PWB-B: DUNTKA527WEE2
CRT UNIT
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
PWB-C: DUNTKB573WEV0
3-LINE Y/C UNIT
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
INTEGRATED CIRCUITS
TRANSISTORS
FILTERS
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
FERRITE BEAD
MISCELLANEOUS PARTS
FERRITE BEAD
Ref. No. Part No. « Description Code
R875 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R876 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R877 VRD-RA2BE103JY X 10k 1/8W Carbon AA
U
R878 VRS-SV2HC120J X 12 1/2W M-Ox. AA
R1511 VRD-RA2BE101JY X 100 1/8W Carbon AA
U
R1513 VRS-VV3DB561J X 560 2W M-Ox. AA
R1514 VRD-RA2BE100JY X 10 1/8W Carbon AA
R1515 VRD-RA2BE820JY X 82 1/8W Carbon AA
R1516 VRD-RA2BE820JY X 82 1/8W Carbon AA
R1517 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R1518 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1519 VRD-RA2BE123JY X 12k 1/8W Carbon AA
R1520 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1521 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R1525 VRD-RA2EE560JY X 56 1/4W Carbon AA
R1526 VRD-RA2EE560JY X 56 1/4W Carbon AA
R1527 VRD-RM2HD1R5JY X 1.5 1/2W Carbon AA
R1528 VRD-RM2HD1R5JY X 1.5 1/2W Carbon AA
U
R1529 VRS-VV3DB221J X 220 2W M-Ox. AA
R1530 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
FB1501 RBLN-0020CEZZ+ X Ferrite Bead AB
U
P854 QPLGN0741CEZZ X plug (7 PINS) AB
P860 QPLGN0841CEZZ X plug (8 PINS) AB
P861 QPLGN0241CEZZ X plug (2 PINS) AA
SC850 QSOCV0936CEZZ X Socket,12Pin AG
RDA850 PRDAR0248PEFW X Heat Sink AD
RDA1506 PRDAR5072CEFW X Heat Sink AC
RDA1507 PRDAR5072CEFW X Heat Sink AC
IC1401 VHITC90A53F-1Y X C90A53 AS
Q1401 VS2SD601AR/-1Y X 2SD601AR AA
Q1402 VS2SD601AR/-1Y X 2SD601AR AA
Q1403 VS2SB709AR/-1Y X 2SB709AR AA
Q1404 VS2SD601AR/-1Y X 2SD601AR AA
Q1406 VS2SB709AR/-1Y X 2SB709AR AA
Q1407 VS2SD601AR/-1Y X 2SD601AR AA
Q1408 VS2SB709AR/-1Y X 2SB709AR AA
L1401 VP-XF100K0000Y X Peaking,10mH AA
L1402 VP-XF100K0000Y X Peaking,10mH AA
L1406 VP-XF220K0000Y X Peaking,22mH AA
L1407 VP-XF220K0000Y X Peaking,22mH AA
L1408 VP-XF100K0000Y X Peaking,10mH AA
L1410 VP-XF100K0000Y X Peaking,10mH AA
L1414 VP-XF330K0000Y X Peaking,33µH AA
L1417 VP-XF220K0000Y X Peaking,22mH AA
C1412 VCEA0A1HW106M+ X 10 50V EL. AA
C1413 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1414 VCCCCY1HH3R0CY X 3p 50V Ceramic AA
C1415 VCE9GA1CW106M+ X 10 16V EL. AB
C1416 VCEA0A1CW477M+ X 470 16V EL. AB
C1417 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1420 VCCCCY1HH270JY X 27p 50V Ceramic AA
C1421 VCCCCY1HH120JY X 12pF 50V Ceramic AA
Ref. No. Part No. « Description Code
C1422 VCCCCY1HH120JY X 12pF 50V Ceramic AA
C1423 VCCCCY1HH3R0CY X 3p 50V Ceramic AA
C1424 VCCCCY1HH270JY X 27p 50V Ceramic AA
C1425 VCCCCY1HH100DY X 10p 50V Ceramic AA
C1428 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1435 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1436 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1439 VCE9GA1CW106M+ X 10 16V EL. AB
C1440 VCEA0A1HW106M+ X 10 50V EL. AA
C1441 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1442 VCFYFA1HA474J+ X 0.47 50V Mylar AB
C1443 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1444 VCKYCY1HB472KY X 100 35V EL. AA
C1445 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1446 VCCCCY1HH181JY X 180p 50V Ceramic AA
C1447 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1448 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1449 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1451 VCEA0A1CW107M+ X 100 16V EL. AA
C1452 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1453 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1454 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1455 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1456 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1457 VCEA0A1HW106M+ X 10 50V EL. AA
C1458 VCEA0A1HW106M+ X 10 50V EL. AA
C1460 VCKYCY1HF103ZY X 0.01uF 50V Ceramic AA
C1470 VCCCCY1HH270JY X 27p 50V Ceramic AA
C1474 VCCCCY1HH150JY X 15p 50V Ceramic AA
R1402 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1405 VRS-CY1JF361JY X 360 1/16W M-Ox. AA
R1406 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1407 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1410 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R1411 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R1412 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1413 VRS-CY1JF122JY X 1.2k 1/16W M-Ox. AA
R1414 VRS-CY1JF331JY X 330 1/16W M-Ox. AA
R1415 VRS-CY1JF391JY X 390 1/16W M-Ox. AA
R1416 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1421 VRS-CY1JF471FY X 470 1/16W M-Ox. AA
R1423 VRS-CY1JF152FY X 1.5k 1/16W M-Ox. AA
R1426 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R1428 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R1429 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R1430 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R1431 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R1432 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1433 VRS-CY1JF122JY X 1.2k 1/16W M-Ox. AA
R1434 VRS-CY1JF331JY X 330 1/16W M-Ox. AA
R1435 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1436 VRS-CY1JF331JY X 330 1/16W M-Ox. AA
R1438 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R1456 VRS-CY1JF564JY X 560k 1/16W M-Ox. AA
R1457 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1458 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R1459 VRS-CY1JF821JY X 820 1/16W M-Ox. AA
R1466 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1467 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R1473 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1475 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
FB1401 RBLN-0061TAZZY X Ferrite Bead AA
P1401 QPLGZ0810CEZZ X plug 32" AD
MISCELLANEOUS PARTS
