12
AE-X07ER
AE-X09ER
AE-X12ER
REF. NO. PART NO. DESCRIPTION Q'TY CODE
2- 27 PSPF-A918JBEZ Comp cover top [AEX12ER] 1 AT
2- 28 PSPF-A878JBEZ Compressor cover [AEX07ER] [AEX09ER] 1 AT
2- 28 PSPF-A919JBEZ Compressor cover [AEX12ER] 1 AE
2- 29 PSPF-A879JBEZ Compressor cover b [AEX07ER] [AEX09ER] 1 AD
2- 30 CANG-A165JBKZ Holder ass’y [AEX12ER] 1 AH
2- 31 TLAB-C511JBRA Label 1 AC
2- 32 TLABMA356JBRA Inverter label 1
2- 33 TSPC-E667JBRZ Name badge [AEX07ER] 1 AC
2- 33 TSPC-E650JBRZ Name badge [AEX09ER] 1 AC
2- 33 TSPC-E679JBRZ Name badge [AEX12ER] 1 AC
CYCLE PARTS
3- 1 CCHS-A842JBTA Base pan ass’y [AEX07ER] [AEX09ER] 1
3- 1 CCHS-A884JBTA Base pan ass’y [AEX12ER] 1 AW
3- 2 DVLV-A571JBKZ 3way valve unit [AEX07ER] [AEX09ER] 1 AU
3- 2 DVLV-A657JBKZ 3way valve unit [AEX12ER] 1 AV
3- 3 LX-NZA270JBEZ Service nut 1
3- 4 LX-NZA271JBEZ Bonnet [AEX07ER] [AEX09ER] 1
3- 4 LX-NZA307JBEZ Bonnet [AEX12ER] 1
3- 5 DVLV-A572JBKZ 2way valve unit 1 AQ
3- 6 LX-NZA271JBEZ Bonnet 1
3- 7 DVLV-A581JBKZ Control valve ass’y [AEX07ER] [AEX09ER] 1 BG
3- 7 DVLV-A653JBKZ Control valve ass’y [AEX12ER] 1
3- 8 CCIL-A129JBKZ Coil ass’y1AU
3- 9 PVLVXA052JBEZ Reverse valve [AEX07ER] [AEX09ER] 1 BB
3- 9 PVLVXA061JBEZ Reverse valve [AEX12ER] 1 BD
3- 10 PDAI-A123JBTA Flare coupling base 1
3- 11 PGUM-A008JBE0 Damper rubber 1 AF
3- 12 DCON-A242JBPZ Condenser ass’y [AEX07ER] [AEX09ER] 1 BV
3- 12 DCON-A241JBPZ Condenser ass’y [AEX12ER] 1 BV
3- 13 PCMPRA430JBEZ Compressor 1 CC
3- 14 GLEG-A099JBE0 Compressor cushion 3 AD
3- 15 LX-NZA026JBE0 Special nut 3
PACKING PARTS
90- 1 CPADBA773YDKZ Top pad ass’y [AEX07ER] [AEX09ER] 1 AG
90- 1 CPADBA048JBKZ Top pad ass’y [AEX12ER] 1
90- 2 CPADBA774YDKZ Bottom pad ass’y [AEX07ER] [AEX09ER] 1 AN
90- 2 CPADBA049JBKZ Bottom pad ass’y [AEX12ER] 1
90- 3 SPAKCB550JBEZ Packing case [AEX07ER] 1
90- 3 SPAKCB536JBEZ Packing case [AEX09ER] 1
90- 3 SPAKCB565JBEZ Packing case [AEX12ER] 1 AU
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
