Sharp AE-X15PU User Manual

AE-X15PU
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION Qty
1-1
CMOTLB537JBEZ N FAN MOTOR 1
1-2 LANGKA326JBTA N
MOTOR ANGLE T 1
1-3 LANGKA325JBTA N
MOTOR ANGLE 1
1-4 LANGKA324JBTA N
FAN MOTOR ANGLE SUB 2
1-5 GCAB-A469JBTA N
FRONT PANEL L 1
1-6 GGADFA049JBFA
FAN GUARD 1
1-7 CCAB-A586JBKZ N
FRONT PANEL R ASS'Y 1
1-7-1 GCAB-A468JBTA N
FRONT PANEL R 1
1-7-2 JHNDPA030JBFA N
HANDLE 1
1-7-3 PSPF-B182JBEZ
IIR SHEET A 1
1-7-4 PSEL-E252JBEZ FRONT PANEL R SEAL 1
1-8 NFANPA152JBEZ
N PROPELLER FAN 1
1-10 GPLTMA081JBTA N
SIDE CABINET L 1
1-11 JHNDPA032JBFA HANDLE 1
1-12 CPLT-A216JBKZ N SIDE CABINET R ASS'Y 1
1-12-1 GPLTMA080JBTA N SIDE CABINET R 1
1-12-2 PSEL-E388JBEZ N SIDE CABINET R SEAL B 1
1-12-3 PGUMSA148JBE0 DAMPER RUBBER 1
1-12-4 PSPF-E329JBEZ N
IIR SHEET 1
1-12-5 PSPF-B185JBEZ
IIR SHEET B 1
1-12-6 PSEL-E120JBEZ
SIDE CABINET R SEAL 1
1-13 MSPR-A026JBE0
SPRING 2
1-14 MSPR-A036JBE0
THERMISTOR SPRING 1
1-18 LHLD-B206JBWZ N
CABLE HOLDER 1
1-19 PCOV-B982JBWZ N
CABLE COVER 1
1-20
PCOV-B981JBFA N SIDE COVER 2 1
1-21
PSEL-E389JBEZ N SIDE COVER SEAL 1
1-22
PCOV-C030JBFA N VALVE COVER 1
1-23 DCAB-A185JBKZ N
TOP PLATE ASS'Y 1
1-23-1 GCAB-A478JBTA N
TOP PLATE 1
1-23-2 PSEL-E129JBEZ
TOP PLATE SEAL A 1
1-23-3 PSEL-E130JBEZ
TOP PLATE SEAL B 1
1-23-4 PSEL-E131JBEZ
TOP PLATE SEAL C 1
1-23-5 PSEL-E284JBEZ
TOP PLATE SEAL E 1
1-24 CSKR-A569JBKZ N
BULKHEAD ASS'Y 1
1-24-1 PSKR-A410JBTA N
BULKHEAD 1
1-24-2 PSEL-E285JBEZ
BULKHEAD SEAL 1
1-24-3 PSEL-E286JBEZ
BULKHEAD SEAL A 1
1-24-4 PFPFPE480JBEZ
BULKHEAD SEAL B 1
1-24-5 PFPFPE481JBEZ
BULKHEAD SEAL C 1
1-25 CANG-A358JBKZ
ANGLE ASS'Y 1
1-26 CCHS-B373JBKZ
BASE PAN ASS'Y 1
1-26-1 CCHS-B375JBTA N
BASE PAN SUB ASS'Y 1
1-26-2 PFPFPE477JBEZ
BASE PAN SEAL C 1
1-28 PDAI-A292JBTA N
FLARE COUPLING BASE 1
1-29 LX-NZA428JBEZ
SPECIAL NUT 1
1-30 LHLD-B217JBFA N
THERMISTOR HOLDER 1
1-31 PSEL-E406JBEZ
MOTOR ANGLE T SEAL 1
1-32 XTTWW40P16000 TAPPING SCREW 4
1-33
TLAB-F617JBRA N ENERGY LABEL 1
1-34
TLAB-F696JBRZ N CAUTION LABEL UL 1
1-35
TLAB-F748JBRZ N UL COPPER WIRE LABEL 1
[2] OUTDOOR UNIT STRUCTURE AND CYCLE PARTS(AE-X15PU,AE-X18PU,AE-X24PU)
BL
BB
BC
BC
BC
BC
BC
AN
AY
AZ
AZ
AZ
AW
AG
AG
AG
AY
AY
AX
AX
AK
AK
AK
AK
AK
AL
AU
AW
AN
AT
AB
AB
AC
AC
AC
AC
AC
AC
AC
AC
AC
AM
AM
AF
AF
AP
AE
AE
AE
AE
AD
AH
