Sharp 27C240 Service Manual

Ref. No. Part No. « Description Code
R2064 VRD-RA2BE391JY X 390 1/8W Carbon AA
R2065 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2067 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2068 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2069 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R2070 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2072 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2101 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2102 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2201 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2202 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R2203 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R2211 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R2212 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R2213 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R2401 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2402 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2403 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2404 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2501 VRD-RA2BE123JY X 12k 1/8W Carbon AA
R2503 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R2504 VRS-CY1JF123JY X 12k 1/16W M-Ox. AA
R2505 VRS-CY1JF563JY X 56k 1/16W M-Ox. AA
R2506 VRS-CY1JF563JY X 56k 1/16W M-Ox. AA
R2507 VRS-CY1JF823JY X 82k 1/16W M-Ox. AA
R2508 VRS-CY1JF153JY X 15k 1/16W M-Ox. AA
R2509 VRS-CY1JF272JY X 2.7k 1/16W M-Ox. AA
R2601 VRD-RA2BE100JY X 10 1/8W Carbon AA
R2602 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2604 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2605 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R3001 VRD-RA2BE221JY X 220 1/8W Carbon AA
R3002 VRD-RA2BE221JY X 220 1/8W Carbon AA
R3003 VRS-CY1JF105JY X 1M 1/16W M-Ox. AA
R3004 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R3005 VRS-CY1JF623JY X 62k 1/16W M-Ox. AA
R3007 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R3008 VRS-CY1JF302JY X 3k 1/16W M-Ox. AA
R3010 VRS-CY1JF392JY X 3.9k 1/16W M-Ox. AA
R3011 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R3012 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R3013 VRD-RA2BE101JY X 100 1/8W Carbon AA
R3014 VRD-RA2BE101JY X 100 1/8W Carbon AA
R3373 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R3374 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R3375 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R3377 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R3378 VRD-RA2BE223JY X 22k 1/8W Carbon AA
R3379 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R3501 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R3502 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R3503 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R3504 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R3507 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3508 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
S2501 QSW-K0202PEZZ+ X Switch, AB
S2502 QSW-K0202PEZZ+ X Switch, AB
S2503 QSW-K0202PEZZ+ X Switch, AB
S2504 QSW-K0202PEZZ+ X Switch, AB
S2505 QSW-K0202PEZZ+ X Switch, AB
S2506 QSW-K0202PEZZ+ X Switch
, AB
PWB-A: DUNTK9510WEV1
CRT Unit
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No. « Description Code
RY701 RRLYJ0081CEZZ X Relay AD
F701 QFS-B4023CEZZ X FUSE - 4A 125V AB
FB601 RBLN-0047CEZZY X FERRITE BEAD AB
FH701 QFSHD1013CEZZ+ X FUSE CLIP AB
FH702 QFSHD1014CEZZ+ X FUSE CLIP AB
FB2002 RBLN-0037CEZZY X FERRITE BEAD AB
J1401 QJAKGA009WJZZ X Front A/V Jack AC
J1404 QSOCD0430CEZZ X S-Video terminal AC
J1701 QTANJ0340CEZZ X Rear A/V Terminal AD
P303 QPLGN0461CEZZA X Plug, 4pin(S1-4) AB
P401 QPLGN0561CEZZA X Plug, 5Pin(KA) AB
P601 QPLGN0160FJZZ X Plug, 5pin(K1-5) AB
P651 QPLGN0361CEZZA X Plug, 3pin (TP651-3) AB
P701 QPLGN0260CEZZ X Plug, 2pin (M1-2) AB
P751 QPLGN0461CEZZA X Plug, 4pin(S1-4) AB
P2001 QPLGN0561CEZZA X Plug, 5Pin(KA) AB
RMC2601 RRMCU0222CEZZ X R/C RECEIVER AD
RDA501 PRDAR0280PEFW X Heat Sink, for IC501 AC
RDA604 PRDAR0233PEFW X Heat Sink, for Q602 AD
RDA701 PRDAR0265PEFW X Heat Sink, for Q701 AB
TLABM0002GJZZ X Model Label AB
LX-BZ3049GEFD X Screw AA
LX-BZ3100CEFD X Screw AA
LX-TZ3004CEFD X Screw AA
Q851 VS2SC3198-G-1+ X 2SC3198-G AB
Q852 VS2SC3789//2E X 2SC3789 AB
Q853 VS2SC3198-G-1+ X 2SC3198-G AB
Q854 VS2SC3789//2E X 2SC3789 AB
Q855 VS2SC3198-G-1+ X 2SC3198-G AB
Q856 VS2SC3789//2E X 2SC3789 AB
Q881 VS2SA1266-Y-1+ X 2SA1266(Y) AB
L851 VP-MK820K0000+ X Peaking 82mH AB
C851 VCCSPA1HL391J+ X 390p 50V Ceramic AB
C852 VCCSPA1HL331J+ X 330p 50V Ceramic AB
C853 VCCSPA1HL391J+ X 390p 50V Ceramic AB
C854 RC-KZ0024CEZZ X 1000p 2kV M.Poly. AB
C883 VCEA0A1HW106M+ X 10 50V EL. AB
R851 VRD-RA2BE470JY X 47 1/8W Carbon AA
R852 VRD-RA2BE181JY X 180 1/8W Carbon AA
R853 VRD-RA2BE121JY X 120 1/8W Carbon AA
R855 VRD-RA2BE471JY X 470 1/8W Carbon AA
R856 VRD-RA2BE221JY X 220 1/8W Carbon AA
R857 VRS-VV3LB123J X 12k 3W M-Ox. AB
R858 VRD-RM2HD222JY X 2.2k 1/2W Carbon AA
R859 VRD-RA2BE470JY X 47 1/8W Carbon AA
R860 VRD-RA2BE181JY X 180 1/8W Carbon AA
R861 VRD-RA2BE121JY X 120 1/8W Carbon AA
R863 VRD-RA2BE471JY X 470 1/8W Carbon AA
R864 VRD-RA2BE221JY X 220 1/8W Carbon AA
R865 VRS-VV3LB123J X 12k 3W M-Ox. AB
R866 VRD-RM2HD222JY X 2.2k 1/2W Carbon AA
R867 VRD-RA2BE470JY X 47 1/8W Carbon AA
R868 VRD-RA2BE181JY X 180 1/8W Carbon AA
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
SWITCHES
MISCELLANEOUS PARTS
PWB-A: DUNTKA462WEA0
MAIN UNIT
TRANSISTORS
COIL
27C240
26
