8M-B120C Dismantle Instruction
6
7. LCD Module bezels/angles
- LCD Dismantle procedure
1. Remove screws (part 1)
2. Remove Corner Angle (part 9) and Bezels (part 8 and 10)
3. Remove screws (part 4 and 5)
4. Remove Middle Frame (Part 2, 3, 6, and 7)
LCD
