PRINTED WIRING BOARD ASSEMBLIES
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBE
R2. REF. NO.
3. PART NO.4. DESCRIPTION
in USA:Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
« MARK: SPARE PARTS-DELIVERY SECTION
p
MARK: X-RAY RELATED PARTS
PICTURE TUBE
(NOT REPLACEMENT ITEM)
MAIN UNIT
PWB-A: DUNTKC290WED5
TUNER
NOTE:THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDETLY
Ref. No. Part No. « Description Code
pU V101 VB89AJZ90X+1E X Picture Tube CY
U L703 RCILGA048WJZZ X Degaussing Coil AR
U QEARCA009WJZZ X Ground-Part AD
PWB-A DUNTKC290WED5 — MAIN Unit —
PWB-B DUNTKA527WEE2 — CRT Unit —
PWB-C DUNTKB573WEV0 — 3-LINE Y/C Unit —
PWB-H DUNTKB569WEV0 — DF MODULE Unit —
INTEGRATED CIRCUITS
Ref. No. Part No. « Description Code
U TU51 VTUVT1T5UF202 X Tuner AS
IC101 VHIPQ050ES1-1+ X AD
p U IC201 VHITB1253AN-1 X AS
U IC361 VHIAN5277//-1 X AK
U IC501 VHITDA8177+-1 X AG
U IC701 VHITEA1533A-1 X AG
U IC702 RH-FXA003WJZZ X AC
p U IC703 VHISE135N++-F X AF
IC751 VHIPQ09RDA1-1 X AF
IC900 VHICXA2089Q-2Y X AM
IC1403 VHIPQ05RDA1-1 X AF
IC2001 RH-IXA418WJZZQ X AQ
IC2040 VHIKIA7045A-1+ X AC
IC2101 VHIBR24L16F-1Y X AE
IC3001 VHICXA2194Q-1Y X AR
Q201 VS2SC2735//1EY X AB
Q361 VS2SB709AR/-1Y X AA
Q401 VS2SD601AR/-1Y X AA
Q402 VS2SB709AR/-1Y X AA
Q403 VS2SD601AR/-1Y X AA
Q404 VS2SD601AR/-1Y X AA
Q451 VS2SA1266-Y-1+ X AB
Q460 VSRT1N441C/-1Y X AB
Q471 VS2SD601AR/-1Y X AA
Q472 VS2SD601AR/-1Y X AA
Q473 VS2SD601AR/-1Y X AA
p U Q601 VS2SC2482//-1+ X AC
Q602 VS2SC5931++-F X AK
Q672 VS2SA1266-Y-1+ X AB
Q673 VS2SD1830//1E X AF
p U Q701 VSSPA11N603-1 X AM
Q751 VS2SC3198-G-1+ X AB
Q754 VS2SC3198-G-1+ X AB
Q755 VS2SD601AR/-1Y X AA
Q756 VS2SD601AR/-1Y X AA
Q757 VS2SC3198-G-1+ X AB
Q758 VS2SA1266-Y-1+ X AB
Q802 VS2SD601AR/-1Y X AA
Q901 VS2SD601AR/-1Y X AA
Q902 VS2SD601AR/-1Y X AA
Q903 VS2SD601AR/-1Y X AA
Q904 VS2SD601AR/-1Y X AA
Q905 VS2SD601AR/-1Y X AA
Q906 VS2SD601AR/-1Y X AA
Q907 VS2SD601AR/-1Y X AA
Q908 VS2SB709AR/-1Y X AA
Q910 VS2SB709AR/-1Y X AA
Q2041 VS2SB709AR/-1Y X AA
Q2042 VS2SB709AR/-1Y X AA
Q2060 VS2SD601AR/-1Y X AA
Q2201 VS2SD601AR/-1Y X AA
Q2211 VS2SD601AR/-1Y X AA
D52 RH-EX0676GEZZY X Zener Diode 32V AB
D103 RH-DX0441CEZZY X Diode AA
D361 VHD1SS133++-1Y X Diode AA
D362 VHD1SS133++-1Y X Diode AA
D410 RH-EX0611GEZZY X Zener Diode 5.1V AB
D411 RH-EX0611GEZZY X Zener Diode 5.1V AB
D412 RH-EX0614GEZZY X Zener Diode 5.6V AB
PQ050ES1MXP
TB1253AN
AN5277
TDA8177
TEA1533AP
PC123Y82
I.C.
PQ090RDA1SZ
CXA2089Q-6T
PQ050RDA1SZ
TMP88CS38BFG
KIA7045AP
BR24L16F
CXA2194Q
2SC2735
2SB709AR
2SD601AR
2SB709AR
2SD601AR
2SD601AR
2SA1266(Y)
RT1N441C
2SD601AR
2SD601AR
2SD601AR
2SC2482
2SC5931
2SA1266(Y)
2SD1830
SPA11N603
2SC3198-G
2SC3198-G
2SD601AR
2SD601AR
2SC3198-G
2SA1266(Y)
2SD601AR
2SD601AR
2SD601AR
2SD601AR
2SD601AR
2SD601AR
2SD601AR
2SD601AR
2SB709AR
2SB709AR
2SB709AR
2SB709AR
2SD601AR
2SD601AR
2SD601AR
TRANSISTORS
DIODE
35UF6
28
