Sharp 36U-S50B

33
Dimension: 140 X 215 mm
(Front connection
terminals of TV)
To AUDIO OUTPUT (R)
To AUDIO OUTPUT (R)
To AUDIO OUTPUT (L)
To AUDIO OUTPUT (L)
To VIDEO OUTPUT
(Rear connection
terminals of TV)
To VIDEO OUTPUT
DVD
CAMCORDER
TV GAME
VCR
Yellow : To video input terminal
White : To audio input (L) terminal
Red : To audio input (R) terminal
Using the Video and Audio Input Terminals
VIDEO EQUIPMENT
•
Connecting video equipment for playback of video material.
• To view video material from external video equipment, make sure to connect the equipment properly
to the input terminals on the TV set.
Connecting video device equipped with video output terminals
CONNECTIONS
