Sharp 27SF560

44
Dimension: 140 X 215 mm
(Rear connection terminals of TV)
DVD
CAMCORDER
TV GAME
VCR
(Front connection terminals of TV)
Pull open the front door
Yellow : To video input terminal
White : To audio input (L) terminal
Red : To audio input (R) terminal
To VIDEO OUTPUT
To AUDIO OUTPUT (R)
To AUDIO OUTPUT (L)
To VIDEO OUTPUT
To AUDIO OUTPUT (L)
To AUDIO OUTPUT (R)
To AUDIO OUTPUT (L)
To AUDIO OUTPUT (L)
To AUDIO OUTPUT (R)
Using the Video and Audio Input Terminals
VIDEO EQUIPMENT
•
Connecting video equipment for playback of video material.
• To view video material from external video equipment, make sure to connect the equipment properly
to the input terminals on the TV set.
Connecting video device equipped with video output terminals
CONNECTIONS
27SF560(43-46).p65 26/10/05, 5:46 PM44
