Sharp 27C240 Service Manual

Ref. No. Part No. « Description Code
R495 VRS-RG3DB820J+ X 180k 1/16W M-Ox. AB
R496 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R497 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R512 VRD-RM2HD102JY X 1.0k 1/2W Carbon AA
R513 VRD-RM2HD102JY X 1.0k 1/2W Carbon AA
R514 VRD-RM2HD1R0JY X 1 1/2W Carbon AA
R515 VRS-RG3DB271J+ X 270 2W M-Ox. AB
R516 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R517 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R518 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R519 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R520 VRN-RL3AB1R0J+ X 1.0 1W M-Film AB
R522 VRS-CY1JF122JY X 1.2k 1/16W M-Ox. AA
R523 VRS-CY1JF392JY X 3.9k 1/16W M-Ox. AA
R525 VRS-CY1JF272JY X 2.7k 1/16W M-Ox. AA
R527 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
U
R604 VRS-RG3LB472J+ X 4.7k 3W M-Ox. AB
R605 VRD-RA2BE121JY X 120 1/8W Carbon AA
R606 VRD-RA2BE102JY X 1k 1/8W Carbon AA
U
R607 VRS-RG3LB472J+ X 4.7k 3W M-Ox. AB
U
R609 VRS-RG3AB562J+ X 5.6k 1W M-Ox. AB
R610 VRD-RM2HD220JY X 22 1/2W Carbon AA
U
R611 VRS-KA3NG3R3K X 3.3 7.0W M-Ox. AB
R612 VRS-RG2HC102J+ X 1k 1/2W M-Ox. AB
U
R621 VRN-RL3DB1R2J+ X 1.2 2W M-Film AB
R622 VRD-RA2BE222JY X 2.2k 1/8W Carbon AA
R623 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R624 VRN-RA2BK472FY X 4.7k 1/8W M-Film AB
R634 VRD-RM2HD121JY X 120 1/2W Carbon AA
R635 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R636 VRD-RA2EE221JY X 220 1/4W Carbon AA
U
R641 VRS-RG3AB682J+ X 6.8k 1W M-Ox. AB
p
U
R651 VRS-RG2HC270J+ X 27 1/2W M-Ox. AB
p
U
R653 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
p
U
R654 VRS-CY1JF154JY X 150k 1/16W M-Ox. AA
p
U
R655 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R656 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R657 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R658 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R659 VRD-RA2BE332JY X 3.3k 1/8W Carbon AA
U
R661 VRN-RL3ABR47J+ X 0.47 1W M-Film AB
U
R701 RR-DZ0049CEZZY X 3.9M 1/2W Solid AB
U
R703 VRW-KQ3NC1R2K X 1.2 7W Cement AB
R705 VRN-RL3ABR33J+ X .33 1W M-Film AB
R706 VRN-RL3ABR22J+ X 0.22 1W M-Film AB
R707 VRD-RM2HD270JY X 27 1/2W Carbon AA
R708 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R710 VRS-RG2HC103J+ X 10k 1/2W M-Ox. AB
R711 VRD-RA2BE334JY X 330k 1/8W Carbon AA
R712 VRD-RA2BE100JY X 10 1/8W Carbon AA
R713 VRS-RG2HC122J+ X 1.2k 1/2W M-Ox. AB
R715 VRD-RA2BE150JY X 15 1/8W Carbon AA
R716 VRS-RG3AB121J+ X 120 1W M-Ox. AB
R730 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R731 VRS-RG2HC821J+ X 820 1/2W M-Ox. AB
R733 VRS-SV2HC332J X 3.3k 1/2W M-Ox. AB
R736 VRS-SV2HC222J X 2.2k 1/2W M-Ox. AB
U
R737 VRN-RL3ABR39J+ X 0.39 1W M-Ox. AB
R740 VRD-RM2HD470JY X 47 1/2W Carbon AA
R742 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
U
R744 VRN-RL2HCR68J+ X 0.68 1/2W M-Film AB
R745 VRD-RA2BE393JY X 39k 1/8W Carbon AA
PWB-A: DUNTKA462WEA0
MAIN UNIT
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No. « Description Code
R746 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R747 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R752 VRD-RA2BE392JY X 3.9k 1/8W Carbon AA
U
R758 VRS-RG2HC100J+ X 10 1/2W M-Ox. AB
R762 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
U
R773 VRS-RG3LB270J+ X 27 3W M-Ox. AB
U
R774 VRS-RG3LB680J+ X 68 3W M-Ox. AB
R801 VRD-RM2HD470JY X 47 1/2W Carbon AA
R807 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R808 VRS-CY1JF272JY X 2.7k 1/16W M-Ox. AA
R809 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R810 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R816 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R925 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R926 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R961 VRD-RA2BE101JY X 100 1/8W Carbon AA
R962 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1401 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R1402 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R1403 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1404 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R1410 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1419 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1420 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1421 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1422 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1423 VRS-CY1JF822JY X 8.2k 1/16W M-Ox. AA
R1426 VRD-RA2BE750JY X 75 1/8W Carbon AA
R1428 VRD-RA2BE750JY X 75 1/8W Carbon AA
R1429 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R1431 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1432 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1434 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1435 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1440 VRS-CY1JF563JY X 56k 1/16W M-Ox. AA
R2001 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R2002 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2006 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2008 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R2009 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R2010 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R2012 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2016 VRD-RA2BE223JY X 22k 1/8W Carbon AA
R2018 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2020 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R2022 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R2023 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R2024 VRD-RA2BE682JY X 6.8k 1/8W Carbon AA
R2025 VRD-RA2BE682JY X 6.8k 1/8W Carbon AA
R2026 VRD-RA2BE682JY X 6.8k 1/8W Carbon AA
R2027 VRD-RA2BE682JY X 6.8k 1/8W Carbon AA
R2028 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R2029 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2032 VRD-RA2BE471JY X 470 1/8W Carbon AA
R2033 VRD-RA2BE334JY X 330k 1/8W Carbon AA
R2034 VRS-CY1JF334JY X 330k 1/16W M-Ox. AA
R2040 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R2041 VRD-RA2BE333JY X 33k 1/8W Carbon AA
R2042 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2043 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2044 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R2045 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2047 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R2048 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R2049 VRD-RA2BE333JY X 33k 1/8W Carbon AA
R2060 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R2061 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R2062 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
R2063 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
27C240
25
