AFS120FX
1 – 5
5. AF-R100FX
Cooling Capacity BTU/h 10000
Moisture Removal Pint/h 2.5
Electrical Data
Phase Single
Rared frequency Hz 60
Rated voltage Volts 115
Rated current Amps 9.3
Rated input Watts 1020
Power factor % 96
EER BTU/Wh 9.8
Compressor
Type (Hermetically sealed rotary type)
Model, Motor Output 44R241AG-FES, 950
REFRIGERANT SYSTEM
Evaporator Louver fin, Grooved tube, 7mm, hair pin
Condenser Louver fin, Grooved tube, 7mm, hair pin
Control O.D. x I.D x Length x Q'ty(mm) Capil-
lary Tube
2.5 x 1.3 x 1150 x 2
Refrigerant Volume R-22 (OZ) Factory Charge 19.4
NET DIMENSIONS
Width Height Depth Inch (mm) 18.9" (480) x 14.4" (365) x 22.6" (575)
Net Weight Lbs 72.7
GROSS DIMENSIONS
Width Height Depth Inch (mm) 22.1" (560) x 17.1" (435) x 24.6" (625)
Gross Weight Lbs 83.7
FAN SYSTEM
Indoor side (Evaporator) Centrifugal fan
Outdoor side (Condenser) Propeller fan
Air Flow rate (Indoor side) CFM High / Med / Low
820/710/610
OTHERS
Safety devices Compressor: Over load
Fan motor: Internal thermal protector
Air filter Polypropylene net
Power cord length ft 6.0
Power plug type 125V, 15A
