Sharp 27C240 Service Manual

Ref. No. Part No. « Description Code
C801 VCCCCY1HH180JY X 18p 50V Ceramic AA
C807 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C808 VCEA0A1HW106M+ X 10 50V EL. AB
C809 VCEA0A1HW105M+ X 1 50V EL. AB
C811 VCKYCY1CB473KY X 0.047 16V Ceramic AA
C812 VCEA0A1HW474M+ X 0.47 50V EL. AB
C901 VCEA0A1HW105M+ X 1 50V EL. AB
C925 VCEA0A1HW106M+ X 10 50V EL. AB
C1401 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C1402 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C1403 VCEA0A1CW476M+ X 47 16V EL. AB
C1405 VCEA0A1HW106M+ X 10 50V EL. AB
C1406 VCEA0A1HW106M+ X 10 50V EL. AB
C1430 VCEA0A1CW106M+ X 10 16V EL. AB
C1433 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1434 VCEA0A1CW106M+ X 10 16V EL. AB
C1435 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C1441 VCEA0A1CW106M+ X 10 16V EL. AB
C1442 VCCCCY1HH220JY X 22p 50V Ceramic AA
C2001 VCCCCY1HH101JY X 100p 50V Ceramic AA
C2002 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C2003 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C2004 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C2006 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C2040 VCEA0A1AW107M+ X 100 10V EL. AB
C2041 VCEA0A1HW105M+ X 1 50V EL. AB
C2060 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C2061 VCKYCY1HB222KY X 2200p 50V Ceramic AA
C2062 VCEA0A1AW107M+ X 100 10V EL. AB
C2201 VCKYCY1HB682KY X 6800p 50V Ceramic AA
C2202 VCCCCY1HH151JY X 150p 50V Ceramic AA
C2203 VCCCCY1HH331JY X 330p 50V Ceramic AB
C2601 VCEA0A1CW476M+ X 47 16V EL. AB
C2602 VCCCCY1HH101JY X 100p 50V Ceramic AA
C3001 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3002 VCKYCY1HB562KY X 5600p 50V Ceramic AA
C3003 VCKYCY1EB123KY X 0.012 25V Ceramic AA
C3004 VCEA0A1HW105M+ X 1 50V EL. AB
C3005 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3006 VCEA0A1HW106M+ X 10 50V EL. AB
C3007 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3008 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C3009 VCEA0A1CW227M+ X 220 16V EL. AB
C3010 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3011 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3012 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3013 VCKYCY1HB272KY X 2700p 50V Ceramic AA
C3014 VCKYCY1CB473KY X 0.047 16V Ceramic AA
C3015 VCEACA1HC335K+ X 3.3 50V EL. AB
C3016 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3017 VCEACA1CC106K+ X 10 16V EL. AB
C3018 VCEA0A1HW105M+ X 1 50V EL. AB
C3374 VCEA0A1HW225M+ X 2.2 50V EL. AB
C3375 VCEA0A1HW225M+ X 2.2 50V EL. AB
C3376 VCKYCY1HB332KY X 3300p 50V Ceramic AA
C3501 VCEA0A1HW106M+ X 10 50V EL. AB
C3502 VCEA0A1HW475M+ X 4.7 50V EL. AB
C3503 VCEA0A1HW475M+ X 4.7 50V EL. AB
RJ1 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ2 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
PWB-A: DUNTKC290WEA4
MAIN UNIT
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No. « Description Code
RJ3 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ4 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ5 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ6 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ10 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ11 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ14 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ15 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ16 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ17 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
U
R53 VRS-RG3LB223J+ X 22k 3W M-Ox. AB
R54 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R55 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R56 VRS-CY1JF823JY X 82k 1/16W M-Ox. AA
R57 VRD-RA2BE473JY X 47k 1/8W Carbon AA
R58 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R59 VRS-CY1JF1R0JY X 1 1/16W M-Ox. AA
R101 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R102 VRS-CY1JF100JY X 10 1/16W M-Ox. AA
R201 VRS-CY1JF151JY X 150 1/16W M-Ox. AA
R202 VRS-CY1JF122JY X 1.2k 1/16W M-Ox. AA
R203 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R204 VRS-CY1JF270JY X 27 1/16W M-Ox. AA
R205 VRS-CY1JF331JY X 330 1/16W M-Ox. AA
R206 VRD-RA2EE151JY X 150 1/4W Carbon AA
R207 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R209 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R210 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R211 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R212 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R220 VRS-CY1JF331JY X 330 1/16W M-Ox. AA
R301 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R302 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R304 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R305 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R306 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R308 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R354 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R355 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R357 VRS-CY1JF822JY X 8.2k 1/16W M-Ox. AA
R359 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R401 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R402 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R403 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R404 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R410 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R411 VRS-CY1JF684JY X 680k 1/16W M-Ox. AA
R412 VRS-CY1JF391JY X 390 1/16W M-Ox. AA
R413 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R417 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R418 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R423 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R426 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R427 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R431 VRS-CY1JF272JY X 2.7k 1/16W M-Ox. AA
R432 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
U
R451 VRS-RG2HC103J+ X 10k 1/2W M-Ox. AB
R453 VRD-RA2BE152JY X 1.5k 1/8W Carbon AA
R454 VRD-RM2HD184JY X 180k 1/2W Carbon AA
R455 VRD-RA2BE392JY X 3.9k 1/8W Carbon AA
R456 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R457 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R458 VRD-RA2EE564JY X 560k 1/4W Carbon AA
R461 VRS-CY1JF274JY X 270k 1/16W M-Ox. AA
R462 VRS-CY1JF563JY X 56k 1/16W M-Ox. AA
R491 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R492 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R493 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R494 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
27C240
24
