AYXP26FRN
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] INDOOR UNIT PARTS
1-1 CMOT-A433 JBKZ BK Fan motor sub ass'y
1-2 DSGY-B830JBKZ Control board unit
1-3 QACC-A318JBZZ Power supply cord
1-4 QTANZA001JBZZ AQ Terminal board
1-5 QTANZA018JBZZ AU Terminal board
1-6 RH-HXA014JBZZ AG Thermister ass'y
1-7 RTHM-A292 JBE0 AH Thermistor
1-8 Q W-VZE403JBZZ AH Lead wire
1-9 RMOT-A110 JBZZ AN Louver motor
1-10 RMOT-A108 JBEZ AN Louver motor-B
1-11 CKITTA016AKKZ AY Plasmacluster unit
2-1 CHLD-A050JBK0 AG Bearing ass'y
2-2 PGUMMA315JBEZ AE Rubber
2-3 PGUMMA316JBEZ AE Rubber
2-4 DCHS-A502JBKZ BA Cabinet ass'y
2-5 PGID-A108JB F A AL Guide
2-6 NFANCA087JBKZ BA Crossflow fan
2-7 PCOV-A845JBFZ AG Motor cover
2-8 CCOV-A093JBKZ AL Louver cover ass'y
2-8-1 FCOV-A155JBFA AE Cover
2-8-2 MHNG-A03 1JBFA AC Cover hinge
2-8-3 PCOV-B005JBFA AF Louver cover
2-9 PCOV-A849JBFZ AF Side cover
2-10 PGID-A109JB F Z AF Guide
2-11 CLOV-A054JBKZ AN Direct.louver ass'y
2-11-1 MLOV-A385JBFA AG Air direction louver
2-11-2 NBRG-A030JBFA AB Bearing
2-11-3 NBRG-A037JBFA AE Bearing
2-12 CPNL-A485JBKZ AQ Cont.box cover ass'y
2-13 FCOV-A143JBFZ AD Senser cover
2-14 PCOV-A992JBFZ AD LED holder
2-15 PCOV-B010JBFA AF LED cover
2-16 LH LD-A449JBF0 AH Thermistor holder
2-17 LHLD-A690JBFZ BD
Senser holder
2-18 PBOX-A432JBFZ BF Control box
2-19 PCOV-A847JBPZ AG Cont.box cover
2-20 CSRA-A581JBKZ BB Drain pan ass'y
2-20-1 CHOS-A018JBKZ AN Drain hose ass'y
2-20-2 DSRA-A258JBKZ AZ Drain pan sub ass'y
2-20-3 GGAD-A057JBTA AN Wire guard
2-20-5 LH LD-A615JBFA AC Louver stopper
2-20-6 LH LD-A682JBFA AE LED holder
2-20-7 LH LD-A691JBFZ AE Lead wire guide
2-20-8 LPFT-A144JBFZ AD Drain joint
2-20-9 LPFT-A147JBFZ AD Drain joint R
2-20-10 MJNTPA095JBFA AB Louver link
2-20-11 MLOV-A346JBFA AB Vertical louver
2-20-12 MLOV-A347JBFA AB Vertical louver
2-20-13 MLOV-A38 6JBTA AS Air flow louver
2-20-14 NBRG-A028JBFA AB Bearing
2-20-15 NBRG-A031JBFA AC Bearing
2-20-16 NBRG-A038JBFA AC Bearing C
2-20-17 PGUMMA169JBE0 AD Drain plug
2-21 CPNL-A546JBKZ AZ Open panel ass'y
2-21-1 HBDG-A1 44JBEA AF Badge
2-21-2 HDECQA097JBRA AF Display panel
2-21-3 HDECQA159JBRA AZ Display panel
2-21-4 HPNL-A672JBTA AV Open panel
2-21-5 LH LD-A680JBFA AD Holder
2-21-6 LH LD-A681JBFZ AC Display holder
2-22 DWAK-A869JBKZ AS Front panel ass'y
2-22-1 GWAK-A300JBFA AV Front panel
2-22-2 TLABCB878JBRZ AC Wiring diagram
2-23 DHLD-A009JBK0 AE Pipe holder ass'y
2-24 LH LD-A689JBFA AG Holder
2-25 LH LD-A394JBFA AD Pipe holder
2-26 PCOV-A848JBFZ AD Drain cover
2-27
PCOV-B006JBFA AD Screw cover
2-28 PFILMA191JBEZ AL Air filter
2-29 PPLTNA078J BPZ AU Mounting angle
3-1 CPIPCA796JBKZ AX Inlet tube ass'y
3-2 DEVA-A189 JBKZ BS Evaporator ass'y
3-3 LX-N ZA169JBE0 AG Flare nut 1/4
3-4 LX-N ZA251JBEZ AG Flare nat
4-1 CFIL-A088JBKZ AR Purify filter ass'y
4-2 CRMC-A669JBEZ BD Remote control
4-3 FFZK-A178JBKZ AM Screws kit
4-4 LH LD-A688JBFA AE Cord holder
4-5 LPFT-A088JBF0 AC Drain joint
4-7 TINS-A983JB RZ AK Installation manual1
4-8 TLAB-C927JBEZ AH Eu energy label
4-9 TINSEA449JBRZ AE Operation manual
4-10 U BATUA027JBE0 AE Battery pack
