8M-B120C Dismantle Instruction
5
6. Printed circuit boards
All PWBs can be removed by screw driver.
Main PWB (1pcs) Power PWB (4pcs) Back end PWB(1pcs)
Backlight Power Control PWB (1pcs) Main T-CON PWB (1pcs)
Sub T-CON PWB (8pcs) LED Driver PWB (4pcs) AC Detection PWB (1pcs)
