AB
C515 VCEA0A1HW475M+ X 4.7 50V EL. AB
C516 VCKYCY1HB222KY X 2200p 50V Ceramic AA
C517 VCEA0A1CW226M+ X 22 16V EL. AB
C520 VCEA0A1HW107M+ X 100 50V EL. AB
C530 VCFYFA1HA334J+ X 0.33 50V Mylar AB
C531 VCFYFA1HA564J+ X 0.56 50V Mylar AB
C606 VCKYPA2HB561K+ X 560p 500V Ceramic AB
C607 VCKYPA1HB472K+ X 4700p 50V Ceramic AB
C608 VCKYPA2HB331K+ X 330p 500V Ceramic AB
p
U
C610 RC-FZ1034CEZZ X 13500p 1.8kV Plastic AC
C612 VCFPVC2DB474J X 0.47 200V M-Poly. AB
C632 VCKYCY1EB153KY X 0.015 25V Ceramic AA
C633 VCEA0A1AW337M+ X 330 10V EL. AB
C634 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C635 VCEA0A1HW105M+ X 1 50V EL. AB
C637 VCEA0A1CW476M+ X 47 16V EL. AB
C652 VCEA0A1HW475M+ X 4.7 50V EL. AB
C653 VCEA0A1HW105M+ X 1 50V EL. AB
C654 VCFYSA1HB184J+ X 0.18 50V EL. AB
C662 VCEA0A1CW477M+ X 470 16V EL. AB
U
C701 RC-FZ029SCEZZ X 0.22 250V Ceramic AB
C702 RC-KZ0029CEZZ+ X 0.01 AC250V Ceramic AB
C703 RC-KZ0029CEZZ+ X 0.01 AC250V Ceramic AB
U
C705 RC-EZ0800CEZZ X 560 200V EL. AF
U
C706 RC-KZ0092GEZZA X 3300p AC250V Ceramic AB
C717 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C723 RC-EZ0724CEZZ X 100 160V EL. AC
U
C725 RC-EZA064WJZZ X 220 160V EL. AD
C726 VCKYPH3DB561K X 560p 2kV Ceramic AB
C727 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
U
C730 VCEA0A1CW108M+ X 1000 16V EL. AB
U
C731 VCEA0A1EW337M+ X 330 25V EL. AB
C732 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C736 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C737 VCEA0A1EW226M+ X 22 25V EL. AB
C738 RC-KZ0040CEZZ X 820p 2kV Ceramic AB
C739 VCEA0A1HW104M+ X 0.1 50V EL. AB
C740 VCEA0A1EW476M+ X 47 25V EL. AB
C742 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C743 VCKYPH3DB561K X 560p 2kV Ceramic AB
C750 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C752 VCEA0A1CW476M+ X 47 16V EL. AB
C753 VCKYPH3DB561K X 560p 2kV Ceramic AB
C754 VCEA0A1CW476M+ X 47 16V EL. AB
C758 VCEA0A2EW106M+ X 10 250V EL. AB
C760 VCEA0A1CW108M+ X 1000 16V EL. AB
C771 VCEA0A1CW476M+ X 47 16V EL. AB
C772 VCEA0A1CW476M+ X 47 16V EL. AB
C783 VCQYTA1HM103J+ X 0.01 50V Mylar AB
C784 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
27C240
PWB-A: DUNTKA462WEA0
MAIN UNIT
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
PACKAGED CIRCUITS
VARISTOR
FILTERS AND COILS
TRANSFORMERS
23
