PWB-H: DUNTKB569WEV0
DF MODULE UNIT
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
Ref. No. Part No. « Description Code
IC1680 VHIKIA358P+-1 X KIA358P AC
Q1680 VS2SC5022//1E X 2SC5022 AG
Q1681 VS2SC3198-G-1+ X 2SC3198-G AB
D1610 RH-DX0202CEZZY X Diode AC
D1681 RH-DX0475CEZZY X Diode AA
D1682 RH-DX0475CEZZY X Diode AA
D1683 RH-DX0475CEZZY X Diode AA
D1684 RH-DX0475CEZZY X Diode AA
D1686 RH-DX0487CEZZY X Diode AC
D1687 RH-EX0618GEZZY X Zener Diode 6.2V AB
D1688 VHD1SS119//-1Y X Diode AA
L1640 RCILZA022WJZZ X Coil AG
L1641 RCILZA023WJZZ X COIL AG
L1680 RCILZA034WJZZ X Coil AE
L1681 VP-DF8R2K0000Y X Peaking,8.2mH AA
T1680 RTRNZ0209PEZZ X Transformer AK
C1610 VCFYSB2EB224K X 0.22uF 250V M.Poly. AB
C1644 VCFPFA2EB684J X 0.68uF 250V EL. AC
C1677 VCKYPA1HB391K+ X 390p 50V Ceramic AA
C1678 VCKYPA1HB391K+ X 390p 50V Ceramic AA
C1681 RC-KZ0024CEZZ X 1000p 2kV M.Poly. AC
C1682 RC-KZ0037CEZZ X 390p 2kV M.Poly. AB
C1683 VCE9GA1HW335M+ X 3.3 50V EL. AB
C1684 VCEA0A1VW477M+ X 470 35V EL. AC
C1685 VCFYFA1HA474J+ X 0.47 50V Mylar AB
C1686 VCEA0A1VW108M+ X 1000 35V EL. AC
C1687 VCEA0A1EW107M+ X 100 25V EL. AB
C1695 VCFYFA1HA224J+ X 0.22 50V Mylar AB
C1696 VCQYTA1HM103J+ X 0.01uF 50V Mylar AA
R1610 VRS-VV3DB103J X 10k 2W M-Ox. AB
R1627 VRS-KT3LB122J X 1.2k 3W M-Ox. AD
R1656 VRD-RA2BE394JY X 390k 1/8W Carbon AA
R1657 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1658 VRD-RA2BE183JY X 18k 1/8W Carbon AA
R1659 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R1680 VRS-KT3LB154J X 150k 3W M-Ox. AD
R1681 VRS-KT3LB104J X 100k 3W M-Ox. AD
R1682 VRC-MA2HG333KY X 33k 1/2W Solid AB
R1683 VRD-RA2BE332JY X 3.3k 1/8W Carbon AA
R1684 VRD-RA2BE681JY X 1.5k 1/8W Carbon AA
R1685 VRS-VV3AB181J X 180 1W M-Ox. AB
R1686 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R1687 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R1688 VRD-RA2BE473JY X 47k 1/8W Carbon AA
R1689 VRD-RA2BE823JY X 82k 1/8W Carbon AA
R1690 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R1691 VRD-RA2BE823JY X 82k 1/8W Carbon AA
R1695 VRD-RA2BE224JY X 220k 1/8W M-Ox. AA
R1696 VRD-RA2BE684JY X 680k 1/8W Carbon AA
R1697 VRD-RA2EE1R0JY X 1 1/4W Carbon AA
R1698 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
R1699 VRD-RA2BE562JY X 5.6k 1/8W Carbon AA
INTEGRATED CIRCUITS
TRANSISTORS
DIODE
FILTERS AND COILS
TRANSFORMERS
P1602 QPLGN0741CEZZ X plug (7 PINS) AB
P1603 QPLGN0161FJZZ X plug 6Pin(K1-6) AD
MISCELLANEOUS PARTS
Ref. No. Part No. « Description Code
P1604 QPLGN0157FJZZ X plug 2Pin(XC) AC
RDA1680 PRDAR0135PEFW X Heat Sink AC
SG1681 QSPGH0025CEZZ X Spark Gap AC
SP1 VSP1206PB648A X Speaker (L) AK
SP2 VSP1206PB648A X Speaker (R ) AK
QCNW-A689WJZZ X WIRE (SPEAKER) AE
QCNW-B177WJZZ X WIRE (XA) AD
QCNW-B178WJZZ X WIRE (XB) AG
QCNW-B179WJZZ X WIRE (XC) AE
QCNW-B294WJZZ X WIRE (CJ) AE
QCNW-B295WJZZ X WIRE (N) AE
MISCELLANEOUS PARTS
35UF6
36
