Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
39
32F630
32F631
PICTURE TUBE
★ MARK: SPARE PARTS-DELIVERY SECTION
' MARK: X-RAY RELATED PARTS
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics iden-
tified in this manual ; electrical components having such features are
identified by å and shaded areas in the Replacement Parts Lists and
Schematic Diagrams. The use of a substitute replacement part which
does no have the same safety characteristic as the factory recom-
mended replacement parts shown in this service manual may create
shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the fol-
lowing informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order. For
location of SHARP Parts Distributor, Please call Toll-Free; 1-
800-BE-SHARP
Ref. No. Part No. ★ Description Code
'åV101 VB80AJZ90X+3E X Picture Tube CX
å L703 RCiLGA045WJZZ X Degaussing Coil AN
QEARCA006WJZZ X Ground-Part AD
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A DUNTKB567WEW2 – Main Unit(32F630) —
PWB-A DUNTKB567WEX8 – Main Unit(32F631) —
PWB-B DUNTKA527WEV9 – CRT Unit —
PWB-C DUNTKB573WEV0 – 3-Line Y/C Unit —
PWB-F DUNTKB207WEA5 – Control Unit(32F631) —
PWB-H DUNTKB569WEV0 – DF Module Unit —
PWB-S DUNTKB571WEV1 – Audio Unit —
PWB-A: DUNTKB567WEW2(32F630)
DUNTKB567WEX8(32F631)
MAIN UNIT
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTUVT1T5UF202 X VHF Tuner AR
INTEGRATED CIRCUITS
IC101 VHiPQ050ES1-1+ X PQ050ES1MXP AB
'åIC201 VHiTB1253AN-1 X TB1253AN AP
å IC361 VHiAN5277//-1 X AN5277 AG
å IC501 VHiTDA8177+-1 X TDA8177 AE
å IC701 VHiTEA1507/-1 X TEA1507P/N1 AE
'åIC703 VHiSE135N++-F X I.C. AD
IC751 VHiPQ09RD11-1 X PQ09RD11 AD
IC900 VHiCXA2089Q-2Y X CXA2089Q-6T AK
IC1403 VHiPQ05RD11-1 X PQ05RD11 AD
IC2001 RH-iXA418WJZZQ X TMP88CS38BFG AN
IC2040 VHiKiA7045A-1+ X KIA7045AP AB
IC2101 VHiBR2416E2-1∗ X BR24C16F AD
IC3001 VHiCXA2074Q-1∗ X CXA2074Q AP
TRANSISTORS
Q201 VS2SC2735//1E∗ X 2SC2735 AB
Q361 VS2SB709AR/-1∗ X 2SB709AR AA
Q401 VS2SD601AR/-1∗ X 2SD601AR AA
Q402 VS2SB709AR/-1∗ X 2SB709AR AA
Q403 VS2SD601AR/-1∗ X 2SD601AR AA
Q404 VS2SD601AR/-1∗ X 2SD601AR AA
Q451 VS2SA1266-Y-1+ X 2SA1266-Y AB
Q460 VSRT1N441C/-1∗ X RT1N441C AB
Q471 VS2SD601AR/-1∗ X 2SD601AR AA
Q472 VS2SD601AR/-1∗ X 2SD601AR AA
Q473 VS2SD601AR/-1∗ X 2SD601AR AA
Q601 VS2SC2482//-1+ X 2SC2482 AB
å Q602 VS2SC5450++1E X 2SC5450++ AH
Q672 VS2SA1266-Y-1+ X 2SA1266-Y AB
Q673 VS2SD1830//1E X 2SD1830 AD
å Q701 VSSPA11N603-1 X SPA11N603 AK
Q751 VS2SC3198-G-1+ X 2SC3198-G AB
Q755 VS2SD601AR/-1∗ X 2SD601AR AA
Q756 VS2SD601AR/-1∗ X 2SD601AR AA
Q757 VS2SC3198-G-1+ X 2SC3198-G AB
Q758 VS2SA1266-Y-1+ X 2SA1266-Y AB
Q770 VS2SC3333//-1+ X 2SC3333 AB
Q771 VS2SA1091-O1A+ X 2SA1091-O1 AC
Q802 VS2SD601AR/-1∗ X 2SD601AR AA
Q901 VS2SD601AR/-1∗ X 2SD601AR AA
Q902 VS2SD601AR/-1∗ X 2SD601AR AA
Q903 VS2SD601AR/-1∗ X 2SD601AR AA
Q904 VS2SD601AR/-1∗ X 2SD601AR AA
Q905 VS2SD601AR/-1∗ X 2SD601AR AA
Q906 VS2SD601AR/-1∗ X 2SD601AR AA
Q907 VS2SD601AR/-1∗ X 2SD601AR AA
Q908 VS2SB709AR/-1∗ X 2SB709AR AA
Q910 VS2SB709AR/-1∗ X 2SB709AR AA
Q2060 VS2SD601AR/-1∗ X 2SD601AR AA
Q2201 VS2SD601AR/-1∗ X 2SD601AR AA
Q2211 VS2SD601AR/-1∗ X 2SD601AR AA
DIODES
D52 RH-EX0676GEZZ∗ X Zener Diode, 32V AB
D103 RH-DX0441CEZZ∗ X Diode AA
D361 VHD1SS119//-1∗ X 1SS119 AA
D362 VHD1SS119//-1∗ X 1SS119 AA
D410 RH-EX0611GEZZ∗ X Zener Diode, 5.1V AB
D411 RH-EX0611GEZZ∗ X Zener Diode, 5.1V AB
D412 RH-EX0614GEZZ∗ X Zener Diode, 5.6V AB
D413 RH-EX0614GEZZ∗ X Zener Diode, 5.6V AB
D414 RH-EX0614GEZZ∗ X Zener Diode, 5.6V AB
