AFS120FX
1 – 1
AFS120FX
Service Manual
CHAPTER 1. PRODUCT SPECIFICATION
[1] SPECIFICATION
1. AF-S60FX
Cooling Capacity BTU/h 6000
Moisture Removal Pint/h 1.9
Electrical Data
Phase Single
Rared frequency Hz 60
Rated voltage Volts 115
Rated current Amps 4.9
Rated input Watts 560
Power factor % 96
EER BTU/Wh 10.7
Compressor
Type (Hermetically sealed rotary type)
Model, Motor Output 39R141BD-04P, 570
REFRIGERANT SYSTEM
Evaporator Louver fin, Grooved tube, 7mm, hair pin
Condenser Louver fin, Grooved tube, 7mm, hair pin
Control O.D. x I.D x Length x Q'ty(mm) Capil-
lary Tube
2.5 x 1.3 x 1000 x 1
Refrigerant Volume R-22 (OZ) Factory Charge 12.7
NET DIMENSIONS
Width Height Depth Inch (mm) 18.5" (470) x 12.6" (320) x 16.3" (415)
Net Weight Lbs 46.3
GROSS DIMENSIONS
Width Height Depth Inch (mm) 22.0" (560) x 14.8" (375) x 18.7" (472)
Gross Weight Lbs 57.3
FAN SYSTEM
Indoor side (Evaporator) Centrifugal fan
Outdoor side (Condenser) Propeller fan
Air Flow rate (Indoor side) CFM High / Med / Low
500/440/386
OTHERS
Safety devices Compressor: Over load
Fan motor: Internal thermal protector
Air filter Polypropylene net
Power cord length ft 6.0
Power plug type 125V, 15A
