64
32JW-74E
VSP9402A (IC6007)
Pin List
pin 9402/32 9412/42 I/O 9402/32 9412/42 remark
52 cvbs1 I CVBS input analog input
53 cvbs2 I CVBS input analog input
54 cvbs3 I CVBS input analog input
55 cvbs4 I CVBS input or Y1 analog input
56 cvbs5 I CVBS input or C1 analog input
57 cvbs6 I CVBS input or Y2 analog input
58 cvbs7 I CVBS input or C2 analog input
63 cvbso1 O
CVBS output 1
CVBS output 2
analog output
62 cvbso2 O analog output
61 cvbso3 O CVBS output 3 analog output
70 xin I Crystal connection 1
69 xout O Crystal connection 2
23 vout O vertical output
single or double
scan, dependent
on version
17 hout O horizontal output
3
vssdacy
i656i7 S/I DAC (Y)
656 input
(MSB)
2
ayout
i656i6 O/I Y output 656 input
1
vdddacy
i656i5 S/I DAC (Y) 656 input
80
vssdacu
i656i4 S/I DAC (U) 656 input
79
auout
i656i3 O/I U output 656 input
78
vdddacu
i656i2 S/I DAC (U) 656 input
77
vssdacv
i656i1 S/I DAC (V) 656 input
76
avout
i656i0 O/I V output
656 input
(LSB)
75
vdddacv
i656iclk S/I DAC (V)
656 input
clock
27 MHz nom.
39 rin1 I R or V in1 analog input
40 gin1 I G or Y in1 analog input
41 bin1 I B of U in1 analog input
37 fbl1 I Fast Blank input 1 (H1) analog input
46 rin2 I R or V in2 analog input
47 gin2 I G or Y in2 analog input
