AE-X15PU

NO. PARTS CODE

PRICE

RANK

NEW MARK

PART

RANK

DESCRIPTION Qty

1-36

TLABBA291JBRA AK PCI LABEL 1

1-37

TLABMA849JBRA AM INVERTER LABEL 1

1-38 TSPC-H649JBRZ

AH N NAME LABEL 1

2-1 DVLV-B073JBKZ

AY 2WAY VALVE UNIT 1

2-2 DVLV-B074JBKZ

BC 3WAY VALVE UNIT 1

2-3 DCON-A753JBPZ

CP N CONDENSER (AE-X15PU) 1

2-3

DCON-A754JBPZ CU N CONDENSER (AE-X18PU,AE-X24PU) 1

2-4 DVLV-B343JBKZ

BS N REVERSE VALVE ASS'Y (AE-X15PU) 1

2-4 DVLV-B346JBKZ

BT N REVERSE VALVE ASS'Y (AE-X18PU,AE-X24PU) 1

2-5 DVLV-B344JBKZ

BG N EXPAN.VALVE ASS'Y (AE-X15PU) 1

2-5 DVLV-B354JBKZ

BH N EXPAN.VALVE ASS'Y (AE-X18PU,AE-X24PU) 1

2-6 PSPF-B239JBEZ

AK COMRESSOR COVER TOP 1

2-7

PSPF-B328JBEZ AS N COMRESSOR COVER 1

2-8 PCMPRA688JBEZ

CF N COMRESSOR 1

2-9 LX-NZA411JBEZ

AH FRANGE NUT 1

2-10 PSEL-E239JBEZ

AH GASKET WASHER 1

2-11 PCOV-B887JBEZ

AR TERMINAL COVER 1

2-12 PSEL-E240JBEZ

AK TERMINAL GASKET 1

2-13 XNFS760-50000

AB NUT 1

2-14 LX-WZA057JBEZ

AC WASHER 22 1

2-15 GLEG-A162JBEZ

AF COMPRESSOR CUSHION 1

2-16 PSEN-A044JBKZ

AG FLARE NUT ASS'Y 1

2-17 PSEN-A053JBKZ

AN FLARE NUT ASS'Y 1

2-18 CCIL-A185JBKZ

AU N COIL ASS'Y 1

2-19 RMOTSA037JBZZ

BC COIL 1

2-20

PGUMS0170JBE0 AE DAMPER RUBBER 1

3-1 PCOV-B888JBWZ

AL COVER 1

3-2 DSGY-F029JBKZ

CA N CONTROL BOARD UNIT (AE-X15PU) 1

3-2 DSGY-F033JBKZ

CA N CONTROL BOARD UNIT (AE-X18PU) 1

3-2 DSGY-F122JBKZ

CA N CONTROL BOARD UNIT (AE-X24PU) 1

3-3

LHLD-B240JBFZ AT N HOLDER 1

3-4 LHLD-B241JBFZ

AF N HOLDER C 1

3-5 LANG-A771JBWZ

AN N TERMINAL ANGLE 1

3-6 QTANZA091JBZZ

AU N TERMINAL BOARD 1

3-7 PBOX-A570JBWZ

AK CONTROL BOX B 1

3-8 PBOX-A576JBWZ

AM CONTROL BOX 1

3-9 CBOX-A082JBKZ

AQ N CONTROL BOX C ASS'Y 1

3-10 RCILZA051JBZZ

AY N REACTOR 1

3-11 RH-HXA187JBZZ

AY N THERMISTOR 1

3-12 TLABCE028JBRZ

AD N WIRING DIAGRAM 1

3-13 TLABNA002JBRZ

AF LABEL 1

4-1

QFS-GA077JBZZ AD Fuse (FU3) 1

4-2

QFS-GA078JBZZ AD Fuse (FU2) 1

4-3

QFS-GA090JBZZ AG Fuse (FU5) 2

4-4

QFS-GA091JBZZ AG N Fuse (FU1) 1

4-5 QSPGCA006JBZZ

AH Surge absorb (SA1) 1

4-6

QW-VZG365JBZZ AF Lead wire(BT2) 1

4-7

QW-VZG366JBZZ AF Lead wire (BT1) 1

4-8

QW-VZG372JBZZ AF Lead wire (BT6) 1

4-9

QW-VZG613JBZZ AG Lead wire (BT12) 1

4-10

QW-VZG614JBZZ AG Lead wire (BT13) 1

[2] OTHER OUTDOOR UNIT ELECTRIC PARTS(AE-X15PU,AE-X18PU,AE-X24PU)
