AYXP26FRN
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[4] OUTDOOR UNIT PARTS
1-1 CMOTLB078JBEZ BL Fan moter
1-2 DSGY-B834JBKZ CA Control board unit
1-2-6 RH-IXA790JBZZ BC IPM
1-2-7 VHDRBV2506+-F AL Diode bridge
1-3 QW-VZF151JBZZ AN Lead wire
1-4 RCILZA009JBZZ BA Reactor
1-5 RTHM-A022JBE0 AN Thermistor
1-6 QTANZA001JBZZ AQ Terminal board
1-7 FW-VZA056JBKZ AR Lead wire
1-10 RFIL-A064JBE0 AF Ferrite core
1-11 RH-HXA029JBZZ AX Thermistor ass'y
2-1 LANGKA157JBPZ AQ Motor angle
2-2 CCAB-A409JBKZ AV Top plate ass'y
2-3 TLABCC170JBR Z AC Wiring diagram
2-4 LX-BZA355JBEZ AE Special screw
2-5 PCOV-A881JBFA AL Reactor cover
2-7 CFTA-A268JBKZ AN Cover
2-7-1 PCOV-A594J BPZ AE Terminal cover
2-7-2 PFTA-A090JBFA AL Cover
2-8 PRDAFA191JBEZ AR Heat sink
2-9 LHLD-A684JBFA AN Holder
2-10 LHLD-A685JBFA AF Holder
2-11 DBOX-A048JBWZ AT Control box ass'y
2-12 PDAI-A167JBWZ AH Terminal holder
2-13 PC OV-A595JBFZ AE Cover
2-14 PSKR-A306JBPZ AT Bulkhead
2-15 GCAB-A237JBTA AY Front panel
2-16 GGADPA004JBFA AR Fan guard
2-17 JHNDPA015JBFA AD Handle
2-18 LHLD-A449JBF0 AH Thermistor holder
2-19 LHLD-A491JBFZ AD Cord clamp
2-20 LHLD-A492JBFZ AD Cord clamp base
2-21 MSPR-A026JBE0 AB Spring
2-25 NFANPA110JBEZ AQ
Propeller fan
2-26 PPLT-A370JBTA AW Side cover R
2-27 PSPF-A871JBEZ AF Comp cover top
2-28 PSPF-A878JBEZ AT Compressor cover
2-31 TLAB-C511JBRA AC Label
2-32 TLABMA356JBRA AP Inverter label
2-33 TSPC -F31 9JB RZ AC Name badge
2-34 PPLT-A195JBTA AS Side cover L
2-35 PSEL-C 830JBEZ AF Seal
2-36 CHET-A025JBKZ BM Heater ass'y
2-37 PC OV-A997JBWZ AM Cover
2-38 PSEL-C 685JBEZ AC Seal
2-39 PSEL-C 686JBEZ AC Seal
3-1 CCHS-A898JBKZ BD Base pan ass'y
3-2 DVLV-A571JBKZ AU 3way valve unit
3-5 DVLV-A572JBKZ AQ 2way valve unit
3-6 CVLV-A800JBKZ BR Reverse valve ass'y
3-8 CCIL-A129JBKZ AU Coil ass'y
3-9 PVLVXA052JBEZ BB Reverse valve
3-10 PDAI-A123JBTA AL Flare coupling base
3-12 DCON-A24 6JBPZ BX Condenser ass'y
3-13 PCMPRA430JBEZ CC Compressor
3-14 GLEG-A099JBE0 AD Compressor cushion
3-15 LX-NZA313JBEZ AE Special nut
3-16 LX-NZA002JBE0 AA Special nut
3-17 MSPR-A157JBEZ AD Protector spring
3-18 PCOV-A736JBEZ AH Terminal cover
3-19 PSEL-C 248JBEZ AG Terminal gasket
3-20 PSPF-A978JBEZ AM Compressor cover
3-21 PSPF-A879JBEZ AD Compressor cover B
3-22 PSPF-A951JBEZ AM Compressor cover
[5] OTHER PARTS (OUTDOOR UNIT)
1-2-1 QFS-CA001JB ZZ AK Fuse (20A 250V)
1-2-2 QFS-GA051JBZZ AD Fuse
1-2-3 QFS-GA052JBZZ AD Fuse
1-2-4 QFS-CA002JB ZZ AH Fuse (15A 250V)
1-2-5 QFS-GA064JBZZ AF Fuse (1A 250V)
2-22 MSPR-A027JBE0 AB Thermistor spring
3-7 DVLV-A725JBKZ B H Control valve ass'y
90-1 CPADBA773YDKZ AG Top pad ass'y
90-2 CPADBA774YDKZ AN Bottom pad ass'y
90-3 SPAKCC045JBEZ AS Packing case
