V01 PICTURE 0-15 (00h-0Fh) 8 (08h)
V02 TINT 0-127 (00h-7Fh) 66 (42h)
V03 COLOR 0-127 (00h-7Fh) 56 (38h)
V05 BRIGHT 0-127 (00h-7Fh) 64 (40h)
V06 R CUT-OFF 64-255 (40h-FFh) 64 (40h)
V07 G CUT-OFF 64-255 (40h-FFh) 64 (40h)
V08 B CUT-OFF 64-255 (40h-FFh) 64 (40h)
V09 G/R DRIVE 0-127 (00h-7Fh) 64 (40h)
V10 B DRIVE 0-127 (00h-7Fh) 64 (40h)
V11Y-MUTE/V-STOP0-20 (00h)Y-Mute / Holizontal “—” 00
V12SHARP0-63 (00h-3Fh)50 (32h)32
V13 DC RESTORATION 0-3 (00h-03h) 2 (02h) 02
V14 BLACK STRETCH 0-3 (00h-03h) 2 (02h) 02
V15 ABL START POINT 0-3 (00h-03h) 3 (03h) 03
V16 ABL GAIN 0-3 (00h-03h) 2 (02h) 02
V17 γ POINT 0-3 (00h-03h) 0 (00h) 00
V19ENERGY SAVE0-63 (00h-3Fh)63 (3Fh)Offset3F
V24 LOW-G 0-255 (00h-FFh) 12 (0Ch) Color Temp. F4
V25 LOW-B 0-255 (00h-FFh) 241 (F1h) Color Temp. E6
V26 ML-G 0-255 (00h-FFh) 0 (00h) Color Temp. FD
V27ML-B0-255 (00h-FFh)247 (F7h)Color Temp.F8
V28 HIGH-G 0-255 (00h-FFh) 2 (02h) Color Temp. 01
V29 HIGH-B 0-255 (00h-FFh) 8 (08h) Color Temp. 06
V30 WPL 0-1 1 (01h) 01
V31 RGB CONTRAST 0-63 (00h-3Fh) 59 (3Bh) 3B
V34 VSM GAIN 0-3 (00h-03h) 1 (01h) 01
V36 BPF/TOF-INPUT 0-1 0 (00h) External Input 00
V37 CORING 0-1 0 (00h) 00
V38 VSM PHASE 0-1 0 (00h) 00
V39COLOR γ0-10 (00h)00
V40SHARP-INPUT0-63 (00h-3Fh)44 (2Ch)External Input2C
V41 TINT-INPUT 0-127 (00h-7Fh) 62 (3Eh) External Input 3E
V42 PICTURE-COMPONENT 0-15 (00h-0Fh) 6 (06h) Component Input
V43 TINT-COMPONENT 0-127 (00h-7Fh) 62 (3Eh) Component Input 3E
V44 COLOR-COMPONENT 0-127 (00h-7Fh) 72 (48h) Component Input 48
V45 BRIGHT-COMPONENT 0-127 (00h-7Fh) 84 (54h) Component Input
V46 R CUT OFF-COMPONENT 64-255 (00h-FFh) 64 (40h) Component Input
V47 G CUT OFF-COMPONENT 64-255 (00h-FFh) 64 (40h) Component Input
V48 B CUT OFF-COMPONENT 64-255 (00h-FFh) 64 (40h) Component Input
V49 G/R DRIVE-COMPONENT 0-127 (00h-7Fh) 64 (40h) Component Input
V50 B DRIVE-COMPONENT 0-127 (00h-7Fh) 64 (40h) Component Input
V51SHARP-COMPONENT0-63 (00h-3Fh)44 (2Ch)Component Input2C
V52 TINT-S 0-127 (00h-7Fh) 62 (3Eh) Component Input 3E
V53 C-TRAP 0-1 (00h-01h) 0 (00h) 00
V59 AUTO FRESH 0-1 (00h-01h) 0 (00h) 00
V60 SHARP P F 0-1 (00h-01h) 1 (01h) 01
V61 CD MATRIX 0-3 (00h-03h) 2 (02h) 02
V62 B-Y ATT 0-1 (00h-01h) 0 (00h) 00
V63 R-Y ATT 0-1 (00h-01h) 0 (00h) 00
V64 CD MATRIX COMPONENT 0-3 (00h-03h) 0 (00h) Component Input 00
V65 B-Y ATT-COMPONENT 0-1 (00h-01h) 0 (00h) Component Input 00
V66 R-Y ATT-COMPONENT 0-1 (00h-01h) 0 (00h) Component Input 00
V67 BUZZ 0-1 (00h-01h) 1 (01h) 01
V68 RGB ABCL 0-1 (00h-01h) 1 (01h) 01
R01 RF-AGC 0-63 (00h-3Fh) 36 (24h)
R03 RF-AGC REF 0-255 (00h-FFh) 170 (AAh) Standard value for the self-adjustment AA
D01 V POSITION 0-7 (00h-07h) 0 (00h) 00
D02 H POSITION 0-31 (00h-1Fh) 15 (0Fh)
D03 V SIZE 0-127 (00h-7Fh) 89 (59h)
D04 H SIZE 0-63 (00h-3Fh) 36 (24h)
D05 V-LINEARITY 0-15 (00h-0Fh) 8 (08h)
D06V-S CORRECTION0-15 (00h-0Fh)12 (0Dh)0D
D07 EW PARABOLA 0-63 (00h-3Fh) 43 (2Bh)
D08 EW TRAPEZIUM 0-63 (00h-3Fh) 36 (24h)
D10 AFC GAIN 0-3 (00h-03h) 2 (02h) 02
D11 V EHT 0-7 (00h-07h) 6 (06h) 06
D12H EHT0-7 (00h-07h)6 (06h)06
D13EW CORNER0-31 (00h-1Fh)8(08h)0A
D14 EW CORNER BOTTOM 19-81 (13h-51h) 50 (32h) Offset toward D13. 32
D15NOISE DET LEVEL0-3 (00h-03h)0 (00h)00
D18 V CENTERING 0-63 (00-3Fh) 36 (24h)
D19 V-AGC 0-1 (00h-01h) 0 (00h) 00
A. VCJ IC ADJUSTMENT
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
FIXED VALUE
(HEX)
RANGE
NOTES
