Sharp AE-X09ER - Replacement Parts Categories (AY-XP Models); Cycle Parts; Accessory Parts; Packing Parts

9
AY-XP07ER
AY-XP09ER
AY-XP12ER
REF. NO. PART NO. DESCRIPTION Q'TY CODE
2- 21 CPNL-A486JBKZ Open panel ass’y1BC
2- 21-1 HBDG-A144JBEA Badge 1 AF
2- 21-2 HDECQA097JBRA Display panel 1 AF
2- 21-3 HDECQA098JBRA Display panel 1 AX
2- 21-4 HPNL-A672JBTA Open panel 1
2- 21-5 LHLD-A680JBFA Holder 1 AD
2- 21-6 LHLD-A681JBFZ Display holder 6 AC
2- 22 DWAK-A869JBKZ Front panel ass’y1AS
2- 22-1 GWAK-A300JBFA Front panel 1 AV
2- 22-2 TLABCB878JBRZ Wiring diagram 1 AC
2- 23 DHLD-A009JBK0 Pipe holder ass’y1AE
2- 24 LHLD-A689JBFA Holder 1 AG
2- 25 LHLD-A394JBFA Pipe holder 1 AD
2- 26 PCOV-A848JBFZ Drain cover 1 AD
2- 27 PCOV-B006JBFA Screw cover 3 AD
2- 28 PFILMA191JBEZ Air filter 1 AL
2- 29 PPLTNA078JBPZ Mounting angle 1 AU
2- 30 TSPC-E666JBRZ Name badge [AYXP07ER] 1
2- 30 TSPC-E651JBRZ Name badge [AYXP09ER] 1
2- 30 TSPC-E681JBRZ Name badge [AYXP12ER] 1 AC
CYCLE PARTS
3- 1 CPIPCA796JBKZ Inlet tube ass’y [AYXP07ER] [AYXP09ER] 1 AX
3- 1 CPIPCA813JBKZ Inlet tube ass’y [AYXP12ER] 1
3- 2 DEVA-A189JBKZ Evaporator ass’y1BS
3- 3 LX-NZA169JBE0 Flare nut1/4 1 AG
3- 4 PCAP-A064JBE0 Cap 1/4 1
ACCESSORY PARTS
4- 1 CFIL-A088JBKZ Purify filter ass’y1AR
4- 2 CRMC-A629JBEZ Remote control 1 BB
4- 3 FFZK-A178JBKZ Screws kit 1
4- 4 LHLD-A688JBFA Cord holder 1 AE
4- 5 LPFT-A088JBF0 Drain joint 1 AC
4- 6 SSAKHA149YDE0 Bag 1AC
4- 7 TINS-A811JBRZ Installation manual1 1 AL
4- 8 TINS-A812JBRZ Installation manual2 1 AL
4- 9 TINSEA363JBRZ Operation manual 1 AS
4- 10 UBATUA027JBE0 Battery pack 1 AE
PACKING PARTS
90- 1 CPADBA059JBKZ Packing pad ass’y2AK
90- 2 SPADBA189JBEZ Pad 1AD
90- 3 SPAKCB549JBEZ Packing case [AYXP07ER] 1
90- 3 SPAKCB537JBEZ Packing case [AYXP09ER] 1
90- 3 SPAKCB568JBEZ Packing case [AYXP12ER] 1 AR
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
