Sharp AE-A079E - Replacement Parts List; Cabinet and Unit Parts; Control Box Parts

AY/AE-A079E
AY/AE-A099E
29
REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST [AY-A079E/AY-A099E]
CABINET AND UNIT PARTS
1- 1 CMOT-A273JBK0 Fan motor sub assembly 1 BN
1- 2 NFANCA042JBE0 Cross flow fan 1 BC
1- 3 CSRA-A444JBK0 Drain pan assembly 1 BK
1- 4 MJNTPA040JBFF Louver link 3 AC
1- 5 MLOV-A135JBFF Horizontal adjustment louver A (Vertical louver A) 9 AC
1- 6 MLOV-A136JBFF Horizontal adjustment louver B (Vertical louver B) 3 AC
1- 7 MLOV-A133JBFE Vertical adjustment louver A (Horizontal louver A) 1 AK
1- 8 MLOV-A134JBFE Vertical adjustment louver B (Horizontal louver B) 1 AK
1- 9 PPACGA002JBE0 O ring 1 AA
1-10 RMOT-A050JBE0 Louver motor 1 AY
1-11 PGUMMA071JBE0 Motor cushion 1 AN
1-12 LHLD-A197JBFP Louver holder 4 AC
1-13 PGUMMA086JBE0 Motor cushion 1 AG
1-14 PCOV-A190JBE0 Drain cover 1 AE
1-15 CHLD-A053JBK0 Bearing assembly 1 AD
1-16 LHLD-A187JBFA Tube holder 1 AD
1-17 PSHE-A099JBE0 Evaporator sheet 1 AH
1-18 LSPR-A006JBE0 Sheet spring for fixing evaporator seat 2 AB
1-19 DCHS-A255JBK0 Cabinet assembly 1 AZ
1-20 DWAK-A779JBK0 Panel assembly 1 AX
1-21 PFILMA077JBEB Air filter 2 AN
1-22 HDEC-B020JBEA Display cover 1 AL
1-23 HBDG-A059JBEA Badge 1 AF
1-24 LHLD-A209JBFA Front panel hinge R 1 AF
1-25 MARMPA012JBFA Open panel hinge L 1 AD
1-26 MARMPA013JBFA Open panel hinge R 1 AD
1-27 LHLD-A208JBFA Front panel hinge L 1 AD
1-28 PBOX-A120JBK0 Louver gear assembly 1 AZ
1-29 NBRG-A026JBFA Louver bushing 2 AB
1-30 PSHE-A098JBE0 Evaporator seal 1 AC
1-31 TLABPA175JBR0 Louver seal 1 AB
1-32 TSPC-C981JBRA Name label [AY-A079E] 1 AD
1-32 TSPC-C955JBRA Name label [AY-A099E] 1 AD
1-33 PGUMSA046JBE0 Damper rubber 1 AD
1-34 CPNL-A084JBK0 Open panel assembly 1 AV
1-35 PFPFPB074JBE0 Thermistor insulation 1 AB
1-36 PHOS-A015JBE0 Drain hose 1 AL
1-37 LHLD-A204JBF0 Motor holder 1 AE
1-38 PSEL-B417JBE0 Aluminum tape 1 AC
1-39 PSEL-B418JBE0 Aluminum tape 1 AD
1-40 PSEL-B494JBE0 Aluminum tape 1 AD
1-41 PSEL-B492JBE0 Aluminum tape 1 AC
CONTROL BOX PARTS
2- 1 FSGY-A141JBK0 Display board unit 1 AS
2- 2 FPWBFA013JBK0 Switch board unit 1 AM
2- 3 QTAN-A087JBE0 Terminal board (5P) 1 AS
2- 4 QTAN-A088JBE0 Terminal board (3P) 1 AP
2- 5 DPWBFA151JBK0 Control board unit [AY-A079E] 1 BQ
2- 5 DPWBFA149JBK0 Control board unit [AY-A099E] 1 BR
2- 6 QFS-AA050JBE0 Fuse 250V 2.5A 1 AD
2- 7 QACC-A194JBE0 Power supply cord 1 AU
2- 8 RTRN-A182JBE0 Transformer 1 AY
2- 9 RC-HZA195JBE0 Fan motor capacitor 1 AL
2-10 RTHM-A296JBE0 Thermistor 1 AN
2-11 LHLD-A190JBF0 Thermistor holder 1 AG
2-12 PBOX-A149JBF0 Control box 1 AN
2-13 HPNLCA497JBF0 Control box cover 1 AF
2-14 HPNLCA616JBE0 Control panel 1 AE
2-15 LHLD-A266JBF0 Cord holder 1 AE
2-16 LHLD-A265JBF0 Cord clamp 1 AC
2-17 TLABCB254JBR0 Wiring diagram 1 AC
2-18 PSHE-A076JBE0 Protection cover 1 AE
2-19 PGUMMA095JBE0 Wire cushion 1 AA
2-20 PCOV-A191JBE0 LED holder 1 AD
2-21 RH-IXA519JBE0 Microcomputer (IC1) 1 AX
2-22 RH-IZA149JBE0 Integrated circuit (IC2) 1 AE
2-23 RIC--A022BDE0 Integrated circuit (IC3) 1 AE
2-24 RIC--A025BDE0 Integrated circuit (IC4) 1 AE
2-25 RH-IZA140JBE0 Integrated circuit (IC5) 1 AE
2-26 RH-IZA337DRE0 EEPROM(IC6) 1 AK
2-27 VHRS201D01/-6 Solid state relay(SSR) 1 AK
2-28 RRLYJA067JBE0 Relay (RY) 1 AP
2-29 RFIL-A042JBE0 Coil (L) 1 AM
